Read all instructions BEFORE assembly and USE of product.
KEEP INSTRUCTIONS FOR FUTURE USE.
Model #1305
SNAP N GO
R
05.09
Instruction Manual
Convenience through innovation and thoughtful design
Copyright © 2006 - 2009, Baby Trend Inc., All Rights Reserved.
SNAP-N-GO
WARNING: Please follow all of these instructions to ensure the
safety of your children. Keep these instructions for future reference.
WARNING: Failure to follow these instructions could result in
serious injury or death. Avoid serious injury from falling or sliding out.
Always use the infant car seat harness and insure that the child and
infant car seat are properly positioned according to these instructions.
WARNING: Never leave child unattended.
WARNING: Care must be taken when folding and unfolding
the product to prevent nger entrapment.
• Purses, shopping bags, parcels, diaper bags or accessory items may change the balance of the stroller and cause
hazardous unstable conditions.
• The maximum weight that can be carried in the basket is 5 lbs. The maximum weight for the parent tray is 3 lbs.
Excessive weight may cause a hazardous unstable condition to exist.
• Be certain the stroller is fully erect and latched in the open position before allowing the child near the stroller.
• Use of the stroller with a total weight of more than 40 pounds will cause excessive wear and stress on the
stroller and may cause a hazardous unstable condition to exist.
• NEVER use the stroller on stairways or escalators.
• NEVER allow your stroller to be used as a toy.
• To clean use only mild household soap or detergent and warm water on a sponge or clean cloth.
• Check your stroller for loose screws, worn parts, torn material or stitching on a regular basis. Replace or repair
parts as needed.
• Discontinue use of stroller should it malfunction or become damaged. Please contact our customer service Parts
Hotline to arrange for repair or obtain replacement parts.
If you experience any difculty with the use of our product or have a question regarding these instructions,
please contact our Customer Service Department at 1-800-328-7363 between the hours of 8:00 and 4:30 Pacic
Standard Time. Please do not return the product to the store as once it is returned it cannot be re-sold and the
materials and energy used to make it are wasted.
To Contact us:
Baby Trend, Inc.
1607 S. Campus Ave.
Ontario, CA 91761
Parts Hotline:
1-800-328-7363
8:00 a.m. and 4:30 p.m. Pacic Standard Time
WARNINGS
1
ASSEMBLY:
• Remove stroller from box. The front wheels, rear wheels and
parent tray need to be installed prior to use.
• To attach the front wheels, unfold stroller as described in the
section following. See gure 1. Lean the stroller backwards so
that it rests on the handle and rear frame tubes and the front wheel
bayonet are pointing upward. Position the front wheel assembly
at the front wheel bayonet such that the swivel assembly will slide
onto the front wheel bayonet. Push each front wheel assembly
onto the front wheel bayonet until snapped into place. Pull on
the wheel assembly to ensure that it is securely attached to the
stroller. Please see gure 2.
•Lean the stroller forward to rest on the front wheels. To attach
the rear wheels, position the rear axle and wheel assembly such
that the brake levers are facing to the rear of the stroller. Press the
rear wheel assembly onto the rear frame tubes being careful that
the push buttons on the forward side of each rear tube engage the
hole on the forward side of each rear wheel housing. Pull on the
rear wheel assembly to ensure that it is securely attached to the
stroller. Please see gure 3.
Ensure that the wheels are rmly locked into place. Do Not use the
stroller if the wheels are not locked into place, but rather contact
our customer service department immediately at 1-800-328-7363,
between the hours of 8:00am and 4:30pm PST, for assistance.
BASKET
Rear basket tube needs to be installed prior to use. Insert the
female end of the rear basket tube into the male ends located on the
basket frame until it locks into place. (Fig. A)
TO ENSURE SAFE OPERATION OF YOUR STROLLER, PLEASE FOLLOW
THESE INSTRUCTIONS CAREFULLY. RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
Stroller
Front Wheels
Rear Axle Parent Tray
Figure 1.
Figure 2.
Figure 3.
Push onto
bayonet
2
Rear basket tube
Basket frame Figure A
•To attach the parent tray, position the tray so that the hinges for the
storage compartment are facing foward. Attach one end at a time by
locating the tting at the top of the frame and the hole on the side
of the parent tray, snap together. Repeat for other side. Check that
the tray is securely latched in place. Please see gure 4. To remove
parent tray, reverse the installation steps.
WARNING: Do not place hot
liquids in the parent tray. Hot liquids can
burn your child. Do not place more than
3 pounds in the tray as it may cause a
hazardous unstable condition to exist.
WARNING: Avoid serious injury
from falling or sliding out. Always use the
Infant Car Seat harness.
BRAKES
WARNING: Always set brakes
when the stroller is not being pushed so that
the stroller will not roll away. Never leave
stroller unattended on a hill or incline as the
stroller may slide down the hill.
• To engage brakes, apply light downward pressure to the brake lever
located on each rear wheel. The stroller may require slight forward
or rearward movement in order to line up the teeth on the brake
with the each wheel brake cluster. See gure 5. Check that the
stroller will not move and that the brakes are properly applied. To
release, gently lift up on the brake lever.
TO FOLD STROLLER:
Do Not allow children near stroller while folding.
•To fold the stroller slide the red handle in the center of the handle to
the left and squeeze while pushing forward on the handle. Once the
stroller begins to fold, release the red handle and pull backward on
the front frame until stroller is folded. Please see gure 6. Secure
the stroller in the folded position by latching the fold latch, located
on the right side of the stroller at the intersection of the handle
and the rear tube, over the extended rivet on the lower frame tube.
Please see gure 7.
Figure 4.
Figure 5.
Figure 6.
Figure 7. Figure 8.
LOCK
UNLOCK
3
TO UNFOLD STROLLER:
Do Not allow children near stroller while unfolding.
•Release the folding latch, which is located on the right side. See
gure 8.
• Lift up on the stroller handle with both hands until the stroller frame
is erect and locked in the open position. See gure 9. The stroller
has spring-loaded latches on both sides of the frame. Test that both
latches are fully engaged prior to placing your child in the stroller.
TO ATTACH AN INFANT CAR SEAT
• Place car seat onto front bar. See gure 10. NOTE: Some brands
of infant car seats will lock onto the front bar, and some brands
may simply rest on the front bar, You must ALWAYS use the
safety belt to secure every car seat that is placed on the snap n
go.
•Make sure the front of the car seat rests on the red support tabs located
on the frame. See gure 11. NOTE: For wider car seats there is a
higher support tab located above the main red support tabs. See
Figure 11.
•Strap the safety belt over the carseat and connect the buckles together.
Tighten the strap so the car seat ts snug and can't move. See gure
12. NOTE: Some car seats have slots for the safety belt to slide
through, if you have a car seat with these slots please feed the
safety belt through each slot and secure. See gure 13.
IF YOU EXPERIENCE ANY DIFFICULTY IN USING THIS PRODUCT, PLEASE CONTACT OUR
CUSTOMER SERVICE DEPARTMENT AT 1-800-328-7363 BETWEEN THE HOURS OF
8:00AM AND 4:30PM PACIFIC STANDARD TIME FOR ASSISTANCE.
Figure 9.
Figure 10.
Figure 11.
FRONT
SUPPORT
TAB
Figure 12.
Figure 13.
WARNING:Avoid serious injury
from falling, ALWAYS use the safety belt
to secure carseat to stroller.
UPPER TAB
FOR WIDER
CAR SEAT
4
