Baby Trend SNAP N GO 1305 Manuel utilisateur

Convenience through innovation and thoughtful design

Instruction Manual

10.05

Model #1305

Read all instructions BEFORE assembly and USE of product.

KEEP INSTRUCTIONS FOR FUTURE USE.

SNAPNGO

WARNING: Please follow all of these instructions to ensure the

safety of your children. Keep these instructions for future reference.

WARNING: Failure to follow these instructions could result in

serious injury or death. Avoid serious injury from falling or sliding out.

Always use the infant car seat harness and insure that the child and infant

car seat are properly positioned according to these instructions.

WARNING: Never leave child unattended.

WARNING:Care must be taken when folding and

unfolding the product to prevent  nger entrapment.

• Purses, shopping bags, parcels, diaper bags or accessory items may change the balance of the stroller and cause

hazardous unstable conditions.

• The maximum weight that can be carried in the basket is 5 lbs. The maximum weight for the parent tray is 3 lbs.

Excessive weight may cause a hazardous unstable condition to exist.

• Be certain the stroller is fully erect and latched in the open position before allowing the child near the stroller.

• Use of the stroller with a child weighing more than 25 pounds will cause excessive wear and stress on the

stroller and may cause a hazardous unstable condition to exist.

• DO NOT use the stroller on stairways or escalators.

• Never allow your stroller to be used as a toy

• To clean use only mild household soap or detergent and warm water on a sponge or clean cloth.

• Check your stroller for loose screws, worn parts, torn material or stitching on a regular basis. Replace or repair

parts as needed

• Discontinue use of stroller should it malfunction or become damaged. Please contact our customer service Parts

Hotline to arrange for repair or obtain replacement parts.

Please: If you experience any dif culty with the use of our product or have a question regarding these

instructions, please contact our Customer Service Department at (800) 328-7363 between the hours of 8:00 and

4:30 Paci c Coast Time. Please do not return the product to the store as once it is returned it cannot be re-sold

and the materials and energy used to make it are wasted.

SNAP-N-GO 10.05

To Contact us:

Baby Trend, Inc.

1567 S. Campus Ave.

Ontario, CA 91761

Parts Hotline:

(800) 328-7363

8:00 a.m. and 4:30 p.m. Paci c Coast Time

ASSEMBLY:

• Remove stroller from box. The front wheels, rear wheels and

parent tray need to be installed prior to use.

• To attach the front wheels, unfold stroller as described in the

section following. See  gure 1. Lean the stroller backwards so

that it rests on the handle and rear frame tubes and the front wheel

bayonet are pointing upward. Position the front wheel assembly

at the front wheel bayonet such that the swivel assembly will slide

onto the front wheel bayonet. Push each front wheel assembly

onto the front wheel bayonet until snapped into place. Pull on

the wheel assembly to ensure that it is securely attached to the

stroller. Please see  gure 2.

• Lean the stroller forward to rest on the front wheels. To attach

the rear wheels, position the rear axle and wheel assembly such

that the brake levers are facing to the rear of the stroller. Press the

rear wheel assembly onto the rear frame tubes being careful that

the push buttons on the forward side of each rear tube engage the

hole on the forward side of each rear wheel housing. Pull on the

rear wheel assembly to ensure that it is securely attached to the

stroller. Please see  gure 3.

Ensure that the wheels are  rmly locked into place. Do Not use the

stroller if the wheels are not locked into place, but rather contact

our customer service department immediately at (800) 328-7363,

between the hours of 8:00am and 4:30pm PCT, for assistance.

TO ENSURE SAFE OPERATION OF YOUR STROLLER, PLEASE FOLLOW THESE

INSTRUCTIONS CAREFULLY. RETAIN THESE INSTRUCTIONS FOR FUTURE

REFERENCE.

Stroller

Front Wheels

Rear Axle Parent Tray

Figure 1.

Figure 2.

Figure 3.

Push onto

bayonet

• To attach the parent tray, position the tray so that the hinges for the

storage compartment are facing foward. Attach one end at a time by

locating the  tting at the top of the frame and the hole on the side

of the parent tray, snap together. Repeat for other side. Check that

the tray is securely latched in place. Please see  gure 4. To remove

parent tray, reverse the installation steps.

WARNING: Do not place hot

liquids in the parent tray. Hot liquids

can burn your child. Do not place more

than 3 pounds in the tray as it may cause a

hazardous unstable condition to exist.

WARNING: Avoid serious injury

from falling or sliding out. Always use the

Infant Car Seat harness.

BRAKES

WARNING: Always set brakes

when the stroller is not being pushed so that

the stroller will not roll away. Never leave

stroller unattended on a hill or incline as the

stroller may slide down the hill.

• To engage brakes, apply light downward pressure to the brake lever

located on each rear wheel. The stroller may require slight forward

or rearward movement in order to line up the teeth on the brake

with the each wheel brake cluster. See  gure 5. Check that the

stroller will not move and that the brakes are properly applied. To

release, gently lift up on the brake lever.

TO FOLD STROLLER:

Do Not allow children near stroller while folding.

• To fold the stroller slide the red handle in the center of the handle to

the left and squeeze while pushing forward on the handle. Once the

stroller begins to fold, release the red handle and pull backward on

the front frame until stroller is folded. Please see  gure 6. Secure

the stroller in the folded position by latching the fold latch, located

on the right side of the stroller at the intersection of the handle

and the rear tube, over the extended rivet on the lower frame tube.

Please see  gure 7. 3

Figure 4.

Figure 5.

Figure 6.

Figure 7. Figure 8.

LOCK

UNLOCK

TO UNFOLD STROLLER:

Do Not allow children near stroller while unfolding.

• Release the folding latch, which is located on the right side. See

 gure 8.

• Lift up on the stroller handle with both hands until the stroller frame

is erect and locked in the open position. See  gure 9. The stroller

has spring-loaded latches on both sides of the frame. Test that both

latches are fully engaged prior to placing your child in the stroller.

TO ATTACH AN INFANT CAR SEAT

• Place car seat onto front bar. See  gure 10. NOTE: Some brands

of infant car seats will lock onto the front bar, and some brands

may simply rest on the front bar, You must ALWAYS use the

safety belt to secure every car seat that is placed on the snap n

go.

• Make sure the front of the car seat rests on the red support tabs located

on the frame. See  gure 11. NOTE: For wider car seats there is a

higher support tab located above the main red support tabs.

• Strap the safety belt over the carseat and connect the buckles together.

Tighten the strap so the car seat  ts snug and can't move. See  gure

12. NOTE: Some car seats have slots for the safety belt to slide

through, if you have a car seat with these slots please feed the

safety belt through each slot and secure. See  gure 13

IF YOU EXPERIENCE ANY DIFFICULTY IN USING THIS PRODUCT,

PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT AT (800) 328-7363

BETWEEN THE HOURS OF 8:00AM AND 4:30PM PACIFIC COAST TIME FOR ASSISTANCE.

Figure 9.

Figure 10.

Figure 11.

FRONT

SUPPORT

TAB

Figure 12.

Figure 13.

WARNING: Avoid serious injury

from falling, ALWAYS use the safety belt

to secure carseat to stroller.
