Behringer FEEDBACK DESTROYER PRO DSP1100P Manuel utilisateur

www.behringer.com

Version 1.1 May 2000

Technical Specifications

ENGLISH

FEEDBACKDESTROYER®

PRO DSP1100P

DSP1100P

FEEDBACKDESTROYERPRO

Ultra-high performance 2-channel digital Feedback Destroyer / Parametric EQ powered by a 24-bit high-speed DSP

s20-bitA/DandD/Aconverterswith64/128timesoversamplingforultra-highheadroomandresolution

sAutomaticallyand “intelligently” searchesout and destroysup to 12frequencies per channel

s24fully programmable Parametric Filters that canbe set manually or viaMIDI

s“Set-and-forget”defaultsettingenablesimmediateandsuper-easyFeedbackDestroyerperformance

sSingle-Shot mode automatically searches and destroys feedback and locks the filter until you reset them

manually

sAutomodecontinuouslymonitors the mix, resetting programmed filters automatically

sManual mode allows for setting up to 2 x 12 fully parametric filters including Frequency, Bandwidth and

Gain

sSingle-Shot, Auto and Manual modes are assignable for each filter

sFree FEEDBACK DESTROYER software allows for total remote control via PC (download at

www.behringer.com)

sTwosoftwareenginesgiveyouindependentorcoupledfunctionsonleftandrightchannels

sInternal 24-bit processing with professional 46 kHz sampling rate

sServo-balancedInputsandOutputsongold-platedXLRandTRSJackconnectorsforhighsignalintegrity

sFull MIDI capability and user preset memories to store programs for instant recall

sAccurateeight-segmentLEDlevelmeterssimplifylevel setting for optimum performance

s“Future-proof”software-upgradeablearchitecture

sHigh-qualitycomponentsandexceptionally rugged construction ensures long life and durability

sInternalpowersupplydesignforprofessionalapplications

sManufacturedunderISO9000certifiedmanagementsystem

SPECIFICATIONS

AnalogInputs

Connectors XLR and 1/4" jack

Type RF filtered, servo balancedinput

Impedance 60kOhmsbalanced,30kOhmsunbalanced

NominalOperatingLevel -10 dBV to +4 dBu

Max.InputLevel +16 dBu at +4 dB nominal level, +2 dBV at -10 dBV nominal level

Analog Outputs

Connectors XLR and 1/4" jack

Type electronicallyservo-balancedoutputstage

Impedance 60Ohmsbalanced,30 Ohms unbalanced

Max.OutputLevel +16 dBu at +4 dB nominal level, +2 dBV at -10 dBV nominal level

Systemspecifications

Bandwidth 20 Hz to 20 kHz, -3 dB

Noise > 94 dB, unweighted, 20 Hz to 20 kHz

THD 0.0075 % typ. @ +4 dBu, 1 kHz, Gain 1

Crosstalk < -76 dB

MIDIInterface

Type 5-Pin-DIN-Socket IN /OUT / THRU

Digital Processing

Converters 20-bitSigma-Delta,64/128-timesoversampling

Sampling Rate 46.875 kHz

Display

Type 2 ½-digit numeric LED-Display

Power Supply

MainsVoltages USA/Canada 120 V ~, 60 Hz

U.K./Australia 240 V ~, 50 Hz

Europe 230 V ~, 50 Hz

Generalexportmodel 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz

Fuse 100 - 120 V ~: T 125 mA H

200 - 240 V ~: T 63 mA H

PowerConsumption max. 15 Watts

MainsConnection StandardIECreceptacle

Physical

Dimensions (H * W * D) app. 1 3/4" (44.5 mm) * 19" (482.6 mm) * 7 1/2" (190.5 mm)

NetWeight app. 2 kg

ShippingWeight app. 3 kg

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time

to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.

The information contained in this sheet is subject to change without notice. No part of this sheet may be reproduced or transmit-

ted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any purpose,

without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH.

BEHRINGERandFEEDBACKDESTROYERareregisteredtrademarks.ALLRIGHTSRESERVED.

BEHRINGERSpezielle Studiotechnik GmbH,Hanns-Martin-Schleyer-Str. 36-38,47877Willich-MünchheideII, Germany

Tel. +49 (0) 21 54 / 92 06-0, Fax +49 (0) 21 54 / 92 06-30
