Specifications

ENGLISH

ULTRAGRAPH DIGITAL DEQ1024

Version 1.0 July 2003

ULTRAGRAPH DIGITAL DEQ1024

DEQ1024

ULTRAGRAPH DIGITAL

Digital Stereo 31-Band 24-Bit 96 kHz Equalizer Feedback Destroyer Dynamics Processor

sUltra high-resolution processor for all EQ, RT and dynamic applications, especially for P and audiophile

mastering

sUnique TRUE CURVE Functionwhat you see on the faders is what you get as frequency response

sRevolutionary FBQ DETECTION system instantly reveals critical frequencies and can also be used as

udio nalyzer

sutomatic and ultra-fast Feedback Destroyer plus feedback indication via fader LEDs

sInaudible Noise Gate/Peak Limiter function plus amazing Stereo Imager for spatial enhancement

sdditional sweepable high and low cut filters for removal of unwanted frequencies like floor rumble and high-

frequency noise

sIntegrated Pink Noise generator for perfect room and loudspeaker equalization

sDigital ES/EBU and S/PDIF interface and selectable sample rates (44.1, 48, 96 kHz)

sUltra high-resolution 24-bit/96 kHz /D- and D/ converters and high-performance 24/48-bit MOTOROL ®

DSP for ultimate sonic resolution

sRelay-controlled hard-bypass with an auto-bypass function during power failure (failsafe relay)

sHighly accurate, 2 x 12-digit LED meters for easy input and output level setting

sUltra high-quality, illuminated 45-mm faders, sealed rotary controls and illuminated switches

sServo-balanced inputs and outputs on gold-plated XLR and ¼" TRS connectors

sInternal switch-mode power supply for maximum flexibility (100 - 240 V~), noise-free audio, superior transient

response and lowest possible power consumption

sExtremely rugged construction ensures long life even under the most demanding conditions

sDesigned in Germany. Manufactured under ISO9000 certified management system

ULTRAGRAPH DIGITAL DEQ1024

SPECIFICATIONS

ANALOG INPUTS

Type electronically balanced

Connector XLR

Impedance 22 kΩ at 1 kHz

Max. input level 12 or 22 dBu, switchable

CMRR 80 dB typ.

ANALOG OUTPUTS

Type servo-balanced

Connector XLR

Impedance 100 Ω at 1 kHz

Max. output level 12 or 22 dBu, switchable

SYSTEM SPECIFICATIONS

Frequency response 15 Hz to 35 kHz, /- 3 dB

Signal-to-noise ratio 104 dBu, a-weighted,

22 Hz - 22 kHz

THD 0.004 % typ. @ 4 dBu, 1 kHz,

gain 1

Crosstalk < -85 dB, 22 Hz - 22 kHz

BYPASS

Type Relay, hard-bypass in case of

power failure

DIGITAL INPUTS

Type XLR transformer-balanced

Standard AES/EBU or S/PDIF

Input impedance 110 Ω

Nom. input level 0.2 - 5 V peak-to-peak

DIGITAL OUTPUTS

Type XLR transformer-balanced

Standard AES/EBU or S/PDIF

Impedance 110 Ω

Output level 2 - 5 V peak-to-peak

DIGITAL PROCESSING

Converter 24-bit Delta-Sigma, 64/128

oversampling

Sample rate 44.1 kHz, 48 kHz, 96 kHz

GRAPHIC EQUALIZER

Type analog 1/3-oct EQ

Frequency range 20 Hz to 20 kHz 31 1/3-oct. bands

according to ISO frequencies

Bandwidth 1/3-oct.

Control range /-6, /-12 dB or 0/-24 dB

(switchable)

FEEDBACK DESTROYER (FBD)

Type digital signal analysis for

feedback identification

Filter max. 10 digital notch filters per

channel, automatic feedback

suppression system

Frequency range 20 Hz - 20 kHz

Bandwidth 1/10-oct.

Control range -48 dB in 6 dB-steps

MASTER

Gain -9 dB to 9 dB

FILTER

Low Cut 20 Hz to 160 Hz (12 dB/oct.)

High Cut 2.5 kHz to 16 kHz (12 dB/oct.)

DYNAMICS

Type gate and limiter with digital IGC

(Interactive Gain Control)

Threshold variable: -60 to -10 dB (gate)

variable: -6 to 9 dB (limiter)

FUNCTION SWITCHES

Bypass switch, to deactivate equalizer

functions

Meter in/out selects between input and

output metering

Fader range sets the maximal cut/boost

for the 31 bands

Standby switches into standby mode

Pink noise -48 dB to 0 dB

FB indicator recognition of frequency band

intensity

True Curve Algorithm for achieving filter

curve linearity

DISPLAYS

Input/output level 12-digit LED display: -48/-36/-24/

-18/-12/-6/-3/0/ 3/ 6/ 9 dB/CLIP

Function switch LED display of each switch

(except for clock and

configuration switches)

POWER SUPPLY

Voltage 85 to 250 V~, 50/60 Hz,

auto range

Power consumption typ. 10 W

Fuse T 1 A H

Mains connector Standard IEC receptacle

DIMENSIONS/WEIGHT

Dimensions (H x W x D) approx. 3.5" (89 mm)

x 19" (482.6 mm)

x 5.3" (135 mm)

Shipping weight approx. 2.5 kg (5 lbs)

BEHRINGER continuously strives to assure the highest quality standards

possible. Required modifications may be implemented without prior notice.

echnical data and the appearance of the unit may deviate from the

above values and/or illustrations.

ULTRAGRAPH DIGITAL DEQ1024

The information contained in this manual is subject to change without notice. No part of this manual may be reproduced or

transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any

purpose, without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH.

BEHRINGER Spezielle Studiotechnik GmbH, Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany

Tel. 49 2154 9206 0, Fax 49 2154 9206 4903
