barbas ECO 810 Manuel utilisateur
DIRECTIONS FOR USE INSTALLATION INSTRUCTIONS
NAME OUTPUT DESCRIPTION
ECO 810 6,0 - 10,0 kW Stove
EN - 13240
ECO 810
DIN plus
3
ECO 810
ECO 810 Soapstone
Storage drawer and floor plate are optional!
ECO 810 Cast iron
4
ECO 810
5
ECO 810
TABLE OF CONTENTS
1. Introduction
1.1 Preface........................................................................
1.2 Safety..........................................................................
2. Location..............................................................................
3. Installation instructions.........................................................
4. Operation of the stove...........................................................
5. Stoking up for the •rst time...................................................
6. Use
6.1 Ventilation....................................................................
6.2 Getting the •re going.....................................................
6.3 While stoking...............................................................
6.4 Heating economically....................................................
7. General hints
7.1 Tips.............................................................................
7.2 Output.........................................................................
8. Fuels..................................................................................
9. Amount of fuel.....................................................................
10. Regular maintenance............................................................
11. Replacement parts...............................................................
12. Dimensions.........................................................................
13. Technical parts....................................................................
14. Frequently asked questions..................................................
Page
7
7
10
12
23
27
28
28
28
30
31
32
34
35
37
38
40
41
42
6
ECO 810
7
ECO 810
1. INTRODUCTION
1.1. PREFACE
We would like to congratulate you on your purchase of this modern BARBAS
stove. This quality product will give you years of heating pleasure as you enjoy
the play of the flames and the cosy glow of the fire.
This manual contains directions for both positioning the appliance and for its
environmentally-friendly use. It also contains technical data for the appliance,
parts information and directions in the event of problems. Study this manual
carefully before using the stove. We recommend you keep this manual in a safe
place for reference purposes.
1.2. SAFETY AND INSTALLATION INSTRUCTIONS
Safety
ŸDo not place flammable objects within 80 cm of the appliance. Pay special
attention to furnishings and ornaments around the stove.
Ÿ To ensure safe working of the stove, at least 20 cm must be left between the
sides/rear and the wall (temperature ≤ 80 °C).
Ÿ If the floor is flammable, an inflammable floor plate should be used under the
appliance. Towards the front and the side, you should leave a minimal
distance for the floor plate with regard to the appliance of respectively 50 and
30 cm.
ŸWhen you use your stove, the exterior will become hot. Always wear the
glove or use the accessories supplied when filling etc. Protect yourself and
others (especially children!) from burns. Do not leave children unattended
when the stove is burning.
ŸWatch your clothing. Synthetic clothing in particular can easily catch fire and
burn intensely.
ŸDo not approach the appliance with flammable materials or liquids. Any work
with solvents, adhesives etc. in the space heated by the stove can be very
dangerous.
8
ECO 810
ŸMake sure you know what state your chimney is in. Cracks in the chimney
may not only lead to damp, staining of walls and leaking of smoke, they
can also impair the carrying off of smoke. Make sure you get proper
advice from your Barbas dealer or other specialist company.
ŸAvoid chimney !res" Have your chimney swept at least once per year - more
often if you use your stove a lot.
Prevent excessive deposits of soot inside the chimney by not burning freshly-
cut wood. Instead, burn clean, dry chopped wood.
ŸDo not use your stove as a barbecue. This can cause (#ammable) fat
deposits to be left in the chimney and hastens the chimney becoming
clogged. Prevent your chimney being soiled from above (birds’ nests etc.) by
!tting a suitable cap to the chimney pot.
Ÿ In case more than one stove is connected to a chimney, as is often the case
in Germany, the stove has self-closing doors (Bauart 1).
Ÿ Follow the instructions issued by your local !re brigade.
The stove can be taken in operation if national and local regulations are
satis!ed. The required constructive adaptations should be satis!ed as well.
Installation Instructions
ŸWood, wood bricks and (anthracite) coals can be burned in the stove.
ŸNever use the stove to burn rubbish.
ŸRead all instructions/stickers, on and around, the appliance.
ŸCarefully read the user manual before using your appliance for the !rst time.
When you !rst !re up your appliance, there are a number of extra points you
should take into account. See section 5.
ŸNever use liquid fuels, such as petrol, lighter #uid etc. Use of these could
cause dangerous situations and damage your appliance.
9
ECO 810
ŸIn transit, some parts of the appliance may have moved from their original
place. Check that the door opens and closes, the retardant plate (brake plate
below) is •tted correctly to the brackets at the top of the stove, the cast-iron
interior panels are •xed to the walls and the stones on the bottom have
not moved. Check that the ridling grill is in the correct position and slides
properly. Check that there is nothing in the ash drawer that should not be
there.
Ÿ Prevent over-•ring (white glow) by charging up the •re with primary air
(through the grid) over an extended period. Cast-iron components (grid, •re
cladding) may become overheated and be damaged as a consequence.
Fire the stove slowly when the stove is new and new cast iron has been
applied.
ŸConsult the current local building regulations before starting the assembly.
10
ECO 810
2. LOCATION
2.1. INCLUDED
Set - Warranty
documentation - Manual
- Connection ring (cast iron)
- Sealing plate
Smoke - 4 Attachment bolts including
connection nuts and washers
set box - Protective plate for rear of appliance
- 2 Screws for fastening the protective
In the plate
appliance
- Glove
- Small brake plate above. Only for use
with a top flue connection, including 2x
spacer sleeve, L = 26 mm and fitting
material
- Cast-iron rosette
- Cast-iron cover plate
- Rosette support for cast-iron cover
plate
Soapstone
panel set - Top plate with through-feed hole
Type - Left side panel
Cast iron - Right side panel
N.B. If any part is missing, please contact your dealer.
