Bard W24G4 Manuel utilisateur

Page 1 of 54

INSTALLATION INSTRUCTIONS

Bard Manufacturing Company, Inc.

Bryan, Ohio 43506

www.bardhvac.com

Manual No.: 2100-721B

Supersedes: 2100-721A

Date: 5-7-20

WARNING

READ ALL INSTRUCTIONS CAREFULLY BEFORE

BEGINNING THE INSTALLATION.

THE INSTALLATION MUST COMPLY WITH THESE

INSTRUCTIONS AND THE REQUIREMENTS OF

ALL GOVERNING CODES AND ORDINANCES FOR

THE INSTALLATION LOCATION.

IT IS THE RESPONSIBILITY OF INSTALLER

TO KNOW AND UNDERSTAND ALL OF THESE

REQUIREMENTS.

FAILURE TO DO SO COULD CREATE A HAZARD

RESULTING IN PROPERTY DAMAGE, BODILY

INJURY, OR DEATH.

WALL MOUNTED GAS/ELECTRIC

Models:

W24G4

W24G4D

W30G4

W30G4D

W36G4

W36G4D

W42G4

W42G4D

W48G4

W48G4D

W60G4

W60G4D

Manual 2100-721B

Page 2 of 54

CONTENTS

Getting Other Information and Publications ...4

Wall Mount Gas/Electric General Information

..5

W**G Series Model Nomenclature..................... 5

Ventilation Options .......................................... 5

Air Conditioning Module Options....................... 6

1. Transportation Damage................................... 10

2. Important ..................................................... 10

3. General Information....................................... 10

4. Application ................................................... 10

5. Duct Work..................................................... 10

6. High Altitude Applications.............................. 11

7. Wall Mounting Information ............................. 11

8. Mounting the Unit ......................................... 11

9. Clearances.................................................... 18

10. Vent Terminal and Combustion Inlet Hood........ 19

11. Optional Vertical Venting ................................ 19

12. Vent Resizing Instructions .............................. 20

13. Fresh Air Intake............................................. 20

14. Condensate Drain .......................................... 20

15. Wiring – Main Power ...................................... 20

16. Wiring – Low Voltage Wiring............................ 21

17. Thermostats.................................................. 23

18. Gas Supply and Piping................................... 28

19. Manifold Pressure Adjustment ........................ 29

20. Checking Gas Input Rate................................ 29

21. Standard Oriﬁce Sizing and High

Altitude Derate.............................................. 31

22. Conversion of Gas Input BTUH from High

to Low Rating................................................ 34

23. Measuring Air Temperature Rise...................... 34

24. Filters .......................................................... 34

25. Compressor Control Module ............................ 35

26. Phase Monitor............................................... 37

27. Lighting and Shutdown Instructions ................ 37

28. Service Agency Procedures ............................. 38

29. Maintaining Unit in Good Working Order.......... 38

30. Troubleshooting NIDEC SELECTECH Series

ECM Motors .................................................. 39

31. Replacement Parts ........................................ 41

32. Sequence of Operation – Heating .................... 42

33. Sequence of Operation – Cooling..................... 42

34. Setting Unit Airﬂow ....................................... 43

35. Pressure Service Ports ................................... 52

36. R-410A Refrigerant Charge ............................ 53

37. Fan Blade Setting Dimensions ........................ 53

38. Low NOx Burner Assembly "N" Sufﬁx

Models Only – U.S. Installations Only.............. 53

INDEX – Wiring Diagrams ..................................... 54

Page Page

Manual 2100-721B

Page 3 of 54

FIGURES

Figure 1 Unit Dimensions ..................................9

Figure 2A Mounting Instructions – W24-36G ....... 13

Figure 2B Mounting Instructions – W42-60G .......14

Figure 3A Combustible Clearance – W24-36G ..... 15

Figure 3B Combustible Clearance – W42-60G...... 15

Figure 4 Wall Mounting Instructions.................. 16

Figure 5 Wall Mounting Instructions.................. 16

Figure 6 Common Wall Mounting Installations.... 17

Figure 7 Location of Vent Terminal in Shipping .. 18

Figure 8 Vent Terminal and Combustion

Air Inlet Hood .................................... 19

Figure 9 Fresh Air Damper ............................... 20

Figure 10 Installation of Flexible Conduit ............ 21

Figure 11 Low Voltage Wiring – All Units Except

Units with Economizers....................... 24

Figure 12 Low Voltage Wiring – Thermostat Using

Separate Temperature and Humidity

Controllers .........................................25

Figure 13 Low Voltage Wiring –

JIFM Economizer................................ 26

Figure 14 Gas Pipe Connection...........................27

Figure 15 Proper Piping Practice ........................28

Figure 16 Access Internal Filter through

Upper Service Door............................. 35

Figure 17

8201-169 Compressor Control Module ...

Figure 18 Lighting and Shutdown

Instruction Label ................................ 37

Figure 19 Top View of Gas Control ......................38

Figure 20 Motor Connections..............................40

Figure 21 Motor Connections..............................41

Figure 22 Sequence of Operation –

Electronic Blower Control .................... 42

Figure 23 Increasing Heating Speed ...................43

Figure 24 Increasing Cooling Speed ....................44

Figure 25 Speed Taps........................................ 44

Figure 26 Fan Blade..........................................53

Figure 27 Low NOx Insert ..................................53

TABLES

Table 1A Speciﬁcations – W24-36G Models ...........7

Table 1B Speciﬁcations – W42-60G Models ...........8

Table 2 Minimum Installation Clearances........... 18

Table 3 Low Voltage Connections for

DDC Control ........................................ 22

Table 4 CO2Controllers ....................................23

Table 5 Thermostat Wire Size............................ 23

Table 6 Wall Thermostats .................................23

Table 7 Humidity Controls ................................ 23

Table 8 Length of Standard Pipe Threads........... 28

Table 9 Gas Pipe Sizes – Natural Gas ................28

Table 10 Natural Gas Derate Capacities

for All Models ...................................... 31

Table 11A Natural Gas Oriﬁce Tables – W24-36G ... 32

Table 11B Natural Gas Oriﬁce Tables – W42-60G ... 33

Table 12 W24G4 Indoor Blower Performance ....... 45

Table 13 W30G4 Indoor Blower Performance ....... 46

Table 14 W36G4 Indoor Blower Performance ....... 47

Table 15 W42G4 Indoor Blower Performance ......48

Table 16 W48G4 Indoor Blower Performance ....... 49

Table 17 W60G4 Indoor Blower Performance ....... 50

Table 18 Integrated Furnace and Blower

Control Operation ................................. 51

Table 19 Cooling Pressure Table.......................... 52

Table 20 Fan Blade Dimension ...........................53

Page Page

Manual 2100-721B

Page 4 of 54

Getting Other Information and Publications

For more information, contact these publishers:

ACCA Air Conditioning Contractors of America

1712 New Hampshire Avenue, NW

Washington, DC 20009

Telephone: (202) 483-9370

ANSI American National Standards Institute

11 West Street, 13th Floor

New York, NY 10036

Telephone: (212) 642-4900

Fax: (212) 302-1286

ASHRAE American Society of Heating Refrigerating,

and Air Conditioning Engineers, Inc.

1791 Tullie Circle, NE.

Atlanta, GA 30329-2305

Telephone: (404) 636-8400

Fax: (404) 321-5478

NFPA National Fire Protection Association

Batterymarch Park

P.O. Box 9101

Quincy, MA 02269-9901

Telephone: (800) 344-3555

Fax: (617) 984-7057

CSA Canadian Standards Association

178 Rexdale Boulevard

Rexdale, Ontario

Canada. M9W 1R3

Telephone: (416) 447-4044

BARD MANUFACTURING COMPANY, INC.

BRYAN, OHIO 43506 USA

These publications can help when installing the

furnace. They can usually be found at the local library

or purchased directly from the publisher. Be sure to

consult the current edition of each standard.

National Fuel Gas Code ....ANSI Z223.1 / NFPA 54

National Electrical Code .............. ANSI / NFPA 70

Standard for the Installation ..... ANSI / NFPA 90A

of Air Conditioning and Ventilating Systems

Standard for Warm Air .............. ANSI / NFPA 90B

Heating and Air Conditioning Systems

Standard for Chimneys, .......................NFPA 211

Fireplaces, Vents, and Solid Fuel Burning

Appliances

Load Calculation for .....................ACCA Manual J

Residential Winter and Summer Air Conditioning

Duct Design for Residential ........ ACCA Manual D

Winter and Winter Air Conditioning and Equipment

Selection

Canadian Electrical Code.....................CSA C22.1

Canadian Installation Code

…………

CAN/CGA B149

Manual 2100-721B

Page 5 of 54

W 42 G 4 – A X C X X X X X X

WALL MOUNT GAS/ELECTRIC GENERAL INFORMATION

MODEL NUMBER NOMENCLATURE

Low ambient control is required with economizer for low temperature compressor operation.

Ventilation Options

Models

W24G, W30G, W36G W42G, W48G, W60G

Description Factory Installed

Code No.

Field Installed

Part No.

Field Installed

Part No.

Barometric Fresh Air Damper X WGBFAD-3 WGBFAD-5

Blank-Off Plate B WGBOP-3 WGBOP-5

Motorized Fresh Air Damper M WGMFAD-3A WGMFAD-5A

Commercial Ventilator – Spring Return V WGCRVS-3A WGCRVS-5A

Commercial Ventilator – Power Return P WGCRVP-3A WGCRVP-5A

Economizer - Fully Modulating E WGJIFM-3 WGJIFM-5

Energy Recovery Ventilator – 230 Volt R WGERV-A3B WGERV-A5B

Energy Recovery Ventilator – 460 Volt R WGERV-C3C WGERV-C5C

1Reference Supplemental Instructions 7960-867 for dehumidiﬁcation unit information.

MODEL

Wall Mount CONTROL OPTIONS

(See table page 6)

VENT

(See table

below)

COOLING

CAPACITY

24 –2 ton

30 –2½ton

36 –3 ton

42 –3½ton

48 –4 ton

60 –5 ton OUTLET

X –Front Outlet

T –Top Outlet

COIL OPTIONS

X –Standard

1 –Phenolic coated evaporator

2 –Phenolic coated condenser

3 –Phenolic coated both coils

COLOR

X –Beige

1 –White

4 –Gray

8 –Bronze

FILTER

X –2" Pleated (Standard)

W –1" Washable

VOLTAGE

A–230/208-60-1

B–230/208-60-3

C–460-60-3

REVISION

FEATURE

C –Canadian Approval

D –Dehumidiﬁcation1

EMISSIONS

X = Standard

N = NOx Certiﬁed

*125,000 BTU input model is not NOx certiﬁed.

HEATING INPUT

2 - 3 Ton 3.5 - 5 Ton

A –45,000 B –75,000

B –67,500 C –100,000

C –90,000 D –125,000*

GAS/ELECTRIC

Manual 2100-721B

Page 6 of 54

Air Conditioning Module Options

STD – Standard equipment.



CCM Compressor control module has adjustable 30 second to 5 minute delay-on-break timer. On initial power up, or any

time the power is interrupted, the delay-on-make will be 2 minutes plus 10% of the delay-on-break setting. There is no

delay-on-make during routine operation of the unit. The module also provides the lockout feature (with 1 retry) for high

and/or low pressure controls, and a 2-minute timed bypass for low pressure control.



HPC High pressure control is auto reset. Always used with compressor control module (CCM) which is included. See Note

.



LPC Low pressure control is auto reset. Always used with compressor control module (CCM) which is included. See Note

.



LAC Low ambient control permits cooling operation down to 0°F. (Includes fan cycling control + Freeze Stat)



SK CMC-15 is PTCR Start Kit can be used with all -A single phase models. Increases starting torque 2-3X. Not used for -B

or -C 3-phase models. Do not use if SK111 is used.



SK SK111 Start Capacitor and Potential Relay Start Kit can be used with all -A single phase models. Increases starting

torque 9x. Not used for -B or -C 3-phase models. Do not use if CMC-15 is used.

CCM



HPC



LPC



LAC





Factory Installed

Code

Field Installed

Part

STD STD STD • H CMA-45 (WG4D Units)

CMA-46 (WG4 Units)

• Field Only SK111 or CMC-15

Manual 2100-721B

Page 7 of 54

ABLE 1A

Speciﬁcations

W24G4, W30G4 and W36G4 Models

*75° C Copper wire size

** Maximum time delay fuse or circuit breaker

Models W24G4-A W24G4-B W24G4-C W30G4-A W30G4-B W30G4-C W36G4-A W36G4-B W36G4-C

Electrical Rating – 60 Hz 230/208-1 230/208-3 460-3 230/208-1 230/208-3 460-3 230/208-1 230/208-3 460-3

Operating Voltage Range 197-253 187-253 414-506 197-253 187-253 414-506 197-253 187-253 414-506

Minimum Circuit Ampacity 20.6 12.6 8 22.6 16.1 8.6 26.4 19 10.6

* Field Wire Size 10 14 14 10 12 14 8 10 14

Ground Wire Size 10 14 14 10 12 14 10 10 14

** Delay Fuse or Circuit Breaker Max. 30 15 10 30 20 10 35 25 15

Compressor

Voltage 230/208 230/208 460 230/208 230/208 460 230/208 230/208 460

Rated Load Amps 7.6/8.7 4.6/5.3 2.5 9.4/10.7 6/6.9 3.2 12/13.5 7.8/8.7 4.8

Branch Circuit Selection Current 12.9 6.5 3.6 14.2 9 4.2 16.7 10.5 5.8

Lock Rotor Amps 58.3 55.4 28 73 58 28 79 73 38

Compressor Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll

Fan Motor and Condenser

Fan Motor – HP/RPM/SPD 1/5-1100-1 1/5-1100-1 1/5-1100-1 1/5-1100-1 1/5-1100-1 1/5-1100-1 1/5-1100-1 1/5-1100-1 1/5-1100-1

Fan Motor – Amps 1.4 1.4 0.8 1.4 1.4 0.8 1.4 1.4 0.8

Fan – DIA/CFM 20” - 2100 20” - 2100 20” - 2100 20” - 2100 20” - 2100 20” - 2100 20” - 2000 20” - 2000 20” - 2000

Blower Motor and Evaporator

Blower Motor – HP/RPM/SPD 1/2-670-5 1/2-670-5 1/2-670-5 1/2-750-5 1/2-750-5 1/2-750-5 1/2-870-5 1/2-870-5 1/2-870-5

Blower Motor – Amps 0.9 0.9 1.2 1.2 1.2 1.2 1.9 1.9 1.2

CFM Cooling and E.S.P. 800 - 0.15 800 - 0.15 800 - 0.15 900 - 0.15 900 - 0.15 900 - 0.15 1100 -

0.15

1100 -

0.15

1100 -

0.15

Filter Size 20 x 25 x 2 20 x 25 x 2 20 x 25 x 2 20 x 25 x 2 20 x 25 x 2 20 x 25 x 2 20 x 25 x 2 20 x 25 x 2 20 x 25 x 2

Shipping Weight – LBS. 500 500 500 530 530 530 540 540 540

Unit Charge (R-410A lb.) 5.750 5.750 5.750 5.750 5.750 5.750 6.625 6.625 6.625

Manual 2100-721B

Page 8 of 54

*75° C Copper wire size

** Maximum time delay fuse or circuit breaker

TABLE 1B

Speciﬁcations

W42G, W48G and W60G Models

Models W42G4-A W42G4-B W42G4-C W48G4-A W48G4-B W48G4-C W60G4-A W60G4-B W60G4-C

Electrical Rating – 60 Hz 230/208-1 230/208-3 460-3 230/208-1 230/208-3 460-3 230/208-1 230/208-3 460-3

Operating Voltage Range 197-253 187-253 414-506 197-253 187-253 414-506 197-253 187-253 414-506

Minimum Circuit Ampacity 29 23.4 11.5 34.4 24.4 12 40.2 29.7 13.6

* Field Wire Size 8 10 14 8 10 14 8 8 12

Ground Wire Size 10 10 14 10 10 14 10 10 12

** Delay Fuse or Circuit Breaker Max. 40 30 15 50 30 15 50 40 20

Compressor

Voltage 230/208 230/208 460 230/208 230/208 460 230/208 230/208 460

Rated Load Amps 15.5/17.4 11.7/13.2 5.9 16.7/19.5 10.6/12.3 6.5 19.5/21.9 12.9/14.4 7

Branch Circuit Selection Current 18 13.6 6 21.8 13.8 6.5 24.4 16 7.8

Lock Rotor Amps 112 88 44 117 83.1 41 144.2 110 52

Compressor Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll

Fan Motor and Condenser

Fan Motor – HP/RPM/SPD 1/3-850-1 1/3-850-1 1/3-850-1 1/3-830-1 1/3-830-1 1/3-830-1 1/2-1000-1 1/2-1000-1 1/2-1000-1

Fan Motor – Amps 1.8 1.8 1 1.8 1.8 1 3.8 3.8 2.5

Fan – DIA/CFM 24” - 2900 24” - 2900 24” - 2900 24” - 2700 24” - 2700 24” - 2700 24” - 3400 24” - 3400 24” - 3400

Blower Motor and Evaporator

Blower Motor – HP/RPM/SPD 3/4-850-5 3/4-850-5 3/4-850-5 3/4-940-5 3/4-940-5 3/4-940-5 3/4-1040-5 3/4-1040-5 3/4-1040-5

Blower Motor – Amps 2.4 2.4 1.7 3.1 3.1 1.7 3.7 3.7 1.7

CFM Cooling and E.S.P. 1300 -

0.15

1300 -

0.15

1300 -

0.15

1450 -

0.20

1450 -

0.20

1450 -

0.20

1650 -

0.20

1650 -

0.20

1650 -

0.20

Filter Size 20 x 30 x 2 20 x 30 x 2 20 x 30 x 2 20 x 30 x 2 20 x 30 x 2 20 x 30 x 2 20 x 30 x 2 20 x 30 x 2 20 x 30 x 2

Shipping Weight – LBS. 500 500 500 530 530 530 550 550 550

Unit Charge (R-410A lb.) 6.500 6.500 6.500 7.125 7.125 7.125 9.625 9.625 9.625

Manual 2100-721B

Page 9 of 54

DDD FF

EE O

COMBUSTION

AIR INTAKE

CONTROL

RIGHT SIDE

ENTRANCES

GAS

RETURN OPENING

4 DEG. PITCH IN TOP

PANEL DOOR

DOOR

LOW VOLTAGE

SUPPLYOPENING

PANEL

BACK

DISCONNECT ACCESS

VESTIBULE

PANEL (LOCKABLE)

CONDENSER

AIR INLETS

CONDENSER VENT OPTION

AIR OUTLET

AIR EXHAUST

COMBUSTION ENTRANCES

FRONT

CIRCUIT BREAKER/

MIS-3239

HIGH VOLTAGE

ENTRANCES

FRONT DOOR

FILTER

SERVICE

DOOR

UNIT A B C D E F G H I J K L M N O P QR

W24G-W30G-W36G 7.88 27.88 13.88 24.25 40 25.63 81.63 27.38 27.5 39.25 5.88

W42G-W48G-W60G

9.88

29.88

15.88

27.25

43.81

31.63

87.5

33.38

28.75

42.88

3.75

UNIT S T U V W X Y Z AA BB CC DD EE FF GG HH II

W24G-W30G-W36G12 - 7 HOLES 2.88 22.9 38 17.84 4.44 11.44 9 36.25 2 0.38

W42G-W48G-W60G

16 - 6 HOLES

3.88

24.9

17.34

8.44

12.19

40.25

2.75

0.44

1.257.25 1.133.75 2.25 3.25

15.31 4.5 2.514.88 30 14.12 15.44

FIGURE 1

Unit Dimensions

Manual 2100-721B

Page 10 of 54

1. TRANSPORTATION DAMAGE

All units are packed securely in shipping containers.

All units should be carefully inspected upon arrival for

damage. In the event of damage, the consignee should:

Note on delivery receipt of any damage to container.

2. Notify carrier promptly, and request an inspection.

3. In case of concealed damage, the carrier must be

notiﬁed as soon as possible within 15 days after

delivery.

4. Claims for any damage, apparent or concealed,

should be ﬁled with the carrier, using the following

supporting documents:

A. Original Bill of Lading, certiﬁed copy or

indemnity bond.

B. Original paid freight bill of indemnity in lieu

thereof.

Original invoice or certiﬁed copy thereof showing

trade and other discounts or deductions.

D. Copy of the inspection report issued by

carrier’s representative at the time damage is

reported to carrier.

2. IMPORTANT

The equipment covered in this manual is to be installed

by trained, experienced service and installation

technicians. All duct work or portions thereof not in the

conditioned space should be properly insulated in order

to both conserve energy and prevent condensation or

moisture damage.

3. GENERAL INFORMATION

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person

responsible for their safety.

Children should be supervised to ensure that they do

not play with the appliance.

These instructions explain the recommended method

to install the air cooled self-contained electric air

conditioning and gas heating unit and the electrical

wiring connections and gas piping to the unit. The

refrigerant system is completely assembled and

charged. All internal wiring is complete.

These instructions and any instructions packaged with any

separate equipment required to make up the entire heating/

cooling system should be carefully read before beginning

the installation.

While these instructions are intended as a general

recommended guide, they do not supersede any

national and/or local codes in any way. Authorities

having jurisdiction should be consulted before the

installation is made. See page 4 for information on

codes and standards.

Size of unit for proposed installation should be based

on heat loss/heat gain calculations made according to

methods of Air Conditioning Contractors of America

(ACCA). The air duct should be installed in accordance

with the Standards of the National Fire Protection

Association for the Installation of Air Conditioning and

Ventilating Systems of Other Than Residence Type,

NFPA No. 90A, and Residence Type Warm Air Heating

and Air Conditioning Systems, NFPA No. 90B. Where

local regulations are at a variance with instructions,

installer should adhere to local codes.

4. APPLICATION

This is a fan-assisted forced air gas furnace with electric

air conditioning for outdoor installation. A fan-assisted

furnace is equipped with an integral mechanical means

to draw products of combustion through the combustion

chamber and heat exchanger. The furnace installation

must conform with local building codes and ordinances

or, in their absence, with the National Fuel Gas Code

ANSI Z223.1 or CAN/CGA-B149.1, latest edition,

and the National Electrical Code ANSI/NFPA-7 or CSA

C22.1, latest edition. It is the personal responsibility

and obligation of the purchaser to contact a qualiﬁed

installer to assure that installation is adequate and is in

conformance with governing codes and ordinances.

5. DUCT WORK

The unit is designed for use with or without duct work

(see WARNING). Flanges are provided for attaching

CAUTION

During the initial ring of the burners there will probably be some amount of smoke issued to the

circulating air stream as the result of residual oil burning off of the heat exchanger tubes. This oil

is required during the forming process of the stainless steel heat exchanger tubes to facilitate the

bending. OSHA or the National Toxicology Program does not list the oil as a carcinogen. In vapor

form this may be irritating to the eyes or could cause headaches. This is a one-time occurrence, and

ventilation of the space may be required depending upon the space being conditioned.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Bard Système de chauffage

Bard

Bard EHP513-A05 Manuel utilisateur

Manuels Système de chauffage populaires d'autres marques

aerauliqa

aerauliqa QR350ABP Manuel utilisateur

WatchGas

WatchGas ATEX BEACON Manuel utilisateur

Viessmann

Viessmann Vitoligno 300-H Mode d'emploi

Lampoassa

Lampoassa 203GT Manuel utilisateur

MSA

MSA SOA-1022 Manuel utilisateur

nilan

nilan Compact P Manuel utilisateur

ITR

ITR OASIS NE-S Manuel utilisateur

Carrier

Carrier 48LJD Dimensions et guide d'installation

aldes

aldes EVEREST XV Manuel utilisateur

Kober

Kober C22SPV23MEF Manuel utilisateur

Oxygen

Oxygen X-Air V400 Manuel utilisateur

Carrier

Carrier FB4CNF Manuel utilisateur

Kroll

Kroll HM200 Manuel

Kroll

Kroll HM200 Manuel

NuAire

NuAire XBOXER XBC Series Manuel utilisateur

Trane

Trane VR104GD-U Series Manuel utilisateur

Vents

Vents VUT V mini Manuel utilisateur

Viessmann

Viessmann Divicon Manuel utilisateur
