Baumatic BLE360SS Manuel utilisateur

BLE360SS

Refrigerator

USER MANUAL FOR YOUR BAUMATIC

BLE360SS

Refrigerator

You will be mine

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference. for

you or any person not familiar with the operation of the appliance.

DD 05/10/06

Contents

Environmentalnote 4

Important safety information 5 – 6

Specifications of your refrigerator 7

Description of the appliance 8

Description of the product features 9

Using your Baumatic refrigerator 10

Beforeswitchingon 10

Duringfirstuse 10

Controlpanel 11

Turning on the appliance and setting the thermostat 11 - 12

The digital display 12

Arranging and storing food in your refrigerator 12-13

Cleaning and maintenance 14

Defrosting the refrigerator compartment 14 – 15

Replacing the light bulb 15

Installation 16

Electricalconnection 16

Positioning 17-18

Reversing the door of your appliance 19 - 20

Troubleshooting 20 - 22

Baumatic Ltd. Conditions of guarantee 23

Contactdetails 24

Environmental note

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If

you are unsure of any of the information contained in

this booklet, please contact the Baumatic Technical

Department.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person.

Use of the appliance

oYour appliance is only designed to be used in the

home. It is suitable for storing food that needs to

be chilled and refrigerated. If it is used for any

other purpose or it is not used correctly, then

Baumatic Ltd. Will accept no liability for any

damage that may be caused.

oAltering the specification of the appliance must not be attempted

for reasons of safety.

Before using your appliance

oCheck the appliance for any signs of transport damage. If you

notice any damage, then you should not connect your appliance

to your mains supply and should contact your retailer.

Refrigerant

oYour appliance contains R600a refrigerant, which is a natural gas

that does not contain CFCs that can damage the environment.

However it is a flammable substance, therefore care should be

taken:

During the transportation and installation of the

appliance, make sure that the refrigeration pipework

does not get damaged.

If it does become damaged then sources of ignition

and open flames should be avoided. Also the room

that the appliance is situated in should be thoroughly

ventilated.

oDo not place any objects on top of the appliance,

as this may damage the table top.

Child safety

oPackaging material should be kept away from

children.

oChildren should not be allowed to touch the

controls or play with the appliance.

General safety

oDo not pull on the power supply cable to remove the plug from

your mains supply socket.

oDo not pull out or insert the plug with wet hands.

oDo not attempt to use your appliance outdoors or

any place where it is likely to come into contact

with the elements.

oBefore cleaning the appliance or performing

maintenance work, ensure that the appliance has been

disconnected from your mains supply.

oNever allow the back coils of the appliance to come into contact

with the wall surface.

oAlways ensure that the location where you are installing your

appliance is free of stored items such as papers and other

flammable materials.

oNever block the ventilation openings of the appliance, either on

the inside or its exterior.

oIt is vital to keep your appliance well ventilated,

so that there is proper air flow between the

bottom of the unit and the plinth/kick plate

which it is sitting on.

oDo not place electrical devices inside of the appliance, such as

mixers and electric ice cream makers.

Service

You should not attempt to repair the appliance

yourself, as this could cause injury or a more serious

malfunction. If you require a service call then please

contact the Baumatic Service Department.

Specifications of your refrigerator

Congratulations on purchasing a Baumatic refrigerator

oAutomatic defrost

oAdjustable thermostat

oElectronic control

o2 Egg racks

o2 Butter compartments

oBottle rack

o5 General racks

o4 Safety glass shelves

oSalad crisper

oReversible door

oAdjustable feet

oStainless steel front and sides

Dimensions of appliance*

Height: 1800 mm

Width: 600 mm

Depth: 640 mm

Energy efficiency class

Energy class: A

* Please refer to the installation instructions for more specific

information on the size of aperture that you will require.

IMPORTANT: When you install your appliance it is important to bear

in mind its climatic rating.

oIn order to find out the climatic rating of your appliance, you

should check the rating plate.

oThe rating plate is located on the front left edge of the inside of

the fridge section.

oYou will need to open the door of your appliance to be able to

find it.

oThe rating plate will indicate the ambient temperature range that

your appliance will function correctly within.

Description of the appliance

1. Control panel

2. Fan*

3. Interior light

4. Shelf (adjustable height)

5. Foldable egg rack (closed- 6 eggs, open- 12 eggs).

6. Crisper drawer with pull out guides

7. Door shelves

8. Twin row bottle rack with safety holder*

9. Defrost water outlet

10. Adjustable feet

11. Wheels*

* Certain models only

oPull out guide drawers are extracted by lifting the rear end and

pulling out at an angle under 45 degrees. You need to reinsert

them the opposite way, to put a pull out guide drawer back into

position.

Description of the product features

1) Shelves

oThe shelves may be placed in any of the guide slots within the

interior of the appliance. They are protected from sliding out.

oTo remove a shelf: Take off all of the items that are stored on

the shelf that you want to remove. Then lift the front of the shelf

and carefully pull it out of the grooves.

oCertain models are equipped with a wire bottle rack, this is

protected from being pulled out whilst bottles are stored in it.

oIt can only be removed with no bottles in it, by lifting the front

section and pulling it towards you.

oPlace the bottle rack in the appliance, in such a way that it does

not obstruct the closing of the door.

The maximum load of the rack is 9 bottles of 0.75 litres, or 13

kilograms of total mass.

2) Defrost water outlet

oThe interior of the refrigerator is cooled by the cooling plate that

is on the rear wall. Beneath this there is a channel and an outlet

for the defrost water.

oIt is important that this channel never becomes clogged (see

Defrosting the refrigerator compartment for a detailed

explanation of how to keep the channel clear).

3) Crisper drawers and cover

oThe crisper drawer is in the bottom of your refrigerator and there

is a cover that goes over it.

oThe cover helps to prevent fruit and vegetables from drying out

prematurely.

4) Upper door shelves

oThe door liner holds various shelves, that are suitable for storing

eggs, cheese, butter and yogurt. As well as smaller packages,

tubes, cans etc.

5) Bottle shelf

oThe lower shelf should be used for storing reasonably sized

bottles.

IMPORTANT: NONE OF THE SHELVES THAT SIT IN THE DOOR

SHOULD BE OVERLOADED, AS THIS WILL DRASTICALLY

REDUCE THEIR WORKING LIFE.

6) Fan (certain models only)

oThe fan is located under the ceiling or hidden behind the rear

panel of the refrigerator. This ensures even distribution of

temperature and reduces condensation on the storage racks.

Using your Baumatic refrigerator

Before switching on

oMake sure that it has been installed by a suitably qualified

person, as per the information contained in Baumatic’s

installation instructions.

oAfter delivery, wait for eight hours before connecting the

appliance to your mains supply. This will allow any refrigerant

gasses that may have been disturbed during the transportation

process, are allowed to settle.

oThe outside of the appliance and the removable accessories

contained within it, should be cleaned with a solution of liquid

detergent and water.

oThe interior of the appliance should be cleaned

with a solution of sodium bicarbonate dissolved in

lukewarm water. The interior and accessories

should be thoroughly dried, after the cleaning

process has been completed.

oThere can be an odour when you first switch on the appliance. It

will lessen as the appliance starts to cool.

During first use

oWhen you first switch on the appliance, the compressor will run

continuously for approximately 24 hours or until the refrigerator

reaches a cool enough temperature.

oDuring this period of time, you should try not to open the door

frequently or place a large amount of food within the appliance.

oIf the unit is switched off or unplugged, you must allow at least 5

minutes before restarting the appliance on the thermostat or

connecting it to your mains supply.
