BeaverLAB DDL-MX Manuel utilisateur
BeaverLAB Intelligent
Microscope MX
DDL MX Instruction Manual
Please read this user manual carefully! Better reading experience!
Please keep the manual properly!
Catalogue
1. Product Overview
2. Instructions For Use
3. Instructions For Using Microscope
4. Instructions For Operate Steps of the microscope
5. User Guide For Interface
6. Function Description Of External Equipment
7. Accessories And Tools
8. Troubleshooting Of Microscope
9. Trademarks And Legal Statement
10. Product Warranty Instructions
Overall Parameters Of Microscope
01
02
03
06
11
15
26
19
20
20
1 Product Overview
∙ Thank you for purchasing BeaverLAB intelligent microscope, hereinafter referred to as microscope.
∙ Please read this manual carefully and keep it properly before use. Do not use the microscope without any
instructions.
01
Please read this manual carefully and use it correctly.
Pay attention to protect the lens. Be sure to close the lens cover after using, avoid entering dust or foreign
matters.
Pay attention to protect the display screen. Please close the screen after using, avoid damaging the display
screen.
The observation table of this microscope is a lifting table. Please keep the table clean and do not press it
heavily.
When placing specimens or other observation objects, pay attention to the placement position and place
them in the center accurately below the lens as far as possible. Avoid being unable to see objects and bring a
bad experience.
2 Instructions For Use
02
Import of external files is not supported (external files such as videos, pictures, and documents do not support
import and reading, which may cause the device to malfunction.)
3 Instructions For Microscope
Microscope Composition
03
Screen
Host Head
Objective Lense
Lifting Table
Base
Upright column
04
Objective Lens Switching Knob
Objective Lens
Lighting Adjusting
Knob
Platform Move Back
And Forth Button
100x / 600X / 1200X switch by rotation
Turn it on clockwise &
increase the brightness
Turn the brightnessdown
Rotate counterclockwise to move the left
platform backward
Rotate the platform clockwise and move it
forward
Platform Bottom Light
Adjustment Knob
Turn it on clockwise, turn it up,
turn it down
Focusing Knob
(Fine Adjustment)
Zoom out clockwise /
zoom in counterclockwise
Platform Lifting
Adjustment Knob
Decrease counterclockwise /
increase clockwise
Platform Left And
Right Movement Knob
Rotate counterclockwise and
move the platform to the left
Rotate the platform clockwise
and move it to the right
Knob Function Description
•At low temperature, the available capacity of the battery will decay to varying degrees.
•In case of any abnormality, please contact the after-sales department for maintenance. Disassembling the
microscope without permission will not enjoy the warranty policy and may lead to irreparable damage.
Use Environment
Please use it at-
10 ℃ ~ 45 ℃
Please prevent the
microscope from getting
wet by water, beverages
and corrosive lampliquids
Please keep the
microscope away from
heat source, open
explosive gas (liquid)
Please avoid dust
enteringthe microscope lens
and inside
Please avoid the
impact and
violent vibration of the
microscope
05
USB
It can be operated by
connecting the mouse
Interface Usage
Charging / Data Transmission Port
Long press on /
DC5V Charging / Using Adapter
You can connect your mobile phone to export
data Connect windows computer and operate
with
computer software
06
Charging Instructions
Can use daily mobile phone
charger, computer The power
bank charges the microscope.
Do not charge for more than
service life of the battery.
During charging, if the microscope shell and battery have slight heating,
it is normal. Please rest assured to use it 12hStorage Environment
Store in a cool and dry place for daily use and avoid direct sunlight.
Avoid storing the microscope in a place where there is a risk of falling, which may cause lens deviation inside
the microscope or damage to other components, as well as other irreparable defects damage problem.
The red light is always on during charging and
the green light is always on after charging
07
4 Instructions for using the microscope
1. Place Stably
long time to start the machine
2. Open the screen
4. Move the platform to a suitable
08
5. Remove the lens cover and put in the observation items
(note that the specimen should be facing the eyepiece)
7. Raise the platform to a suitable height
6. Select the multiple to be observed (note
that the specimen should be facing the
eyepiece)
8. Adjust the intensity of bottom
lighting and top lighting
