Baumatic B40DSS Manuel utilisateur

即日起更改说明书页码3、5页、35页、36页、37页内容，删除原先

的37页(Baumatic consumables)，内页有标记颜色的都需要仔细注意 2014.4.12 周凤霞

李宇

B40DSS

570 Litre 4 door

frost free fridge-freezer

USER MANUAL FOR YOUR BAUMATIC

B40DSS

570 Litre 4 door

frost free fridge-freezer

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference, for

you or any person not familiar with the operation of the appliance.

JW 11/06/13

Contents

Environmental note 4

Important safety information 5-6

Specifications of your fridge freezer 7-12

Description of the appliance 8

Product features (fridge section) 9-12

Product features (freezer section 12

Using your Baumatic fridge freezer 13-18

Before switching on 13

During first use 13

Control panel 14-18

Switching on the appliance 15

Manually setting the temperature (fridge) 15

Manually setting the temperature (freezer) 15

Switching on Super Cool mode 16

Switching on Super Freeze mode 16

Switching on energy saving mode 16

Turning off the fridge section 17

Switching on the control panel lock 17

Returning the appliance to normal operation 17

Door open alarm 18

Temperature rise alarm 18

Arranging and storing food in the fridge section 18-19

The **** freezer section 20-24

Freezing fresh food 20

Tips on freezing 21

Storing commercially frozen food 21

Defrosting frozen food 22

In the event of power failure 22

Using the twist ice maker 23

Normal operating noises 23-24

Important user information 24

Saving energy when using your fridge-freezer 24-25

Cleaning and maintenance 26-28

General cleaning 26-28

Replacing the light bulb 28

Adjusting the fridge doors 28

Installation 29-33

Electrical connection 29

Positioning 30

Installation preparation 31

Installing the fridge door/freezer drawer handles 31-32

Installing the decorative plinth 33

Troubleshooting 33-35

Techni cal data

Contact details 38

Environmental note

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If you

are unsure of any of the information contained in this

booklet, please contact the Baumatic Advice Line.

IMPORTANT: Any installation work must be carried

out by a qualified electrician or competent person.

Use of the appliance

oYour appliance is only designed to be used in the

home. It is suitable for storing food that needs to

be chilled and refrigerated. If it is used for any

other purpose or it is not used correctly, then

. will accept no liability for any

damage that is caused.

oAltering the specification of the appliance must not be attempted

for reasons of safety.

Before using your appliance

oCheck the appliance for any signs of transport damage. If you

notice any damage, then you should not connect your appliance

to your mains supply and should contact your retailer.

Refrigerant

oYour appliance contains R600a refrigerant, which is a natural gas

that does not contain CFCs that can damage the environment.

However it is a flammable substance, therefore care should be

taken:

During the transportation and installation of the

appliance, make sure that the refrigeration pipe-

work does not get damaged.

If it does become damaged then sources of ignition

and open flames should be avoided. Also the room

that the appliance is situated in should be thoroughly

ventilated.

oDo not place any objects on top of the appliance,

as this may damage the table top.

Baumatic

Child safety

oPackaging material should be kept away from

children.

oChildren should not be allowed to touch the

controls or play with the appliance.

General safety

oDo not pull on the power supply cable to remove the plug from

your mains supply socket.

oDo not pull out or insert the plug with wet hands.

oDo not attempt to use your appliance outdoors or

any place where it is likely to come into contact

with the elements.

oBefore cleaning the appliance or performing maintenance work,

ensure that the appliance has been disconnected from your

mains supply.

oNever allow the back coils of the appliance to come into contact

with the wall surface.

oAlways ensure that the location where you are installing your

appliance is free of stored items such as papers and other

flammable materials.

oNever block the ventilation openings of the appliance, either on

the inside or its exterior.

oIt is vital to keep your appliance well ventilated, so

that there is proper air flow between the bottom of

the unit and the plinth/kick plate which it is sitting

on.

oDo not place electrical devices inside of the appliance, such as

mixers or ice cream makers.

oDo not store aerosol cans with a flammable propellant in this

appliance.

Service

You should not attempt to repair the appliance yourself,

as this could cause injury or a more serious malfunction.

If you require a service call then please contact the

Baumatic Customer Care Department.

Specifications of your fridge freezer

Dimensions of your appliance

oHeight: 1775 mm

oWidth: 911 mm

oDepth: 728.5 mm (excluding handles)

Energy efficiency class

oEnergy class: A+

Cubic capacities

oTotal gross/net capacity: 570/542 litres

oGross capacity (fridge/freezer): 425/145 litres

oNet capacity (fridge/freezer): 422/120 litres

Specifications of the appliance

oFrost free fridge and freezer

oStar rating ****

oMulti airflow cooling system

oElectronic temperature control

oDigital control panel

oAdjustable thermostat

oFast cooling switch

oFast Freeze switch

oFast freeze indicator light

oDoor open warning indicator

oTemperature rise warning indicator

oAdjustable feet

oMark resistant coating

o4 Adjustable fridge safety glass shelves

o1 Salad crisper shelf (Safety glass)

o2 Salad crispers

o1 Full width pantry drawer

o2 Bottle racks

o4 General door racks

o2 Butter and cheese compartments

o2 Egg racks

o1 Wine rack

o2 Non-transparent freezer drawers

oTwist ice maker

IMPORTANT: When you install your appliance it is important to bear

in mind its climatic rating.

In order to find out the climatic rating of your appliance, you should

check the rating plate. The rating plate is located inside of the fridge

section, on the left side. You will need to open the door of the fridge

section and you may need to remove one of the middle safety glass

shelves. The rating plate will indicate the ambient temperature range

that your appliance will function correctly within.

Description of the appliance

1) Pantry drawer

2) Storage compartment

3) Salad crisper (x2)

4) Wine rack

5) Adjustable safety glass shelf

6) Vertical girder

7) Adjustable safety glass shelf

8) Left refrigerator door

9) Top interior light

10) Light switch/door close sensor

11) Right refrigerator door

12) Dairy compartment

13) Rear wall airflow cover plate

14) Adjustable safety glass shelf

15) Interior side light

16) Bottle rack

17) General door rack

18) Freezer interior light

19) Upper freezer drawer

20) Lower freezer drawer

21) Bottom beam/ kick plate

22) Adjustable feet

23) Freezer door handles

Description of product features (fridge)

Adjustable safety glass shelves

oThe shelves may be placed in any of the guide slots within the

interior of the appliance. They are protected from sliding out.

oTo remove a shelf: Take off all of the items that are stored on

the shelf that you want to remove. Then whilst lifting the front of

the shelf, pull it forwards to unhook it from the slots at the rear

of the cabinet.

oTo refit a shelf: When placing a shelf back inside the fridge

compartments, place the hooks into the slots at the rear of the

cabinet. Lower the front of the shelf back down again.

IMPORTANT: You must ensure that both of the hooks are in slots

that are at the same height; otherwise the shelf will not be level.

Salad crispers

oThese drawers are suitable for storing fruits, salad and

vegetables. They are designed to keep the contents fresh for as

long as possible.

oCare should be taken when storing tropical fruit (bananas and

pineapples etc) and tomatoes. As these types of items can easily

deteriorate at a lower temperature.
