Barco MFCD 3220 D Mode d’emploi

Installation & User Manual

B410512 / 00

July 2004 MFCD 3220 D

 Read the safety and

operating instructions before

operating the apparatus.

 Retain safety and operating

instructions for future

reference.

 Adhere to all warnings on

the apparatus and in the

operating instructions

manual.

 Follow all instructions for

operation and use.

This apparatus conforms to:

CE, IEC 60950, UL 60950, CAN/

CSA C22.2 No. 60950 (cUL)

Power connection

 Warning: This apparatus

must be earthed!

 Power requirements: The

apparatus must be powered

using the 2 VDC power

supply that is supplied with

the apparatus.

The 2 VDC power supply

must be powered by the AC

mains voltage.

 Do not overload wall outlets

and extension cords as this

may result in fire or electric

shock.

 Mains lead protection:

Supply cords should be

routed so that they are not

likely to be walked upon or

pinched by items placed

upon or against them, paying

particular attention to cords

at plugs and receptacles.

SAFETY INSTRUCTIONS

Water and moisture

 Never expose the

apparatus to rain or

moisture.

 Never use the apparatus

near water - e.g. near a

bathtub, washbasin,

swimming pool, kitchen

sink, laundry tub or in a wet

basement.

Ventilation

 Do not cover or block the

ventilation openings in the

cover of the set. When

installing the apparatus in a

cupboard or another closed

location, heed the

necessary space between

the set and the sides of the

cupboard.

Installation

 Place the apparatus on a

flat, solid and stable surface

that can bear the weight of

at least 3 displays. If you

use an unstable cart or

stand, the set may fall,

causing serious injury to a

child or adult, and

seriousdamage to the

equipment.

MFCD 3220D User's Guide 4

MFCD 3220D User's Guide 5

CONTENTS

1. Overview ......................................................................................................... 7

1.1 Introduction .............................................................................................. 7

I-Gu rd ....................................................................................................... 7

1.2 P ck ge contents .................................................................................... 8

1.3 Controls nd connectors ......................................................................... 8

2. Inst ll tion .................................................................................................... 10

2.1 Prec utions ............................................................................................ 10

2.2. Before inst lling the displ y ................................................................. 10

2.3 Portr it or l ndsc pe position ............................................................... 11

2.4 Connecting the sign ls ......................................................................... 12

To connect the power: ............................................................................. 12

To connect the video & sync sign ls: ...................................................... 12

2.5.Routing the sign l c bles ...................................................................... 13

2.7 St rting up .............................................................................................. 14

2.6 Tilt nd swivel positioning ..................................................................... 14

3. Controls ........................................................................................................ 15

3.1 St nd-by switching ................................................................................. 15

3.2 Brightness control .................................................................................. 15

4. M inten nce ................................................................................................. 16

P nel ............................................................................................................ 16

C binet ......................................................................................................... 16

Removing dust from the re r of the gl ss p nel ........................................ 16

6. Technic l specific tions ............................................................................... 17

MFCD 3220D User's Guide 6

MFCD 3220D User's Guide 7

1. OVERVIEW

1.1 Introduction

The MFCD 3220D, BARCOs 21 3 meg pixel

color LCD displ y, gu r ntees perfect im ge

qu lity in medic l im ging pplic tions.

The displ y combines TFT (thin film tr nsistor)

liquid cryst l displ y p nel structure nd built-in

b cklight with inverter for better picture qu lity. It

is designed to meet the users' needs for

perform nce, consistency, nd outst nding im ge

qu lity through stre mlined development

process.

The displ y c n be used in portr it or l ndsc pe

version, simply by turning the p nel. The tilt &

swivel foot llows ide l positioning of the p nel, in

height nd viewing ngle.

The im ge brightness c n be djusted by me ns

of control wheel on the displ y. Other im ge

p r meters c n be djusted by me ns of extern l

softw re, like MediC l® Pro.

I-Guard I-GUARD® is B rcos p tent-pending, built-in

c libr tion device, continuously m int ining im ge

qu lity. With I-GUARD®, QA checks no longer

need to disturb norm l r diology ctivities, s they

c n be performed while pplic tions re running.

I-GUARD® llows r diologists or QA

dministr tors to c libr te their viewing st tions or

djust the p nels curve to DICOM st nd rds

without dministr tor intervention.

MediCal Pro In combin tion with B rcos MediC l ® Pro

m n gement nd c libr tion softw re p ck ge,

Coronis offers truly intervention-free displ y

system, m king it possible to perform QA checks

from one centr l server t ny time, thereby

reducing lifecycle cost.

Multi-scan capabilities The optimum nd recommended resolution is

2048 x 1536 or 1536 x 2048 at 60 Hz.

The MFCD 3220D displ y will lso displ y most

of the computer boot modes.

BARCO's B rcoMed 5MP2FH im ging bo rd is

the best choice to drive the MFCD 3220D displ y.

MFCD 3220D User's Guide 8

1.2 Package contents

The p ck ge should include the following items,

ple se check. If some of the items re missing,

ple se cont ct the reseller you h ve purch sed

the unit from.

- The MFCD 3220D displ y

- 12V DC power supply

- Europe n power cord

- Du l-link DVI video c ble

- This user m nu l

1.3 Controls and connectors

(4) (5) (6)

(1)

(2)

(3)

MFCD 3220D User's Guide 9

(1) Power LED

- The LED is off when the displ y is off.

- The LED is green when the displ y is on.

Note: This function c n be switched off by

softw re.

- The LED is blinking green when the

displ y is in Suspend power-s ving mode.

- The LED is or nge when the displ y is in

St nd-by power-s ving mode.

(2) Control wheel for st nd-by switching nd

lumin nce control

(3) USB-downstre m connector

(4) USB-upstre m connector

(5) DVI (video nd d t ) input

(6) 12V DC power input

MFCD 3220D User's Guide 10

 Keep your origin l p ck ging. It is

designed for this displ y nd is the ide l

protection during tr nsport.

 Avoid reflections in the fl t p nel to reduce

eye str in.

 Pl ce the displ y on strong nd st ble

t ble or desk.

 Keep the displ y w y from he t sources

nd provide enough ventil tion in c se it is

built in r ck or console.

 M ke sure the computer is switched off

before connecting the sign ls.

 Do not turn the power supply upside down

or t its side. Doing so would c use

overhe ting of the power supply.

Also do not block free ir circul tion round

the power supply.

2.2. Before installing the display

Important:

In the f ctory, the height-positioning system in

the displ y foot is blocked with clip to prevent

d m ge during tr nsport tion.

Before inst lling the displ y, you must remove

this clip.

To remove the clip:

1 Position the displ y with its re r side f cing

you.

2 If the foot cover is mounted on the foot, lift

up the 2 clips of the foot cover to rele se the

cover from the foot.

3 Pull the lower side of the cover tow rds you

nd simult neously slide the cover

downw rd.

2. INSTALLATION

2.1 Precautions

MFCD 3220D User's Guide 11

4 Pull the red clip out of the fix tion holes in

the foot.

You c n better le ve the cover off the foot while

connecting the sign l c bles to the displ y.

2.3 Portrait or landscape position

You c n ch nge the orient tion of the p nel t

ny time, but it is more convenient to select

l ndsc pe or portr it orient tion before

connecting the c bles.

To ch nge the p nel orient tion:

1 St nd t the front side of the p nel nd t ke

the p nel t both sides.

2Very important: Tilt the p nel before

ch nging the orient tion.

Should you ch nge the p nel orient tion

without tilting it first, you might irreversibly

d m ge the tilt & swivel mech nism.

3 To ch nge from portr it to l ndsc pe, turn

the p nel co nterclockwise while lifting it

up slightly.

To ch nge from l ndsc pe to portr it, turn

clockwise.
