Installation and Operating instructions for

CP26xx

Multi-touch built-in Panel PC

Version: 1.5

Date: 2023-09-28

 Table of contents

CP26xx 1
Table of contents
1Foreword 3
1 Notes on the Documentation 3
1.1 Liability Conditions 3
1.2 Trademarks 3
1.3 Patent Pending 3
1.4 Copyright 3
1.5 State at Delivery 3
1.6 Delivery conditions 3
2 Description of safety symbols 4
3 Basic safety measures 5
4 Operator’s obligation to exercise diligence 6
4.1 National regulations 6
4.2 Procedure in the event of a fault 6
4.3 Operator requirements 6
2Product Description 7
1 Product overview 7
2 Appropriate Use 8
3 Access to the connectors 8
4 Interfaces 9
4.1 Power Supply (X101) 9
4.2 Network connection LAN1 (X 102) 9
4.3 EtherCAT connection (X 103) 9
4.4 USB output (X 104, X 105) 9
4.5 Serial interface COM1 (X107) 9
4.6 Ground connection (Ground) 9
5 Access to the battery and the plug-in card slot 10
6 Status-LEDs 10
7 1-second UPS 11
3Installation 12
1 Transport and Unpacking 12
1.1 Transport 12
1.2 Unpacking 12
2 Installation in the control cabinet 13
2.1 Preparation of the control cabinet 13
2.2 Installation in a control cabinet wall 13
2.3 Mounting of the Panel PC 14

Table of contents

2CP26xx
3 Fitting the power supply cable 15
4 Connecting the Panel PC 16
4.1 Connecting cables 16
4.2 Earthing measures 16
4Operating Instructions 17
1 Switching the Panel PC on and off 17
1.1 Switching on 17
1.2 Shutting down and switching off 17
1.3 First switching on and driver installation 17
2 Operation 17
3 Servicing and maintenance 18
3.1 Cleaning 18
3.2 Maintenance 18
3.3 Replacing the battery on the motherboard 18
4 Emergency procedures 18
5 Shutting down 18
5.1 Disposal 18
5Troubleshooting 19
6Assembly dimensions 20
7Technical Data 21
8Appendix 22
1 Beckhoff Support and Service 22
1.1 Beckhoff branches and partner companies 22
1.2 Beckhoff company headquarters 22
2 Approvals for USA and Canada 23
3 FCC Approvals for the United States of America 23
4 FCC Approval for Canada 23


Foreword

CP26xx 3

1 Foreword

1.1 Notes on the Documentation

This description is only intended for the use of trained specialists in control and automation engineering

who are familiar with the applicable national standards. It is essential that the following notes and

explanations are followed when installing and commissioning these components.

The responsible staff must ensure that the application or use of the products described satisfy all the

requirements for safety, including all the relevant laws, regulations, guidelines and standards.

1.1.1 Liability Conditions

The documentation has been prepared with care. The products described are, however, constantly under

development. For that reason the documentation is not in every case checked for consistency with

performance data, standards or other characteristics. In the event that it contains technical or editorial

errors, we retain the right to make alterations at any time and without warning. No claims for the

modification of products that have already been supplied may be made on the basis of the data, diagrams

and descriptions in this documentation.

1.1.2 Trademarks

Beckhoff®, TwinCAT®, EtherCAT®, Safety over EtherCAT®, TwinSAFE®and XFC®are registered

trademarks of and licensed by Beckhoff Automation GmbH.

Other designations used in this publication may be trademarks whose use by third parties for their own

purposes could violate the rights of the owners.

1.1.3 Patent Pending

The EtherCAT Technology is covered, including but not limited to the following patent applications and

patents: EP1590927, EP1789857, DE102004044764, DE102007017835 with corresponding applications

or registrations in various other countries.

The TwinCAT Technology is covered, including but not limited to the following patent applications and

patents: EP0851348, US6167425 with corresponding applications or registrations in various other

countries.

1.1.4 Copyright

©Beckhoff Automation GmbH.

The reproduction, distribution and utilization of this document as well as the communication of its contents

to others without express authorization are prohibited. Offenders will be held liable for the payment of

1.1.5 State at Delivery

All the components are supplied in particular hardware and software configurations appropriate for the

application. Modifications to hardware or software configurations other than those described in the

documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH.

1.1.6 Delivery conditions

In addition, the general delivery conditions of the company Beckhoff Automation GmbH apply.

Foreword

4CP26xx

1.2 Description of safety symbols

The following safety symbols are used in this operating manual. They are intended to alert the reader to

the associated safety instructions.

DANGER

Acute risk of injury!

If you do not adhere the safety advise adjoining this symbol, there is immediate

danger to life and health of individuals!

WARNING

Risk of injury!

If you do not adhere the safety advise adjoining this symbol, there is danger to life and

health of individuals!

CAUTION

Hazard to individuals!

If you do not adhere the safety advise adjoining this symbol, there is obvious hazard to

individuals!

Attention

Hazard to devices and environment

If you do not adhere the notice adjoining this symbol, there is obvious hazard to

materials and environment.

Note

Note or pointer

This symbol indicates information that contributes to better understanding.

Foreword

CP26xx 5

1.3 Basic safety measures

Before the Panel PC is switched off, software that is running must be properly closed.

Otherwise it is possible that data on the storage medium is lost. Please read the section Switching the

Panel PC on and off.

Warning

Switch off all parts of the equipment, then uncouple the Panel PC

Before opening the housing, and whenever the Panel PC is not being used for control

purposes (such as during functional checks after a repair), all parts of the equipment

must first be switched off, after which the Panel PC is to be disconnected from the

equipment.

Disconnect the device by unplugging the connectors on the rear side of the Panel PC.

Items of equipment that have been switched off must be secured against being switched on again.

Warning

Do not exchange any parts when under power

When components are being fitted or removed, the supply voltage must be switched

off.

Fitting work on the Panel PC can result in damage:

•if metal objects such as screws or tools fall onto operating circuit boards

•if connecting cables internal to the Panel PC are removed or inserted during

operation.

Foreword

6CP26xx

1.4 Operator’s obligation to exercise diligence

The operator must ensure that

•the product is only used as intended (see chapter Product Description)

•the product is in a sound condition and in working order during operation

•the product is operated, maintained and repaired only by suitably qualified and authorized

personnel

•the personnel is instructed regularly about relevant occupational safety and environmental

protection aspects, and is familiar with the operating manual and in particular the safety notes

contained herein

•the operation manual is in good condition and complete, and always available for reference at the

location of the product.

Note

Do not open the housing of the Panel PC!

For technical support contact Beckhoff Service.

1.4.1 National regulations

Depending on the type of machine and plant in which the Panel PC is used, national regulations

governing the controllers of such machines will apply, and must be observed by the operator. These

regulations cover, amongst other things, the intervals between inspections of the controller. The operator

must initiate such inspections in good time.

1.4.2 Procedure in the event of a fault

In the event of faults at the Panel PC, the list in the section Troubleshooting can be used to determine the

measures to be taken.

1.4.3 Operator requirements

Anyone who uses the Panel PC must have read these operating instructions and must be familiar with all

the functions of the software installed on the Industrial PC to which he has access.

Product Description

CP26xx 7

2 Product Description

2.1 Product overview

The compact multi-touch built-in Panel PC

The new Beckhoff Panel PC generation with industry-standard multi-touch display offers a feature-laden

solution for any application. The wide selection of models offers different display sizes and formats as

well as custom designs. Even for single-touch users, this new Panel PC generation offers an excellent

price-to-performance ratio and represents an economical alternative to other systems.

The multi-touch built-in Panel PCs offer the following benefits:

•aluminium housing with glass front

•all connectors at the bottom of the rear side

•1 slot for one MicroSD Flash Card, accessible from outside

•protection class front side IP65, rear side IP20

•lithium battery of the system clock, accessible from the rear side

•pull-out clamping levers for fast installation without loose parts

•multi-finger touch screen

•TFT display in eight sizes

Product Description

8CP26xx

2.2 Appropriate Use

The multi-touch built-in Panel PC CP26xx is designed for industrial application in machine and plant

engineering. A multi-touch display is accommodated in an aluminium housing. The Panel PC is installed

in the front of control cabinets.

Danger

Risk of explosion!

The Panel PC must not be used where there is a risk of explosion.

2.3 Access to the connectors

The connectors of the Panel PC are located at the rear side of the housing.

Picture: Bottom view
