Belkin F9K1121v1 Manuel utilisateur

User Manual

F9K1121v1 8820-01421 Rev. A00

N600 DUAL-BAND

PLUG-IN

Wi-Fi®ROUTER

TABLE OF CONTENTS

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

What’s in the Box ................................................ 1

Initial Setup ...........................................................1

Manually Set Up Your Internet Connection ........................... 10

Additional Capabilities ..........................................22

Guest Access........................................................23

Content Filtering Powered by Norton ................................24

Intellistream QoS ....................................................25

IPv6 Configuration ..................................................28

Getting to Know Your Router ....................................29

Front Panel..........................................................29

Back Panel ..........................................................30

Technical Details ................................................ 31

Technical Features ...................................................31

System Requirements ............................................... 32

Using Your Router ..............................................33

Enabling Auto Update on Your Router ...............................33

Updating the Router’s Firmware via the Web Interface................34

Resetting the Router ................................................37

Restoring the Router to Factory Default .............................37

Troubleshooting, Support, and Warranty .........................40

Troubleshooting.....................................................40

Technical Support ...................................................44

Belkin International, Inc., Limited 2-Year Product Warranty ...........45

Regulatory Information..........................................48

FCC Statement ......................................................48

What’s in the Box

N600 Dual-Band Plug-In Wi-Fi Router

Ethernet cable

Network information card (attached to router)

Quick Setup Guide

Initial Setup

Where to Place Your Router

For the best results, place the Router next to your modem in

an open location, away from large metal objects and magnets

such as those found in speakers. Raising the Router above

floor level can improve the strength of your wireless signal.

GETTING STARTED

15 seconds

GETTING STARTED

How to Set It Up

Connect Your N600 DB Router

Restart your modem by disconnecting its power supply. Some modems

have a battery backup; this will need to be disconnected at this time

as well.

Wait approximately 15 seconds and then connect the modem’s power

supply back into a power outlet.

Prior to plugging in the Router to a power source, please make a note

of the network ID information from the label on the back of your new

Router.

Plug in the Router to an available outlet and connect it to your modem

using the cable already attached.

GETTING STARTED

Connect to Your Router

Retrieve the network ID information from the label

on the back of your new Belkin Router.

Use your computer, tablet, or smartphone to connect to

the wireless network shown on the network label that

you made a note of when setting up the hardware.

For information on how to connect your wireless devices, please

see the “Connect Your Wireless Devices” section on page 20.

When requested, please enter the password

(security key) provided on the label.

When your device has connected to the Router, use

a browser to visit http://router/ or http://192.168.2.1.

The router homepage will appear.

GETTING STARTED

If the page does not load, then try visiting

http://192.168.2.1 to see the router homepage.

Click the “Detect my connection” button in green. (If

you would rather set up the Router manually, click the

“set it up manually” link and proceed to page 10.)

After several moments, your Router should automatically detect

your Internet connection and restart. This can take anywhere from

30 seconds to 3 minutes depending on your connection type.

If your Router is unable to establish an Internet connection

on its own, you may be asked to restart your modem or

provide a username and password if your connection requires

one. Follow the on-screen instructions provided.

GETTING STARTED

Once your Router is online, it will determine if there is a

firmware update available and offer to install it. Please

allow up to 5 minutes for the firmware to update.

If there are no updates available, then setup will proceed.

GETTING STARTED

At the next screen you will be invited to change your

network name and password. Re-using your previous

network name (SSID) and password makes connecting

your existing devices to the new router much easier.

If you decide to change these settings, then enter the

new values and click “Save and Continue.” (Note: The

password must be at least 8 characters long.)

If you changed your network name and password, make note

of it on the service card located on the foot of the Router.

You will then have to connect to the new network.

GETTING STARTED

Please take this opportunity to register your Router. This will

help technical support if there is a problem with your Router.

Simply complete each of the required fields and click

“Complete Registration.” If you don’t want to register

right now, click “Register Later” to proceed.

GETTING STARTED

At the next screen you can download optional

software that was bundled with your Router.

This screen shows you optional software that is available for your

Router, such as the Belkin Wi-Fi app used to access your router’s

homepage quickly. If you wish to download and install this software

program, simply click on the button appropriate for your device.
