Baling WL10 Manuel utilisateur
Special Attention:
1. Mechanical keys please keep outdoor, just in case keys lock in doors.
2. Please charge for the battery when low wattage alarm.
3. Reading this manual carefully before installation, and keep it for future reference.
Smart Lock User Manual
1
1. Lock Structure
2. Mortise
2
3. Installation
3.1 Turn the handle
Notice: Adjust the handle according to the direction you open the door.
For Front Panel:
For Back Panel:
3
3.2.1 Installation Diagram(For Latch)
Step 1 Install Mortise
Step 2 Install Sliding Screw Casing
Step 3 Fix Front Panel and Wire
Step 4 Install Back Panel
Step 5 Install the Battery
Step 6 Install the Battery Cover
1.
The screw casing
place is adjustable
from 55mm to 100mm
far from the square
shaft.
Depending on the
location of the
hole-drilling or the old
door hole.
2.
Keep arrow directi
on(shows in image
) always facing to
the latch
4
3.2.2 Installation Diagram(For 5572)
Step 1 Install Mortise
Step 2 Install Sliding Screw Casing
Step 3 Fix Front Panel and Wire
Step 4 Install Back Panel
Step 5 Install the Battery
Step 6 Install the Battery Cover
1.
The screw casing
place is adjustable
from 55mm to 100mm
far from the square
shaft.
Depending on the
location of the
hole-drilling or the old
door hole.
2.
Keep arrow directi
on(shows in image
) always upward.
5
4 Specifications
Suitable for Models
WL10
Materials
Zinc Alloy
Front Panel Lock Size
170*70*20mm
Back Panel Lock Size
170*70*20mm
Lock Weight
1.5KG
Unlocking way
Password
Card
Mechanical key
Color
Silver
Black
Doors Applicable
Aluminum Door
Wooden Door
Working Voltage
6V/8x AAA Batteries
Door Thickness to Fit
30-65mm/65-100mm
Data Capacity
500 Password
500 Card
Working Temperature
-25℃-60℃
Working Humidity
20%-90%
Low Wattage Alarm
Less than 4.5V
Features:-
Passage mode function
LCD screen display Date & Time, User ID access & User unlock records
Stainless steel handle
Voice guided operation
Auto secure & break-in alarm
Voice setting function
Auto locking time setting function
Privacy locking
Dual combination mode
Anti-theft Password
Emergency power supply through USB
Note : The lock can be opened using default code 123456 followed by # in trial mode
6
5.Operating Instructions
5.1. Key Manual
Key
Function of the key
2
↑UP
8
↓DOWN
4
←LEFT
6
→RIGHT
*
EXIT; Long press 3s to enter the menu
#
ENTER
5.2 Setting
System Initialization
Method 2
Method 1:Open the cover of the
battery, long press the "Reset"
button on the back panel for 5s,
prompt "initialization success"
and the initialization is complete
Choose “5.system set”
Press”#” confirm
Long press”*”for 3s
Enter the menu
Choose “7.initialization”
Choose “yes”
Press”#” confirm
Display:”succeed”
initialization is complete
7
5.3 User management
8
5.4 Trouble Shooting
5.4.1 Programming Troubleshooting
1) How to read operation records?
In the Records of the main interface. / Or in Web TTLock.
2) What is the purpose of upload
fingerprint?
What is uploaded is not the fingerprint itself but just the
number of the fingerprint. Because some locks don’t
need to go through the APP to add fingerprint, they
can’t be seen in the APP. You need to upload fingerprint
before you manage them in the APP.
3) What is the maximum limit of
e-Key?
No limit.
4) Why it shows “pending” when
we send e-Key to other?
Before the receiver opens the APP to receive, the status
shows Pending.
5) Unable to received OTP?
It may be due to a problem with the operator or the SMS
server, or it may be due to some of the parameters
being incorrect, which prevents it from receiving OTP.
Please provide a mobile phone number for inspection.
6) Can be used same user name at
same time on different mobile?
No, it can’t. But you can authorize the admin to other
user.
7) Whether to download unlock
records?
Bluetooth: you can download in web
Non-Bluetooth: can not download
8) Why can’t I unlock it after open
the passage mode
You need to perform an unlock verification in any
method, than the passage mode will take effect.
9) What is the purpose of Auto Lock
You can set how long to lock after unlocking
10)Why it can not to send e-Key
Check if the account sent to the user is already
registered
11)APP can add maximum limit of
the locks
Not limit.
9
12)Is it possible to obtain passcode,
add fingerprint and card
remotely?
A) Non-custom passcode: can be obtain directly;
Custom passcode: can be obtain remotely by adding
gateway.
B) Fingerprint: do not support remote addition for the
time being.
C) The remote add card currently only supports Android
phones with NFC
5.4.2 Hardware Troubleshooting
1) After installation, touch
sensing keyboard, screen no
respond
a) In this case, first check that the positive and
negative electrodes of the battery have been
installed upside down, whether the battery has
enough power
b) Remove the back panel and see if it's connected.
c) To eliminate the above situation, you need to remove
the lock ,check whether the wires of the lock body
are squeezed, and the re-wire.
2) Unable to register
fingerprint
Check the fingers for dirt or wear, check the
fingerprint head on the lock for dirt and oil stains,
etc.
Check to see if the fingerprint is working
properly(Press to see if there is any responds.
3) Fingerprint verification is
successful, but the door
cannot be opened.
The fingerprint lock has two important components: one
is the fingerprint module and the other is the
electronic clutch .If the verification is successful
but the door does not open, you can listen carefully when
the verification is successful, and if there is any
sound of the motor rotating inside the lock. If there
is, it is usually caused by the clutch in the handle.
If not , it may be because the circuit board to the motor
line has burned out. At this time, you can’t solve it
yourself, or the warranty is processed.
4) What is the reason why the
smart lock consumes fast
power?
a) Large standby power consumption
b) Short circuit
5) Can you adjust the volume?
a) The Bluetooth system can only turn the sound On or
