CHORUS SPACE-C CC300

Thank you for showing your confidence in us by purchasing the BEHRINGER CHORUS

SPACE-C CC300. This ultimate effects pedal comes with 4 dedicated space presets that

let you add a breathtaking third dimension to your sound or instrument. Experience the

secret weapon of professional recording studios.

The chorus effect adds a shifting detuned signal to the original, similar to playing in

unison in a group of instruments, and it is often used for dispersing sounds.

1. CONTROLS

Top view

The MODE SELECTOR switches let you choose between 4 dedicated space

presets. Use these presets in any combination or even activate them at the same

time. This results in 16 combinations giving you a wide range of spacious effects.

The effect gets deeper from the left to the right.

The ON/BATT LED illuminates when the effect is activated. It also serves as a

battery level indicator.

Use the footswitch to activate/deactivate the effect.

Use this 1/4" TS IN connector to plug in the instrument cable.

The two 1/4" TS OUT A and OUT B connectors send the signal to your amp. Use

both connectors if you want to achieve full stereo chorus effect. For mono use

plug in OUT A only.

Use the DC IN connection to plug in a 9 V power supply (not included).

The BATTERY COMPARTMENT is located underneath the pedal cover. To install or

replace the 9 V battery (not included), press the hinges with a ballpoint pen and remove

the pedal cover. Be careful not to scratch the unit.

The CC300 has no on/off switch. As soon as you insert the plug into the IN

connector, the CC300 is on. When not in use, remove the plug from the IN

connector. This extends the life of the battery.

The SERIAL NUMBER is located at the underside.

CHORUS SPACE-C CC300

2. WARRANTY

For our current warranty terms, please refer to our website at http://www.behringer.com.

3. SPECIFICATIONS

In Connector 1/4" TS

Impedance 500 kΩ

Out A Connector 1/4" TS

Impedance 1 kΩ

Out B Connector 1/4" TS

Impedance 1 kΩ

Power supply 9 V_, 100 mA, regulated

BEHRINGERPSU-SB

USA/Canada 120 V~, 60 Hz

Europe/U.K./Australia 230 V~, 50 Hz

China 220 V~, 50 Hz

Korea 220 V~, 60 Hz

Japan 100 V~, 50/60 Hz

Power connector 2 mm DC jack, negative center

Battery 9 V type 6LR61

Power consumption 30 mA

Dimensions (H x W x D) approx. 54 mm (2 1/8") x 70 mm (2 3/4") x 123 mm (4 4/5")

Weight approx. 0.33 kg (0.73 lbs)

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made

from time to time to existing products without prior notice. Specifications and appearance may therefore differ from those listed or shown.

4. SAFETY INSTRUCTIONS

Do not use near water, or install near heat sources. Use only authorized attachments/accessories. Do not service product yourself.

Contact our qualified servicing personnel for servicing or repairs, especially when power supply cord or plug is damaged.

No utilizar cerca de agua o instalar cerca de fuentes de calor. Utilice sólo accesorios y aditamentos autorizados. No intenté reparar

el producto usted mismo. Contacte a nuestro personal técnico cualificado para servicio y reparaciones, especialmente cuando la

fuente o el cable de alimentación estén dañados.

Не эксплуатируйте прибор вблизи от источников воды и тепла. Применяйте только авторизованные дополнительные

устройства. Никогда не ремонтируйте прибор самостоятельно. Ремонт может производить только квалифицированный

специализированный персонал, особенно при повреждениях сетевого провода или сетевой вилки.

Die deutsche Anleitung ist erhältlich @ www.behringer.com

Manuel francophone en téléchargement sur www.behringer.com

Manualen español disponibleen www.behringer.com

Manualiitaliani disponibili @www.behringer.com

Русскоязычное руководство @ www.behringer.com

Polska instrukcja dostępna jest pod adresem @ www.behringer.com

Nederlandsehandleiding beschikbaar @www.behringer.com

Suomenkielinen käyttöohje saatavilla osoitteesta www.behringer.com

Svensk manual finns tillgänglig på www.behringer.com

Dansk vejledning findes på @ www.behringer.com

Manualportuguês disponível@ www.behringer.com

Åëëçíéêü åã÷åéñßäéï õðÜñ÷åé äéáèÝóéìï óôç äéåýèõíóç www.behringer.com

Technicalspecificationsandappearancesubjecttochange withoutnotice.The informationcontainedhereinis correctatthetime

ofprinting. BEHRINGERaccepts noliability forany losswhich maybe sufferedby anyperson whorelies eitherwholly orin part

uponanydescription, photograph orstatement contained herein.Coloursand specification mayvaryslightly from product.

Productsaresoldthrough our authorised dealers only. Distributors and dealersarenotagents of BEHRINGERandhave

absolutelynoauthoritytobind BEHRINGERbyanyexpressorimpliedundertakingor representation.Nopartofthismanualmay

bereproducedortransmittedinanyformorbyanymeans, electronicormechanical,includingphotocopyingandrecordingofany

kind,foranypurpose,withouttheexpresswrittenpermissionofBEHRINGERInternationalGmbH.BEHRINGER,theBEHRINGER

Hanns-Martin-Schleyer-Str.36-38,47877Willich-Münchheide II,Germany.Tel.+49215492060,Fax +492154 92064903
