MDRC2124TS

24inch clinical review display with touch screen interface

The MDRC2124 TS is a 24” widescreen

clinicalreviewdisplaywithanintuitivetouch

screen interface. The 24inch multipurpose

displaybringsreliable,DICOMcompliantand

remotely managed images to a broad

palette of imaging applications, including

modality control systems and electronic

patientsystems.

Highimagequality

The highquality LCD panel presents medical images with better contrast,

higher brightness and a wider viewing angle than conventional computer

monitors.

Advanced Backlight Output Stabilization (BLOS) technology ensures fast

powerup and stable luminance over time, resulting in longterm image

consistency.

ThankstotheintegratedDICOMPart14LookUpTable,theMDRC2124TSis

DICOMcompliant“outofthebox”.

Fitforpurpose

Barco’s range of MDRC displays has been designed for use in clinical

environments. The displays comply with international medical (IEC 60601)

standardsforoptimumpatientsafety.

MDRC2124TS

24inch clinical review display with touch screen interface

Remotemanagement

All MDRC displays come standard with Barco’s industryleading MediCal

QAWebsoftware.ThisonlineserviceforautomatedcalibrationandQuality

Assuranceensuresaccurateandreliableimagesanywhere,anytime.Italso

allowsremoteQAadministration and asset management viatheInternetto

guaranteemaximumuptimeofyourmedicaldisplay.



Productspecifications MDRC2124TS

Screentechnology TFTColorLCDIPS

Activescreensize(diagonal) 612mm(24.1")

Activescreensize(HxV) 518x324mm(24.1x12.8")

Aspectratio(H:V) 16:10

Resolution 2MP(1920x1200)

Pixelpitch 0.2700mm

Colorimaging Yes

Grayimaging No

Colorsupport 16.8million

Viewingangle(H,V) 178°

UniformLuminanceTechnology(ULT) No

PerPixelUniformity(PPU) No

AmbientLightCompensation(ALC) No

BacklightOutputStabilization(BLOS) Yes

IGuard No

Maximumluminance 400cd/m²

DICOMcalibratedluminance 250cd/m²

Contrastratio 1000:1

Responsetime(Tr+Tf) 24ms

Scanningfrequency(H;V) 31.579.95kHz;5961Hz

Housingcolor Black

Videoinputsignals DVIISingleLink

DisplayPort

Videoinoutterminals SeparateH&Vsync

CompositesynconH

SynconGreensupported

USBports 1upstream,2downstream

USBstandard 2.0

Powerrequirements(nominal) 100250V

Powerconsumption(nominal) 65W

Powersavemode Yes

Powermanagement DVIDMPMstatessupported

PowerOnstate

ActiveOffstate

DPMSstatessupported

Dotclock 165MHz

OSDlanguages English,French,German,Spanish,Italian,Dutch,SimplifiedChinese,Taditional

Chinese,Japanese,Korean

Dimensionswithstand(WxHxD) Landscape:579x515~615x231mm

Dimensionsw/ostand(WxHxD) Portrait:382x579x106mm

Landscape:579x382x106mm

Dimensionspackaged(WxHxD) 872x482x352mm

Netweightwithstand 15.4kg

Netweightw/ostand 10.0kg

Netweightpackagedwithstand 19.4kg

Netweightpackagedw/ostand 14.0kg

Heightadjustmentrange 100mm

Tilt 5°/+40°

Swivel 45°/+45°

Productspecifications MDRC2124TS

Pivot 90°

Mountingstandard VESA(100mm)

Recommendedmodalities CT,MR,US,DR,CR,NM,Film

Certifications EN6060112(2001),EN55011(ClassB),IEC6100032,IEC6100033,IEC

6100042,IEC6100043,IEC6100044,IEC6100045,IEC61000411,IEC

6100046,IEC6100048,CE,EN606011MedicalPart1,FCCB,cul,PSE,BSMII,VCCI

,CCC,KCC,CSAc22.2No601.1,UL505011

Suppliedaccessories Usermanual

Videocables(DVISingleLink,Analog)

Maincables(UK,European(CEBEC/KEMA),USA(UL/CSA;adaptorplugNEMA

515P),Chinese(CCC))

Externalpowersupply

Optionalaccessories BarcoExternalMedicalLCDDisplaySensor

BarcoMDRC2124ClinicalReviewMedicalLCDDisplayProtectiveFrontCoverKit

QAsoftware MediCalQAWeb

Unitsperpallet 16

Palletdimensions(WxH) 800x1200mm

Warranty 3years

Generatedon:26Feb2014

Technicalspecificationsaresubjecttochangewithoutpriornotice.

Pleasecheckwww.barco.comforthelatestinformation.
