recycle previous test steps, saves time and permits immediately detect-
ing the extent to which rejuvenation should be performed.
%
12. Simplified life test.
13. Activate mode provides precise metered monitoring of activation.
14. Rejuvenation capability is provided in three improved steps, the first
two of which are automatically timed to prevent damage to atube. The
unique Super Rejuvenate feature provides even greater capability for
restoring the emission of an aging and otherwise worthless CRT.
*-.
15. The largest storage spacejjfany CRT tester currently available.
16. New improved, expanded, more versatile adapter set is included and
provides capability to directly test more CRT types than any other cur-
rently available tester. For example, even the new Trinitron, 11SP22
and 11WP22 tubes are accurately tested on the 466 without having to
obtain additional adapters at added cost.
• 9 •
*V
17. Unlike other CRT testers which allow some of the internal elements
of acolor CRT' under test tp “float at random” or to be shorted to-
'a *•••
•,''v•*•
gether (to reduce; cost of the tester), in all test modes the 466 insures
that all key elements of the color CRT are properly connected to ap-
propriate test circuit points. This permits greater precision in test re-
sults and eliminates the real possibility of any uncontrolled, internal
current paths injuring the CRT under test.
***** ^
•<
••••%•V
Safety Precautions
•••—A4‘* •
NOTE: The proper power line supply voltage is indicated in the line
cord storage compartment. Do not attempt to operate this instrument from
apower source other than specified.
When testing any CRT that is installed in achassis, first disconnect the
chassis power plug from the AC line outlet. DO NOT APPLY POWER
TO THE CHASSIS AT ANY TIME DURING THE TEST OF THE
CRT. Remove the receiver female socket assembly from the base of the
CRT. Always perform test steps carefully.
5
