Barco LDX46 Manuel utilisateur

LDX46

46" full HD LED backlit LCD display

Barco's LDX46display with LED backlights has been designed for use in a

wide variety of professional applications. The LDX46 produces crisp, bright

andcoloraccurateimagesona46”screensize.

Featuring LED backlit LCD technology, theLDX46 boasts a high brightness

anddurableLEDbacklighttechnologyandprovidesanexceptionallythinand

spacesaving design. Available in native full high definition (1920 x 1080

pixels),theLDX46isahighqualitydisplayforlongtermusage.

Barco'sLDX46combinesthetypicalbenefitsofliquidcrystaltechnology(such

as low maintenance costs) with energyefficient LED backlights, reducing

imageburninandcolorations.

Wideviewingangle

The wide viewing angle (178°) and large surface are very beneficial in

collaborativeenvironmentswheredetailedinformationisviewedbymultiple

participants.

LDX46

46" full HD LED backlit LCD display

Spacesavingdesign

The LDX46 is based on Edge LED technology, meaning that the LEDs are

positioned around the outer rim of the screen.This technology provides the

LDX46 with an exceptionally thin and spacesaving design. The display has

beendesignedforeasyinstallationofhighqualitystandaloneapplicationsor

asacomplementaryvisualizationsolutioninmoderncontrolrooms.

Highresolution

Barco'shighresolutionLDX46showslargeamountsofdatainaccurateand

highquality images. Any input source can be shown pixelonpixel, which

avoidsunnecessaryscalingartifactsoftenfoundonlowerresolutiondisplays.

Combined with the displays' nonglossy professional LCD panel and

AntiImage Retention functionality, the LDX46 delivers bright and crisp

imagesthatdofulljusticetohighresolutiongraphicsandvideo.

Productspecifications LDX46

LCDtechnology SPVA,normallyblack

DIDtechnologyforextensiveusage

AIRAntiImageRetentionCircuitry

Resolution FullHD(1920x1080)

Backlight EdgeLED

AspectRatio 16:9

LCDtechnology •SPVA,normallyblack

•DIDtechnologyforextensiveusage

•AIRAntiImageRetentionCircuitry

•Internal10bitprocessingforprecisecolorcalibration

Pixeldensity 48dpi

Refreshrate 120Hz

Luminance 700cd/m²(max)

Contrastratio 4000:1(typ)

Viewingangle H178°/V178°

Whitepoint 10,000K

Colordepth 10bits1.07Bcolors

Precision Internal10bitprocessingforprecisecolorcalibration

Backlightlifetime 50,000h

MTBF >100,000h@25°C

Activescreendiagonal 46”(1168mm)

Dimensions 1075x639x85mm(42.32”x25.16”x3.35”)

Activescreenarea 1019x573mm(40.12”x22.56”)

Weight 27kg(59.52lbsnet)

Cooling Fanlesscoolinglownoise

ACinputvoltage 100240VAC,6050Hz

Powerconsumption 207W(max)

88(typ)

19(sleep)

2.1(stdby)

Heatdissipation 706BTU/h(max)

VGA SeparatesyncDSUB15Pin/out

DVI SinglelinkDVIDin/outwithHDCP

Displayport Displayportinput(OutviaDVI)

HDMI HDMITypeAwithHDCP(OutviaDVI)

HDSDI 2xBNCin

2xout

SD,HD,3Gb/s

CVBS BNCin/out

Svideo MiniDINSterminalin/out

Componentvideo 3xBNCin/out

BarcoNSLcontrolmanager ServerconnectedviaRS232chain

Remoteclientapplication:on/off,wallsetup,sourceselection,status,brightness,

contrastandcoloradjustments

Controlsignal RS232DSUB9PINin/out

Operatingtemperature 0°to40°C

Operatinghumidity 2080%noncondensing

Storagetemperature 2060°C

Storagehumidity 1090%noncondensing

RegulationCompliance CE,TÜV,cTÜVus,CCC,ROHS,WEEE

Generatedon:26Feb2014

Technicalspecificationsaresubjecttochangewithoutpriornotice.

Pleasecheckwww.barco.comforthelatestinformation.
