Belkin F8T003 Manuel utilisateur

Bluetooth

™

USB Adapter

Connect your peripherals and computing

devices, without cables

User Manual

F8T003

TABLE OF CONTENTS

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

USB Adapter Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Supported Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Software Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Installing the USB Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Installing the USB Device Driver

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Bluetooth

Configuration Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

“My Bluetooth Places” Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Uninstalling the Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

FCC/CE/IC Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

INTRODUCTION

Thank you for purchasing the

Bluetooth

USB Adapter (the USB Adapter) from Belkin

featuring

Bluetooth

wireless technology. The USB Adapter lets you create cable-free

connections between your USB desktop PC and devices using

Bluetooth

wireless

technology. The USB Adapter is compatible with all

Bluetooth

v1.1-certified devices and

enables you to wirelessly connect up to seven other devices enabled with

Bluetooth

technology, such as printers, PDAs, and cell phones simultaneously. Now you can

connect your peripherals and computing devices up to 10 meters

away without cables in your home, office, or while on the

road. Establish ad-hoc connection between devices

without having to configure a network.

Before you install and start using your new USB

Adapter, please take a few minutes to review

some of the terms that you will be seeing

throughout the document. You will find a

brief Glossary on page 27 of this manual.

PRODUCT FEATURES

The USB Adapter is compliant with

Bluetooth

standard version 1.1 and provides:

•Compliancy with

Bluetooth

specification v1.1 devices

•USB bus powering: No external power supply necessary

•Support for Microsoft®Windows®98 SE, Me, 2000, and XP

•Compatible with Mac®OS X v10.2 and higher*

•Operating distance of up to 10 meters

•Point-to-multipoint connections

•Support for data rates up to 721Kbps

•Built-in security: up to 128-bit encryption and authentication

•Compatibility with USB desktop and notebook computers

*Mac OS X driver and software provided by Apple®.

PC System Requirements

•PC-compatible computer, CPU speed of 200MHz or above

•Memory: 64MB or above, 128MB recommended

•One available USB port USB 1.1 standard

•Windows 98 SE, Me, 2000, and XP

Mac®System Requirements

•One available USB port, USB 1.1 standard

•Mac OS X v10.2 and higher*

*Mac OS X driver and software provided by Apple.

SYSTEM REQUIREMENTS

PACKAGE CONTENTS

•

Bluetooth

USB Adapter

•CD-ROM for installation software and documentation

•User Manual

•Quick Installation Guide

•Registration Card

USB ADAPTER SPECIFICATIONS

Bluetooth

Compliance: Version 1.1

Physical Interface: USBUHCI/OHCI 1.1-

compliant

Operating Frequency: 2.4 to 2.4835GHz

Output Power: 0 dBm, Class 2

Sensitivity: <0.1% BER@ -70 dBm

Data Rate: 723/57.6Kbps

Operating Range: 10-meter radius indoors

Network Topology: Point-to-Multipoint

Packet Support: 1/3/5 Slots Packet

Operation: Master/Slave

Frequency Stability: +/- 10PPM

LED Indicator: Power On/Data Traffic

Antenna Type: Internal

Dimensions: 57mm (L) x 24mm (W)

x 10mm (H)

Weight: 0.3oz. or 9g

Operating Temp: 0 to 70 degrees Celsius

Storage Temp: -30 to 85 degrees Celsius

Humidity: 10-90% (non-condensing)

Supply Voltage: 5.0VDC (USB)

Nominal Current: 100mA

Support Profiles: Service Discovery, File

Transfer, LAN Access, Serial

Port, DUN, Generic Object

Exchange, Business Card,

Push, Pull & Exchange, FAX,

Synchronization

OS Support: Windows 98 SE, Me, 2000,

and XP

Mac OS X v10.2 and higher*

Specifications are subject to change without notice.

*Mac OS X driver and software provided by Apple.

SUPPORTED PROFILES

The services supported by your USB Adapter are defined as “Profiles”.

Available profiles include:

•Generic Access

•Service Discovery

•Serial Port

•LAN Access

•Dial-Up Networking

•Generic Object Exchange

•Object Push

•File Transfer

•Synchronization

•FAX

SUPPORTED PROFILES

Your USB Adapter gives you the ability to do the following—without cables:

•Transfer files

•Access dial-up networks

•Connect to local area networks

•Perform an ActiveSync®session

•Connect to serial ports

•Exchange PIM data

•Send or exchange business cards

The basic functions of the

Bluetooth

Neighborhood include:

•Device Discovery

•Service Discovery

•Establishing links with remote devices

SOFTWARE SETUP

Software Setup for Windows 98 SE, Me, 2000, and XP

To install the software for the USB Adapter, follow the instructions below:

Note: The installation process for Windows XP may look slightly different from Windows 98 SE,

Me, and 2000.

Note: Do not insert the USB Adapter into the USB port prior to software installation.

1. Insert the software installation CD-ROM

into the PC’s CD-ROM drive.

2. The “Software InstallShield Wizard”

window appears. Click on “Next” to begin

the installation process.
