Bachmann F3-A Dummy Manuel utilisateur

– Page 1 of 2 –

Bachmann Industries, Inc.

1400 East Erie Avenue, Philadelphia, PA 19124 USA

www.bachmanntrains.com

Customer Service Telephone 800-356-3910

F3-A DUMMY DIESEL LOCOMOTIVE INSTRUCTIONS

Thank you for purchasing a Williams by Bachmann® locomotive. This locomotive has been manufactured to provide

years of use and enjoyment. Please follow the simple instructions below.

Before operating, please lightly lubricate the points shown in the diagram below. Do not over-lubricate and take extra care

to avoid getting lubricants on the wheel surfaces.

1. For the axles and coupler pivot points Marked A, we recommend that you lubricate with a small amount of light

oil such as Bachmann E-Z Lube® #99984 Light Gear Oil. Do not over-lubricate.

2. For areas that require electrical flow, such as roller pick-ups Marked B, please use Bachmann E-Z Lube®

#99981 Conductive Contact Lube. Never use any Teflon® based oil on these areas because this type oil has

insulating properties.

– Page 2 of 2 – Printed In China

OPERATION

After unpacking the locomotive, make sure that the uncoupling plunger is in the correct position with the pin inserted in

the knuckle (see figure 1). Failure to do so will allow the uncoupling plunger to contact the center rail and a direct short

will occur when power is applied to the track.

Uncoupling

This dummy locomotive is equipped with an operating knuckle coupler at the pilot end. The rear end of the locomotive

has a fixed coupler, to allow close coupling with the matching powered unit. To uncouple, position the uncoupling

plunger over the center of electro-magnetic track uncoupling section and activate the magnet.

PERIODIC MAINTENANCE

Disassembly Instructions

You will have to remove the body shell for bulb replacement, or to install a power upgrade kit. The body shell is attached

with four screws on the bottom of the locomotive frame. The screws are located in each corner of the frame. When you re-

attach body shell, please be careful not to over-tighten the screws.

Lubrication

We recommend that you lubricate as directed on page 1 every 10 hours of operation.

Light Bulb Replacement

This locomotive uses a 12 volt bayonet style bulb. The standard replacement bulb number is 53.

Power Upgrade Kit

A power upgrade kit, Williams by Bachmann® #00244, is available to convert this dummy unit into a powered unit.

Please follow the installation instructions that are included with the kit.

Bachmann Industries, Inc.

1400 East Erie Ave Philadelphia PA 19124 USA

F3-A (Dummy) Parts List Rev 08.27.08 Printed in China

1400

East

Erie

Ave

Philadelphia

19124

USA

www.bachmanntrains.com

Customer Service Tele

hone 800-356-3910

art

escr

F3-A BODY & BODY PARTS

1468-E002 Body Shell - complete 1

1-30100DPA Screw(Mounts Body to Frame) 4

1468 02 01

Die Cast Chassis

1468

ast

ass

1468-E003 Ornamental Horn 2

1468--03-02 Headlight lens 1

1468-03-01 Windshield 1

1468-03-05 Porthole Lens 4

1468-03-03, 1468-03-06

umber Boards Right & Left 1 each

1468-04-01 Front Grab Iron 2

1468-04-02

Body Ladder

1468

Body

Ladder

293-M021B Rear Ladder 1

1-25060DPS Screw(Mounts Fuel Tank & rear ladder to Frame) 2

TRUCK PARTS

293-M023FR1 Flanged Wheel 8

293-M029NR5 Axle 4

1-30140DPM Truck Mounting Screw 2

293-E001 O

eratin

Cou

ler Assembl

293 E001

Operating

Coupler

Assembly

293-07-01B

on-Operating Coupler 1

885-M013R1 Spring for non-operating coupler 1

1-26060DPWM

ounting Screw for non-operating coupler 1

1027-02-01 Pilo

1-30060DFM Pilot Mounting Screw 1

293-E002R1 Roller Pickup Assembly 1

293-01-02 Top Insulator for Roller Pickup 2

293 01 03

Bottom Insulator for Roller Pickup

293

ottom

nsu

ator

1-26220DPM Roller Pickup Mounting Screw 2

293-06-01 Sideframe 4

1-30060DPM Sideframe / Bolster Mounting Screw 10

293-10-03BR1 Truck Mount 2

1468-E005 Front Truck Bolster with Ladder 1

1468-E006 Rear Truck Bolster with Ladder 1

S Di it id f id tifi ti P t h i It li t ill t t d

See Diagram on opposite side for identification. Parts shown in Italics are not illustrated.

F3-A (Dummy) Parts List Rev 08.27.08 Printed in China
