Barracuda Networks CudaCam Manuel utilisateur
Bullet IP Camera
Quick Start Guide
CAMCudaCam
Dear Barracuda Networks Customer,
Thank you for choosing the CudaCam Bullet IP Camera. Barracuda Networks
oers a complimentary telephone installation appointment with this
purchase to help you plan your installation, congure your system, and
verify the operation of your CudaCam Bullet IP Camera following installation.
Please contact our Technical Support team to schedule your complimentary
telephone installation appointment.
Of course, this complimentary telephone installation appointment is not
designed to replace the local support you may receive from your Barracuda
Networks reseller. If you prefer, please do not hesitate to contact your
Barracuda Networks reseller, whom we will be happy to coordinate with in
order to provide additional deployment support.
Thank you again for choosing the CudaCam Bullet IP Camera. We encourage
you to contact your reseller or our Technical Support team that is available
around the clock to assist with technical questions or concerns. We look
forward to helping you with your current and future needs in the areas of
security, networking, and data protection.
Sincerely,
BJ Jenkins
CEO
Table of Contents
Setup
1. Create Your CudaCam Account
2. Determine How and Where to Mount Camera
3. Wi-Fi Settings (Wi-Fi Users Only)
4. Install and Connect the Cable
5. Mount the Camera
6. Power the Camera
7. Aim and Focus the Camera
Support
1
1
2
2
2
3
3
4
1
2Determine How and Where to Mount Camera
1Create Your CudaCam Account
Setup
If you are a rst time CudaCam user, create your CudaCam account. In a web
browser, navigate to: http://www.cudacam.com
Click the Camera Login button and then click I am a new user and complete
the web form to create your account. The account you create is the rst user. You
can add more users and cameras after creating this account.
The camera provides several mounting options. It can be mounted on a wall or
ceiling, or it can be mounted in a housing for outdoor use. Each camera includes:
• Selectable foot - scissor mount for suspended ceilings.
• 180 degree adjustable head
• Tripod Socket with Industry standard ¼-20 thread
2
4Install and Connect the Cable
Attach the Power over Ethernet Cable (PoE) to the camera.
Plug the camera into an Internet enabled PoE outlet in a comfortable location.
Congure the Wi-Fi settings with the camera connected to the service via
Ethernet cable. Move the camera to the install site with the Wi-Fi ready to go.
For detailed instructions or complex congurations, please visit our website
or contact Support.
Before physically mounting the camera, test the Wi-Fi signal to verify it
provides a reliable network connection. Signal strength may vary due to
environmental conditions.
3Wi-Fi Settings (Wi-Fi Users Only)
Setup
5Mount the Camera
Using the supplied hardware, mount the camera to provide the desired view.
Be sure to protect the camera from water and extreme temperatures.
3
6
7
Power the Camera
Aim and Focus the Camera
The camera is PoE powered, so it receives its power over the Ethernet cable.
You must use an Ethernet power injector, or a PoE switch to provide power.
The cable runs from the PoE injector OUT port to the camera.
If the LEDs do not light within 30 seconds after inserting the Ethernet cable,
check the power source, cabling and connections.
Mount the camera adjusting the camera angle and direction to the desired eld
of view. Zoom settings adjust from the camera settings page in the CudaCam
web interface from a web browser.
Conrm the eld of view using the CudaCam web interface or on a mobile
device. The zoom level adjusts through the UI and the camera automatically
focuses after conguring the desired zoom.
Setup
4Support
Online Support
• For additional product information, conguration instructions or supporting materials,
visit www.cudacam.com.
Telephone Support
• For urgent matters, please call Technical Support at +1 408.342.5300. Phone lines are
open 24 hours a day, 7 days a week.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Warning: Any changes or modifications not expressly approved by Barracuda Networks, Inc. could void the user’s
authority to operate the equipment.
IC Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and (2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Cet appareil est conforme aux CNR exempts de licence d’Industrie Canada. Son fonctionnement est soumis aux
deux conditions suivantes:
(1) Ce dispositif ne peut causer des interférences; et (2) Cet appareil doit accepter toute interférence, y compris les
interférences qui peuvent causer un mauvais fonctionnement de l’appareil
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de
rayonnement et votre corps.
This radio transmitter, BNHW027 has been approved by Industry Canada to operate with a whip antenna with
maximum permissible gain of 3.2 dBi. Other antenna types or whip antennas having a gain greater than the
maximum gain, are strictly prohibited for use with this device.
Cet émetteur radio, BNHW027 a été approuvé par Industrie Canada pour fonctionner avec une antenne fouet avec
un gain maximal autorisé de 3,2 dBi. Autres types d’antenne ou des antennes de fouet ayant un gain supérieur au
gain maximum, sont strictement interdits pour une utilisation avec cet appareil.
Copyright Information
Copyright 2016 Barracuda Networks, Inc. All rights reserved. Use of this product and this manual is subject to license.
Information in this document is subject to change without notice. CudaCam and Barracuda are trademarks of
Barracuda Networks, Inc. All other brand and product names mentioned in this document are registered trademarks
or trademarks of their respective holders. The Software supplied with this Product is provided under license from
Barracuda Networks, Inc. and other licensors, and certain of the programs included in the Software may be provided
under the GNU General Public License (GPL) or the Lesser General Public License (LGPL). In accordance with the
terms of the GPL and LGPL, you may request a copy of the relevant source code. This oer is valid for up to three
years from the date of original purchase of the Product.
