Baxi Neta-tec Plus Guide de configuration

Features and benets

• 5-yearpartsandlabourwarranty**withanoptionto

extendto7†

• Widemodulationratio-1:5–fewerignitionsmeangreater

reliabilityandlesswearandtearoncomponents

• Twospeedpump–40%reductioninelectrical

consumptionperyear

• Spacesaving,cupboard-t*dimensionsandextensiveue

optionsformoreexiblesiting

• Lowliftweightandonepiecepre-plumbingjigforeasier

installation

• CompatiblewithBaxi’srangeofhigh-efciencycontrols

andaccessories

• Fullheateamsupportfromover280expertGasSafe

registeredengineers

Withallofthesefantasticfeaturesandbenets,recommending

theBaxiNeta-tecPlusCombiGAtoyourcustomershasnever

beeneasier.

Baxi Neta-tec Plus Combi GA - 24kW, 28kW and 33kW

TheBaxiNeta-tecPlusCombiGAisthelatestadditiontotheBaxirange.Ittsneatlybehindanordinarykitchencupboard*foramore

exibleanddiscreetsitingwiththebigplusofacustomerfriendly5-yearwarranty**

Baxi’sinnovativeTHINKcombustionmanagementsystemisttedasstandard,includingGasAdaptiveControlwhichcontinuously

optimisescombustionbyadjustingthegasandairmix.TheBaxiNeta-tecPlusCombiGAprovidesmaximumenergyefciencywithfewer

ignitions,meaninggreaterreliability.

*Totstandardcupboarddimensionsof900mmx500mmx300mmwithremovalofcontrolpanelap.Excludes32kWmodel

**SubjecttoregistrationandanannualservicebyanyGasSaferegisteredinstaller

†Forfulltermsgotowww.works2gether.co.uk/7year

Formoreinformationcall08448711525orvisitwww.baxi.co.uk

Baxi Neta-tec Plus.

The only thing that’s

not compact is its

5-year warranty.

00m

390

2mm

106m

mm Mi

(300mm Min if

sin

125m

)

flueing system

)

mm Mi

5mm

5mm Min

450mm Min

For servicing

purposes

In operation

At least 1.5°

290mm

*300mmwithcontrolpanelap

Neta-tec-Plus-Data-SheetV2.indd 1 14/11/2012 15:49

Technical specications

Neta-tec Plus

Combi 24 GA

Neta-tec Plus

Combi 28 GA

Neta-tec Plus

Combi 33 GA

Sales Code

Boiler only 7210899 7210901 7210903

Std. Flue 720870201 720870201 720870201

Boiler with Std. Flue 7210905 7210906 7210907

Controls

Concealed User Controls Yes Yes Yes

User Adjustable DHW Temperature Yes Yes Yes

User Adjustable CH Temperature Yes Yes Yes

LCD Control Panel Temp/Status/Fault Diagnosis Display Yes Yes Yes

Performance

Heat Output CH kW (Max) 20 24 28

kW (Min) 3.4 3.8 4.7

Heat Output DHW Output - kW (Max) 24 28 33

Maximum DHW Flow Rate (Delta T @ 35oMax) l/min 9.8 11.5 13.5

Minimum DHW Flow Rate Required l/min 2 2 2

Minimum Operating DHW Pressure Required bar 0.15 0.15 0.15

SEDBUK 2005 Seasonal Efciency NG/LPG % 91.1/93.2 91.1/93.2 91.1/93.2

SEDBUK 2009 Seasonal Efciency NG/LPG % 88.9/91.0 89.0/91.0 89.0/90.9

NOx Class (5 being lowest) 1 - 5 5 5 5

NOx Emission mg/kW/h 16.1 19.3 17

CO Emission mg/kW/h 5.1 8 7.5

Gas

Gas Supply Pipe Size (mm) 22 22 22

NG & LPG (Propane) Compatible (Single Product) Yes Yes Yes

Nominal Gas Inlet Pressure NG/LPG (mbar) 20/37 20/37 20/37

Maximum Gas Rate (NG/Propane) after 10 mins m3/hr 2.5/1.92 3.0/2.25 3.5/2.64

Electrical

Electrical Supply Volts/Hz 230V/50Hz 230V/50Hz 230V/50Hz

Permanent Live Required Yes Yes Yes

Electrical Cable Required (Core) 3 x 0.75 3 x 0.75 3 x 0.75

Power Consumption Watts 104 116 133

External Fuse Rating Amps 3 3 3

Boiler IP Rating Approval Category IPX5D IPX5D IPX5D

Mechanical & Hydraulic Connections

CH Flow/Return Pipe Size (mm) 22 22 22

DHW Flow/Inlet/PRV Size (mm) 15 15 15

Condensate Discharge Pipe Size (mm) 21.5 21.5 21.5

Installation

24 hr Pump Exercise Yes Yes Yes

Pump Overrun Yes Yes Yes

System Filling Loop Standard Standard Standard

Integral System Pump 2 Speed 2 Speed 2 Speed

Integral ‘Boiler Only’ Frost Thermostat Yes Yes Yes

Pre-plumb Jig Available Yes Yes Yes

Stand off Bracket (Optional) Yes Yes Yes

Installer Lift Weight Max (kg) 34 34 36

Flue Systems

Max Horizontal Ø60/100 m 10 10 10

Max Vertical Ø60/100 m 10 10 10

Max Horizontal Ø80/125 m 20 20 20

Max Vertical Ø80/125 m 20 20 20

Twin-pipe Horizontal Ø80/80 m 15 15 15

Twin-pipe Vertical Ø80/80 m 15 15 15

Plume Management Kit (Max Length) m 8 8 8

Formoreinformationcall08448711525orvisitwww.baxi.co.uk

Neta-tec-Plus-Data-SheetV2.indd 2 14/11/2012 15:49
