INTEGRATED DIGITAL FULL HD COLOUR TELEVISIONS

Operation Instructions

37WLU550FHID

TABLE OF CONTENTS

11-Important Information...............................................................1

1.1-Cleaning the screen and cabinet... .......................................................1

1.2-Disposing of your TV at the end of service life... ...................................1

1.3-Superior features of your integrated digital television ............................1

1.4-Receiving digital broadcasting channels ...............................................1

1.5-Changing the plug................................................................................2

22-Features of your new television ..............................................3

2.1-Special Features ..................................................................................3

33-Important Safety Instructions ..................................................4

44-Start ............................................................................................7

4.1-Aerial connection .................................................................................7

4.2-Powering on your TV and the initial use................................................7

4.3-Batteries ..............................................................................................7

55-Your new television...................................................................8

5.1-TV Control Panel..................................................................................8

5.2-Rear and Side External Connections ....................................................8

5.3-Remote Control ...................................................................................9

66-Performing the initial power-on settings ................................10

6.1-TV controls ..........................................................................................10

6.2-Turning on the TV and Setting the Channels ........................................11

6.3-Performing Digital Tunings....................................................................11

6.4-Performing Analog Tunings ..................................................................15

77-Settings of Your New Television..............................................18

7.1- Sound Menu Settings..........................................................................18

7.2-Picture Menu Settings..........................................................................19

7.3-Features Menu Settings .......................................................................21

7.4-Other Picture Features .........................................................................22

88-Teletext.......................................................................................23

99-External Equipment Connections: ...........................................25

10 10-Help and tips............................................................................30

11 11-Technical specifications chart ...............................................31

12-MAIN UK TRANSMITTER STATIONS.....................................32

13-Guarantee and Service ...........................................................33-34

LCD panels are produced with state-of-the-art technology. However, there may be missing or

lit spots on the screen under certain circumstances. That does not mean that the product is

faulty.

1.1-Cleaning the screen and cabinet...

After powering off, wipe the screen and the cabinet clean with a soft and dry cloth. We

recommend that you do not use patented polishes or solvents on the screen or cabinet since

they may cause damage.

1.2-Disposing of your TV at the end of service life...

The cold cathode fluorescent lamp found in your LCD screen contains a very small amount of

mercury. Once your TV reaches the end of its useful life, please dispose of it in accordance

with local government regulations or leave it at a recycling centre.

1.3-Superior features of your integrated digital television

This television can receive and process all analogue and digital broadcasts. This television set

has an integrated digital and analogue receiver. The digital receiver unit processes the signals

coming from digital transmitters and converts them into superior sound and image quality. TV

Guide (valid for digital broadcasts only) informs you about changes in the program list briefly

and provides program lists of all digital broadcasts for a number of forthcoming days. You

can display detailed information about each program by pressing a single button if this feature

is supported by the broadcaster. This television has a comprehensive and user friendly menu

configuration.

1.4-Receiving digital broadcasting channels

You will need an outdoor aerial to receive digital broadcasts. Contrary to the analogue

broadcasts, all digital broadcasts may not have their own transmission frequency. Instead,

various digital broadcasts channels are gathered in regional or national groups called

bouquets. You can find current transmission data from teletexts of various broadcasters or

from TV guide or from the internet.

NOTE:

• HD signals must be connected to the HDMI input or component (YPbPr) inputs. See

page 8 for external connections.

• You should check your postcode to make sure that you are in freeview coverage area

(www.freewiew.co.uk).

1Important Information

1.5-Changing the plug

The supplied mains cable already has a mains plug fitted, however should you need to

replace it at any time please refer to the appropriatte wiring information below for your

particular cable.

We would like this product, which has been manufactured in modern facilities in accordance

with total quality principles, to offer you the best performance. Therefore, please read this

entire manual carefully before you use your TV and keep it in a safe place for future reference.

2.1-Special Features

• Full HD

• HDCP feature

• MHEG 1.06

• CI Slot input

• 8-day EPG (Electronic Program Guide)

• Favourite channel list in digital mode (maximum 6 lists)

• Compatible with cable broadcasts

• Wide angle of vision

• PIP (Picture in Picture) from AV

• Scart socket, AV Socket and external sound system connection

• S-VHS and v inputs for S-Video connection

• PC connection, 2-HDMI 1.3 input

• Low energy consumption

• AVL

• SRS TruSurround sound

• DNR and MPEG NR

• Programmable power on

• Programmable power off

• 250 pages Teletext

• Fastext

• Graphic equalizer

• Sharpness feature in Colour Transitions (CTI)

• Sharpness feature and picture resolution (LTI) in black-white transitions

• A clearer Picture made possible with a Digital Comb Filter

• Active Contrast

• On-screen viewing of all settings, program numbers and all the processes

• Manual Fine Tuning

• 100 Analog Program memory

• 1000 Digital channel memory

• Infrared remote control equipped with all functions

• Parental Control

• Ability to watch NTSC broadcast via Scart input

• User friendly on-screen menu system

• 4:3, 16:9, 14:9 Letterbox, Subtitle and Panorama picture formats

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks

or registered trademarks of HDMI Licensing LLC.

2Features of your new television

• Cover a table with a soft towel (or other protection to prevent damage to the TV or

table)

• Carefully lay the T.V. front down on the table

• position the T.V. table stand so that it hangs over the edge of the table

• Remove the screws that hold the stand to the T.V. (A torx screwdriver is required

• Remove the stand.

• Attach any new brackets before lifting T.V. back up.

Note: Keep removed stand and screws safely for future use.

This symbol is used to warn the user about the “dangerous voltage” contained

inside the housing of the product that may create a risk of electrical shock.

This symbol is used to remind the user important usage and service instructions

supplied with the TV.

1) Please READ the operating

instructions before using

the TV for the first time.

2) Please observe the

instructions contained in

the Operating Instructions.

3) Please consider all warnings.

4) MAKE SURE that all

power connections

(extension cables and the

connections between the

TV components) have

been made properly and

in accordance with the manufacturer’s

instructions. Before making or changing

the connections, power off the TV and

unplug the mains connection plug.

5) If you have any doubts regarding the

installation, operation or safety of the TV,

please REFER to the retailer.

6) BE CAREFUL with glass panels and

covers on the TV. The screen glass

may break and cause serious injuries if

something hits it.

7) To ensure adequate ventilation, please

leave a clearance area of at least 10 cm

around the television. This clearance

prevents the TV from overheating and

consequently causing damage.

• Using the TV in dusty environments

should also be avoided.

• Never block the slots and openings by

placing the TV on a bed, sofa, pillow or

other similar surfaces.

• Never install the TV into closed places

such as bookcases or cabinets unless

adequate ventilation is provided.

8) DO NOT COVER the

ventilation openings

of the TV with items

such as newspapers,

table-clothes, curtains,

etc. Overheating causes damage and

shortens the service life of the TV.

9) Your TV may be damaged

if you place it under

direct sunshine or close

to a heater. Please

abstain from using the

product in very hot or

humid locations or in places where the

temperature is likely to decrease below

5°C (41°F). DO NOT PLACE on or near

the TV any hot objects or items with

open flame such as candles or any night

lamps. The high temperature can melt

plastic parts and cause a fire.

Important Safety Instructions

13) Make sure that the power

cable is not stepped on and

that there is no bending

at the plug sections, plug

heads and TV output point.

14) Use only the add-ons/accessories

specified by the manufacturer.

15) Use only brackets or

stands specified by the

manufacturer or sold along

with the product. Place your

device on a level surface.

10) Never operate your

TV close to water.

Operating your TV,

for example, near a

bathtub, washbasin,

kitchen washbasin, washing basin, wet

basement and swimming pool can cause

fire or electric shock.

• Do not allow your TV to get wet. Never

pour any liquids onto

the TV. Do not operate

your TV if any solid

or liquid substance

enters into it. This can

cause electric shock and your TV may be

damaged. Have it checked immediately

by qualified personnel.

• Keep open flame sources (such as

candles) away from TV

in order to avoid risk of

fire.

11) DO NOT USE

headphones at extremely high volume

levels since this may

cause permanent loss of

hearing.

12) Operate your TV only in

the 230 V 50Hz voltage

range. Use the AC power

cable supplied with the

product. If your TV is

a grounded (Class I)

product, then it must

certainly be connected to

a grounded socket.

• Thesocketintowhichyoupluginthe

AC power cable must be within easy

reach.

• UnplugtheTVinordertodisconnect

it from mains power.

Note: Do not use defective sockets. Make

sure that the plug is firmly inserted into

the socket. If the plug remains loose,

then it can cause fire due to arcing. Refer

to an electrician to have your socket

replaced.

16) Unplug the power cable

during thunderstorms or

when you will not use your

TV for a long period of time.

17) Consult authorised

service personnel for

service requirements.

Never attempt to

repair the TV yourself.

Opening the cabinet

can expose you to dangerous voltages

or other hazardous situations. Service is

required in situations such as damage

to the power cable of the TV or its plug,

water spills or substances falling into

the TV, the TV is subjected to rain or

moisture, it does not operate normally or

it is dropped.

18) Wipe the TV cabinet

clean with a soft and dry

cloth. Wipe dust from the

screen gently with a soft

cloth. Stubborn stains

can be cleaned with a

cloth slightly moistened

with soap and lukewarm water. Never

use solvents such as thinner or gasoline

for cleaning. Unplug the AC power cable

from the socket when cleaning the TV.

Otherwise, there is the risk of electric

shock.

19) Do not dispose of the

batteries in fire.

• Do not short circuit,

dismantle or overheat

the batteries. There is

theriskofexplosion

if the batteries are not replaced

correctly. Replace only with the

same or equivalent type batteries.

20) Disposing of the exhausted

batteries:

• Dispose of the exhausted

batteries in accordance with

the local laws and regulations in order to

protect our environment.

21) Do not dispose of your TV

with regular household waste.

Observe local laws and

regulations for disposal.

Note 1: This is a Class A product. During

operation, the device can cause radio

interference. In this case the user may

have to remedy this. Please contact your

specialist dealer.

Note 2: Electromagnetic fields can cause

temporary performance degradation. This

can be distinguished as noise in the image.

Not 1: Your TV will switch to the STANDBY

mode in five minutes if there is no broadcast

signal from the aerial.

Note 2: Your TV is equipped to operate with

TV buttons in case your remote is broken or

the batteries are exhausted.

3. To power on your television,

press any numerical key or PR+ or

PR- keys on the remote control.

For this process, you can also use

the buttons on your TV. The picture

will appear on the screen after a

short while.

Remove your television carefully from its

box. You can keep the packaging of your

television to use in future.

Contents of the box

Power cable

Remote control

2 batteries

Note: Scart, HDMI, VGA and PHONO

cables are not supplied with the device.

4.1-Aerial connection

4.2-Powering on your TV and

the initial use

1. Insert the power cable into the power

supply input located on the back panel of

the LCD TV.

2. Insert the power cable plug supplied with

the device into the mains socket.

Start

Note: If you are not going to use your

television for a long time, unplug its power

cable from the socket.

Initial power on and performing

settings

To set up your television, read the sections

on the TV controls and making the channel

settings.

4.3-Batteries

Open the lid of the battery compartment

and make sure that you have placed the

batteries in the correct direction. For this

remote control, UM-4, IEC R03 or AAA 1.5 V

batteries are suitable.

Do not throw your old batteries into the fire,

discard them in a dedicated waste area for

this purpose.

Do not mix used batteries with new ones or

different types of batteries together.

The performance of the remote control will

be reduced at a distance of 8 meters from or

at an angle of 30 degrees beyond the centre

of the TV.

5.1-TV Control Panel

or Program Down/Up button or Volume Level Down/Up

button

On-Off / Standby button

or or

Stand by indicator

Bright light: TV is in Stand-by

Dimmed light: TV is On

No light: Power Cable is not connected.

Menu button / Source selection button

5.2-Rear and Side External Connections

Please see Technical Specifications Table on page 31 for the available external connections

on your television.

• Please do not use the video PHONO and S-Video connection simultaneously, otherwise

these two devices might influence the picture quality of one another.

Your new television

1-Component video input (Y)

2-Component audio input (L)

3-Component video input (Pb)

4-Component audio input (R)

5-SPDIF Digital audio output

6-Component video input (Pr))

7-VGA (PC connection input))

8-AV1 scart

9-AV2 scart)

10-Antenna input

11-PC audio input

12-Power input

13-Stereo Headphone socket

14-S-VHS input

15- Video input PHONO connector

16-Sound input PHONO connector (Left/L)

17-Sound input PHONO connector (Right/R)

18-CI slot input

19-HDMI 1 input

20-HDMI 2 input

Table des matières

Autres manuels Beko TV

Beko

Beko 23WLB450S Manuel utilisateur

Beko

Beko E1 CHASSIS Manuel utilisateur

Beko

Beko K1 CHASSIS Manuel utilisateur

Beko

Beko B24L 5845 4B Manuel utilisateur

Beko

Beko 42" Manuel utilisateur

Beko

Beko C7 Series Manuel utilisateur

Beko

Beko LM CHASSIS Manuel utilisateur

Beko

Beko 20231ND Manuel utilisateur

Beko

Beko A40L 5845 4B Manuel utilisateur

Beko

Beko 37WLU530HID Manuel utilisateur

Beko

Beko B32 D 560 B Guide de référence

Beko

Beko B75 D 986 S Manuel utilisateur

Beko

Beko 42WLU530HID Manuel utilisateur

Beko

Beko 26WLK530HID Manuel utilisateur

Beko

Beko B55 Q 990 A Manuel utilisateur

Beko

Beko B49L 8840 Manuel utilisateur

Beko

Beko 22WLP530HID Manuel utilisateur

Beko

Beko L6B PDP TV Manuel utilisateur

Beko

Beko 32WLU550FHID Manuel utilisateur

Beko

Beko 15WLP530HID Manuel utilisateur

Beko

Beko 26WLA500S Manuel utilisateur

Beko

Beko 32WLA530HID Manuel utilisateur

Beko

Beko B40L 5845 4B Manuel utilisateur

Beko

Beko 26WLB520HD Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur
