Barco Galaxy NH-12 Manuel utilisateur

www.barco.com

The Galaxy NH-12 is an ideal solution for medium- to large-sized bright environments

where 1080p HD stereoscopic quality matters, such as large design rooms, team

collaboration rooms, geophysical analysis rooms, or a university research centers.

•Multiple stereoscopic capabilities (active, circular, passive and active Infitec) and

geometry correction for both flat and curved screens

•Direct access to all connected and networked sources on a single, large-screen

desktop

•Multiple source windows that can be moved or resized easily with keyboard and

mouse, in a Windows interface

•Adaptive framerate conversion

•12,000 lumens light output at a 2000:1 contrast ratio

•Maintenance-free design thanks to dustproof, fully sealed and liquid cooled optical

engine

•Excellent brightness uniformity

•Special, noise-reducing design

Galaxy

NH-12

Stereoscopic, network-centric, 1080p HD, three-chip DLPTM projector

Galaxy NH-12 specsheet June07.qxd:CLM R10+ 7/12/07 11:28 AM Page 1

www.barco.com

R5990055 July 2007

DLP™ technology by Texas Instruments offers crystal

clear images with superior quality.

DLP is a trademark of Texas Instruments.

The information and data given are typical for the equipment described.

However any individual item is subject to change without any notice.

The latest version of this product sheet can be found on www.barco.com.

Galaxy NH-12 technical specifications

EMEA & ROW

Noordlaan 5

8520 Kuurne - Belgium

Tel. +32 56 36 82 11

Fax +32 56 36 85 26

Barco

Presentation & Simulation Division

contact.bps@barco.com

USA

600 Bellbrook Avenue

Xenia, OH 45385-4053

Tel. +1 (937) 372-7579

Fax +1 (937) 372-8645

APAC

7F, FenYang Road 138

200 031 Shanghai - China

Tel. +86 21 5465 5501

Fax +86 21 5465 5502

Display capabilities

Light output

12,000 center lumens (+/- 10%)

Contrast

1,800:1 up to 2,000:1 (with TLD+1.2:1 lens in High Contrast Mode)

Resolution

Full HD (1,920 x 1,080)

Chip technology

Sealed and liquid cooled 3-chip DLPTM

Lamps

Lamp

2 kW Xenon

Lamp warranty

750 hrs waranted, max. 800 hrs

Dimensions

Weight

70 kg (154.2 lbs) net - 85 kg (187.4 lbs) shipping weight

Height - width - length

345 / 590 / 913 mm

13.58

” /

23.22

” /

35.94

”

Lenses

Available zoom lenses

TLD HB (1.6-2.0:1) R9842060

TLD HB (2.0-2.8:1) R9842080

TLD HB (2.8-5.0:1) R9842100

TLD HB (5.0-8.0:1) R9842120

Available fixed focal lenses

TLD HB (0.8:1) R9842040

TLD+ (1.2:1) R9840775

Lens shift range

Horizontal shift up to +/- 65%

Vertical shift up to +/- 100%

Features

Special features

Multiple stereo capabilities (Active, Passive Infitec, Active

Infitec, Polarized)

Source and PiP operation through Windows OS

Standard full geometry correction

Sealed, liquid-cooled engine

Desktop output including external source windows on DVI-

Inputs and outputs

Standard inputs

1x 5-BNC (RGBHV, RGBS or RGBsB)

1x Composite video (BNC)

1x S-Video (4-pin mini DIN)

1x DVI

1x VGA (D15)

3 stereo sync inputs (mini-DIN)

Optional inputs (1 free layer)

SDI/HD-SDI input

Communication ports

RS232 (on D9)

10/100 Mb/s Ethernet (on RJ45)

Compatibility

Video

PAL, SECAM, NTSC video signals in Composite, S-video,

component or RGB format

All current HDTV standards (720i, 720p, 1080i, 1080p) in

Component or RGB format

Data

All computer graphics formats up to UXGA @ 120 Hz

Analog sources with a pixel clock of up to 270 MHz

DVI sources with a pixel clock of up to 165 MHz

Safety

Safety standards

ETL60950 and EN60950

CE compliant

CCC compliant

Power

AC power

100 - 240 VAC/50-60 Hz

Max. power consumption / dissipation

2,800 Watt / 9,560 BTU

Order info

Galaxy NH-12 R9040400

New 2kW lamp R9843080

Refurbished lamp R9843090

QXGA RGBHV input R9843020

DVI/D15 input R9843030

SDI/HD-SDI R9843040

Galaxy NH-12 specsheet June07.qxd:CLM R10+ 7/12/07 11:28 AM Page 2
