>>> SAFETY MESSAGE HIERARCHY

> EN

Safety message hierarchy

This manual uses the following types of

safety messages to draw your attention to

important safety and other information

for use of the Becker® MAP PILOT.

Please review the symbols and content of

the boxes below. The information in the

DANGER, WARNING, CAUTION

and NOTICE boxes describes the poten-

tial consequence associated with disre-

garding the messages throughout the

manual. The information in the NOTE

boxes relates to use of the Becker® MAP

PILOT.

DANGER

The warnings contain safety information

regarding hazardous situations, which if

not avoided, will result in death or seri-

ous injury.

WARNING

These warnings contain safety informa-

tion regarding hazardous situations

which, if not avoided, could result in

death or serious injury.

CAUTION

These warnings contain safety informa-

tion regarding hazardous situations

which, if not avoided, could result in mi-

nor or moderate injury.

NOTICE

These warnings contain information re-

garding items or situations which may

cause damage to the unit or vehicle if dis-

regarded, information regarding unit

warranties and/or information pertinent

to traffic laws.

Note:

This provides information regarding use

of the unit.

CONTENTS >>>

> EN

Safety message hierarchy 1

Contents 2

Safety information 4

The Becker® MAP PILOT 6

Usage 6

Unpacking the Becker® MAP PILOT 6

Checking the delivery 6

Delivery contents 6

Complaints 7

Dealing with the packaging 7

Description of unit 7

Battery 7

USB connecting cable 7

Map update/Additional functions 7

Registration 8

Repairs 8

Emissions and disposal 8

General operation 9

Maintenance and care 9

Battery quality declaration 10

Commissioning 10

Power supply 10

Memory card 10

Unit holder 11

Basic operation 11

Calling up navigation mode 11

Selecting/highlighting elements 11

Keys near the rotary control/push button 12

Back function 12

Delete function 12

Menu basics 12

Main menu 12

Using the input menu 13

Entering characters 13

Selecting from a list 14

Selecting a character set/special

characters 14

Switching between upper and

lower case 14

Malfunctions 15

Content Manager Becker®

MAP PILOT 15

Installing the Content Manager

Becker® MAP PILOT 15

Starting the Content Manager 16

Navigation mode 17

What is navigation? 17

Last destinations 18

Using last destinations 18

Starting with existing destination 18

Displaying or editing a destination 18

Home address 19

Destination input 20

Structure of the destination input

menu 20

Entering an address 20

Selecting a country 21

Selecting an address and starting

route guidance 21

Points of interest 25

POI nearby/POI near destination 26

POI near address 26

Entering a POI directly 27

Entering a POI directly by phone

number 27

Selecting a destination from the map 28

Coordinate entry 28

Route planning 29

Creating a new route 30

Editing a route 31

Traffic announcements

using TMC 31

Displaying TMC messages 31

Reading a message 32

Displaying the relevant road in

the map 32

Taking announcements into

consideration when calculating routes 32

Automatic recalculation 32

Manual recalculation 33

The map display 33

Calling up the map display 34

Structure of the map display 34

Map display without route guidance 34

Map display with route guidance 34

Split screen with route guidance 35

Route guidance with arrow display 36

Using the map display 36

Map zooming 36

Contents

>>> CONTENTS

> EN

Map Toolbox 37

Route 37

Enter/delete stopover. 37

TMC on your route 37

POI (Points of Interest) on your route 38

Set route options 39

Display Entire route 39

Block a route section 40

Skip destination 41

Display destination list 41

Stop destination navigation. 42

Map display 42

Displaying position 43

Repeat announcement 44

Mute announcement 44

Settings 45

Route guidance settings 45

Route options 45

Realistic intersection displays 46

Signposts 46

Lane recommendations 46

Announcements 47

Map settings 47

Autozoom 47

POIs on the map 48

Speed limits 48

Driver alerts 49

TMC settings 49

System settings 50

Language 50

Design variants 50

Pin protection 50

Map update reminder 51

Information 51

Factory reset 51

Glossary 52

Index 53

NOTICE 55

CE declaration of conformity 55

Disposal 56

Disposal of the battery 57

Duty to supply information according

to battery legislation (BattV) 57

Removing the battery 57

The information and data contained in

this document is subject to change with-

out notice.

No part of this document may be repro-

duced or transmitted for any purpose

without the prior written permission of

HARMAN/BECKER Automotive

Systems GmbH. All technical data, draw-

ings etc. are protected by copyright law.

Automotive Systems GmbH

SAFETY INFORMATION >>>

> EN

Safety information

WARNING

• The unit may only be operated if the traffic situation permits and if you are absolutely certain that you, your fellow

passengers or other road users will not be put at risk, encumbered or distracted by it. This unit should not be used as a

substitute for the personal judgment of the driver.

• Applicable traffic regulations must be observed at all times. Destinations may only be input when the vehicle is stationary.

• The unit may only be used for its intended purpose. The volume of the navigational unit should be set so that noises

outside the vehicle can still be heard.

• The SD memory card can be removed. Small children could swallow it.

• Insufficient attention to the road, traffic controls or traffic conditions may result in traffic accidents. Accordingly, the

driver should not operate the unit while he/she is driving.

>>> SAFETY INFORMATION

> EN NOTICE

• The navigational system is only an aid. The data/details provided may in some cases be incorrect. The driver must always

decide whether or not to follow the directions given. We accept no liability for incorrect details issued by the navigational

system. As a result of traffic routing changes and deviating data, inaccurate or incorrect instructions may be given. Drivers

should always pay attention to the actual road signs and traffic conditions. In particular, the navigational system cannot

be used as a means of orientation in cases of poor visibility.

• The unit should be switched off immediately if faults occur (e.g. development of smoke or smells).

• For safety reasons, the unit may only be opened by a specialist. Please refer to your dealer for repair.

• Never open the unit (with the exception of the battery compartment) or the rechargeable battery. Any modification to

the unit is also impermissible and renders the type approval invalid.

• Use only genuine Harman original accessories. This will ensure that all the relevant regulations are complied with and

damage to health and property is avoided. Dispose of defective units and the rechargeable battery according to the

applicable legal requirements.

• No warranty is granted in the case of improper use. These safety instructions also apply to genuine Harman original

accessories.

THE BECKER® MAP PILOT >>>

> EN

The Becker® MAP PILOT

Usage

With the Becker® MAP PILOT you have

a powerful navigation module for your car.

The unit and the accessories are to be pro-

tected against moisture and dirt.

With GPS = Global Positioning System

you no longer have to waste time looking

up road maps.

Your Becker® MAP PILOT is equipped

with TMC. TMC gives you the option of

receiving traffic announcements. You will

then be informed of any traffic problems.

The system plans an alternative route au-

tomatically or on request to avoid traffic

problems, depending on the setting.

Unpacking the Becker® MAP

PILOT

Checking the delivery

Before starting up the Becker® MAP

PILOT, the delivery contents must be

checked to ensure they are complete and

in good order.

>Carefully unpack the packaging con-

tents and check them.

Delivery contents

Becker® MAP PILOT including bat-

tery

Leaflet with installation instructions

USB cable

Note:

Your Becker® MAP PILOT is delivered

in stable packaging. If the packaging or

its contents exhibit serious damage, the

unit must not be unpacked further. In

this case, please contact your dealer.

>>> THE BECKER® MAP PILOT

> EN

Complaints

Please check first on

www.beckermappilot.com (FAQs, soft-

ware updates) for possible solutions. If

this should not lead to success, please con-

tact your dealer.

Dealing with the packaging

The original packaging must be kept in a

dry place at least for the warranty period.

Description of unit

The Becker® MAP PILOT consists of the

basic Becker® MAP PILOT unit and the

supplied accessories in the delivery con-

tents.

Battery

The integrated rechargeable battery is

charged when the Becker® MAP PILOT

is placed in the holder and the vehicle ig-

nition is switched on.

USB connecting cable

You can connect the Becker® MAP

PILOT to a standard personal computer

having a USB interface using the USB

connecting cable provided. The 8 GB

flash memory of the Becker® MAP

PILOT and any SD card can then be ad-

dressed via the PC like a removable stor-

age medium.

Map update/Additional func-

tions

The road network is constantly changing,

but having a fresh map ensures you have

the wealth of information you need to

find your destination with ease.

It is also possible that in the course of fur-

ther development of your device new

functions will be available.

With the program described under “Con-

tent Manager Becker® MAP PILOT” on

page 15 you can easily keep your Becker®

MAP PILOT up to date.

Note:

It must be disposed of correctly in line

with the national regulations. The pack-

aging must not be burnt. The packaging

can be handed over to the dealer, depend-

ing on the country where delivered.

NOTICE

The basic unit and the accessories must

not be opened or modified in any way

(except the battery cover).

Note:

When the Becker® MAP PILOT is con-

nected to a PC, it is supplied with power

via the PC and does not consume battery

power.

THE BECKER® MAP PILOT >>>

> EN

Registration

You can register your product using our

software service. We will then inform you

of any new updates and other news.

You can register online on the Becker

homepage www.beckermappilot.com.

Repairs

The unit must not be opened in the event

of damage. Please contact your dealer.

Emissions and disposal

Information on emissions, electromagnet-

ic compatibility and disposal can be found

in “NOTICE” on page 55.

>>> GENERAL OPERATION

> EN

General operation

Maintenance and care

The unit is maintenance-free.

For proper care, a commercially available

cleansing fluid for electrical devices may

be applied using a soft damp cloth.

Your unit was designed and manufactured

with great care and should be treated with

equal care. You will enjoy your unit for a

long time to come if you observe the rec-

ommendations listed below:

• Protect your unit and the accessories

from water and moisture. If your unit

has been exposed to moisture, switch it

off immediately and disconnect the

power supply. Allow to dry at room

temperature.

• Do not store and operate your unit in a

dusty or dirty environment.

• Do not store your unit in hot environ-

ments. High temperatures can shorten

the service life of electronic components

in your unit, damage the rechargeable

batteries and cause certain plastics to

warp or melt.

• Do not store your unit in cold environ-

ments. During operation, when the

unit warms up to operating tempera-

ture, moisture may form internally,

causing damage to electronic compo-

nents.

• Do not drop your unit, protect it from

shocks and do not shake it. Improper

handling can damage components

within the unit.

• Never use corrosive or aggressive chem-

icals, cleaning solutions or aggressive

detergents for cleaning.

All the above information applies equally

to the unit, the rechargeable battery and

all accessories. Should one of these parts

not work properly, please contact your au-

thorised dealer.

DANGER

Danger to life by electrocution. Always

switch off the unit and disconnect the

mains power supply unit before clean-

ing the unit, supplied components or ac-

cessories.

Note:

Do not use any aggressive or abrasive

substances or cloths which may damage

the surface.

The unit must not be exposed to water.

Autres manuels pour MAP PILOT

Table des matières

Autres manuels Becker GPS

Becker

Becker Traffic Assist Z 098 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST Z101 Manuel utilisateur

Becker

Becker Traffic Assist Pro Z 250 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST HIGHSPEED Manuel utilisateur

Becker

Becker TRAFFIC ASSIST 7827 Manuel utilisateur

Becker

Becker Traffic Assist Z 200 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST PRO 7929 Manuel utilisateur

Becker

Becker MAP PILOT Manuel utilisateur

Becker

Becker Traffic Assist Z 201 Manuel utilisateur

Becker

Becker Ready 50 Manuel utilisateur

Becker

Becker Ready 50 Manuel utilisateur

Becker

Becker Highspeed 7934 Manuel utilisateur

Becker

Becker Traffic Assist Z 112 Manuel utilisateur

Becker

Becker Traffic Assist 7927 Manuel utilisateur

Becker

Becker MAP PILOT Manuel utilisateur

Becker

Becker BE7977 Manuel utilisateur

Becker

Becker Traffic Assist Pro Z 250 Instructions d'utilisation et d'installation

Becker

Becker MR 109 Series Manuel utilisateur

Becker

Becker TRAFFIC ASSIST PRO Manuel utilisateur

Becker

Becker MAP PILOT Manuel utilisateur

Becker

Becker READY 45 LMU Manuel utilisateur

Becker

Becker TRAFFIC STAR NAVIGATION Manuel utilisateur

Becker

Becker Highspeed 7934 Manuel utilisateur

Becker

Becker TRAFFIC ASSIST 7977 Manuel utilisateur

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Garmin

Garmin SOUNDER 125 Manuel utilisateur

Garmin

Garmin DEZL 580 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Garmin

Garmin ECHOMAP PLUS Manuel utilisateur

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Garmin

Garmin 15 H Series Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

Garmin

Garmin DEZL OTR500 Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur
