Baby Jogger CITY ELITE SINGLE Manuel utilisateur

Read these

instructions carefully

before use and

keep them for

future reference.

Your child’s safety may be

affected if you do not follow

these instructions.

Assembly

Instructions

City Elite Single

Amazing 360° Turns

Make For Extreme Maneuverability

This product complies with BS EN 1888:2003 inc. A1,2,3: 2005

This product complies with ASTM F833-07a

• WARNING: DO NOT exceed 3mph – this stroller is not suitable for running, jogging,

skating or roller blading.

• WARNING: Prevent serious injury to your child by always using the safety harness.

• WARNING: Parcels or accessory items, or both, placed on the unit may cause the unit

to become unstable.

• WARNING: Never leave your child unattended.

• WARNING: Recommended weight for seat pocket is 2 lbs and basket is

4.4 lbs. Excessive weight may cause a hazardous unstable condition to exist.

• WARNING: Stroller is not meant to be used for transporting children up or down

stairs. Damage resulting to stroller will not be covered under warranty.

• WARNING: Child may slip into leg openings and strangle. Never use in reclined

carriage position unless safety harness is properly fastened.

• Accessories which are not approved by the manufacturer or distributor

shall not be used.

• The passenger shall remain seated (no standing in the stroller).

• Watch out for cars – never assume that a driver can see you and your child.

• Total weight load recommended for this stroller is 75 lbs / 34 kg

(combined passenger and baggage weight).

• This stroller seats one passenger.

• It may be unsafe to use replacement parts other than those supplied or approved

by the manufacturer.

For the sake of your precious cargo, please read

these warnings before using your stroller.

1Unpack stroller from box and set rear wheels

aside. Ensure that storage latch is not fastened

on frame before unfolding stroller.

2Pull front wheel forks up from

underneath the handlebar.

Then, pull bottom of frame

up and away from handlebar.

3Lay stroller flat so that both ends are

resting on the floor. The stroller frame

will click and lock into place.

WARNING: Ensure all

locking devices are

engaged before use.

To fold: Unsnap safety strap from frame and pull up on fold strap.

Frame

4Turn stroller over.

Front Wheel

Rear Wheels

1To install front wheel, lay stroller back so the

handle is resting on floor.

2 Align the round opening on the top of the front

fork with the round metal peg underneath the

foot plate. Slide the front wheel onto the metal

peg until it clicks into place.

To remove the front wheel, press down on the lever on the

top of the front fork and slide the wheel off.

Front Wheel Locking Lever

Turn to the left to lock front wheel.

Turn to the right for swivel action.

1To install, gently slide the rear wheel’s axle into the hole in the frame until the wheel clicks into place.

2To remove, simply press the

wheel button while gently

sliding the wheel away from

the frame.

Safety Harness

WARNING: Always use the crotch strap in combination with the

shoulder straps and waist belt.

1Unclip top of shoulder

strap from the seat and

re-clip on the pair of

seat loops closest to

your child’s shoulder

height.

2To adjust the shoulder

and crotch strap length:

Remove the shoulder

pads and slide the

plastic guide up or

down to lengthen

or shorten.

WARNING: Engage

parking device

before loading

and unloading

passenger.

Brake

• To engage parking brake: Gently

pull brake lever into upright

position until it clicks into place.

• To release parking brake:

Pinch gray tabs and pull

towards you. Push brake

lever down until it is

parallel with the frame.

3To buckle the harness: Simply

push side buckle into center

buckle until it locks into place.

To unbuckle: Push one side of

the center button and pull the

corresponding side buckle away

from the center buckle. Repeat

to unbuckle other side.

To remove canopy: stand facing the stroller

and press the bracket buttons with index

finger while removing canopy from the

bracket.

1To attach canopy to frame, simply slide canopy

axle into top hole of the bracket on the

frame, until you hear it click into place. The

bottom hole can be used for accessories (sold

separately), and they should be inserted into

bracket the same way as the canopy.

Canopy

3Secure canopy around frame

with Velcro tab.

2Snap webbing together

around top of frame.

4Once canopy is in place,

attach the console by

aligning the Velcro strips

on the console and

canopy.

Seat

1Secure seat fabric to

frame by lining up

snap placement on

frame and fabric.

To fold stroller:

Remove child from

seat. Unsnap safety

straps from frame

and pull upwards on

the fold strap with a

gentle tug.

3Secure safety straps to both

sides of the frame before use.

4Be sure that fold strap rings are secured to the

frame before use.

2Secure seat straps around the bottom

of the frame, behind the front wheel.

Thread one seat strap through the D

ring of the other strap, and fasten both

Velcro sides firmly together.

WARNING: Always be

sure the safety strap

Is securely snapped

onto the frame

before using stroller!

Raised Kicker

Basket

1To use the raised kicker, pull

up on seat flap above the

footplate, and remove the

kicker stand from storage

pocket. Attach the kicker

stand to the seat with the

hooks provided under seat flap.

1From the front of the stroller: Remove lower

seat fabric to expose bottom front portion

of frame. Fasten basket Velcro around frame

tubing on right side. Repeat on left side.

Re-apply seat fabric to frame once complete.

2Attach kicker stand by

wrapping both sides of the

webbing under the footplate.

Thread one side of the velcro

webbing through the D ring

of the other side, and secure

velcro together.

2From the rear of the

stroller: Fasten the top

snaps of the basket

around frame tubing

above the middle

support bar.

3When not using the raised

kicker, tuck the kick stand

and the webbing straps into

the pocket provided under

the seat.

3Fasten the bottom

snaps of the basket

around frame tubing

below the middle

support bar.

1 To recline: Pinch the clamp behind the seat, and slide it down to desired recline. Pull seat down on

both sides to match recline position of clamp.

Reverse steps to return to the upright position.

Reclining Seat

• Weather Cover: If desired, pull weather cover down

and over the seat back mesh. Secure firmly over

both sides of seat. When not in use, roll weather

cover up and fasten with elastic loop and barrel

provided under top of the seat fabric.

Steering

• Steering your stroller is simple: It is balanced to turn with just a light touch on the handlebar without

having to lift the front wheel.

In the Dark

• Since we are concerned about the safety of you and your child, we recommend that you not use

your stroller at night. However, if you choose to, please attach reflective strips to the wheels and the

seat. Bicycle lights can also be mounted on the handle crossbar. These accessories can be found at

most bike stores.

Maintenance

• To preserve the longevity of your stroller, it is important to perform simple, regular maintenance.

The tires on your stroller are foam filled. Though the P.S.I is printed on the tire, you will never need

to inflate them. From time to time, make sure that the joints and folding areas are still in good

condition. If you hear any squeaking or feel tension, you can take your stroller to a local bike shop

for added lubrication. All repairs should only be carried out by an authorized dealer.

In Motion

Quick Fold

Technology

To fold stroller:

1Remove child from seat. Remove safety

straps from frame. Pull upwards on the

fold strap with a gentle tug.

The sample product shown in this manual may differ slightly from your production quality Elite stroller.

However, this will not affect the assembly or functionality of your Baby Jogger stroller.

Simple Lift & Fold

(Patented)

WARNING: Always be

sure the safety strap

Is securely snapped

onto the frame

before using stroller!

NOTE: When contacting

Baby Jogger regarding your

stroller, please have your

stroller’s serial number and

manufacturing date ready.

They can be found on the

lower back portion of the

frame, above the right wheel.

Washing

• You can machine wash your stroller’s seat in cold water with a mild detergent.

To minimize shrinkage, simply reattach the seat to the frame to dry.

(Please do not put the seat in the dryer!)

• Be sure to remove the frame from the back of the seat

before washing.

Wheel Care

• The wheels can be cleaned using a damp cloth.

They will need to be dried completely with a soft towel or cloth.

Storing

• Sunshine can fade seat fabric and dry out tires, so storing your stroller indoors will

prolong its good looks. However, if you do store it outside, using a tarp will help

protect against weather wear.

Stroller Care

Baby Jogger's Limited Lifetime Warranty:

Baby Jogger warrants that the frame is free of manufacturer defects for the lifetime of the product. Manufacturer’s defects include

but are not limited to the breaking of welds and frame tube damage. Textile or soft side materials and all other components

shall be warranted for one year from the date of purchase (except for tubes and tires). Proof of purchase is required to make a

warranty claim and the warranty is only extended to the original purchaser.

THIS WARRANTY DOES NOT COVER:















fitness for a particular purpose is according to the specific warranty period for this model unit at time of purchase. Some states do not allow the





consult your local or state consumer affairs office or your state’s Attorney General.

E-MAIL: 

CALL: 

 1-804-262-6277

MAIL: BABY JOGGER COMPANY

8575 Magellan Parkway

Suite 1000

 

WARRANTY REGISTRATION ON-LINE AT

www.babyjogger.com/register

We wish you many happy journeys with your new

stroller! Your stroller is a great product, and we

are proud to manufacture it. If you have any

questions or comments, please give us a call at:

1.800.241.1848

Baby Jogger is a Division of Dynamic Brands

8575 Magellan Parkway, Suite 1000 • Richmond, VA 23227

T: 800.241.1848 • F: 804.262.6277 • www.babyjogger.com

Thank You!

Autres manuels pour CITY ELITE SINGLE

Table des matières

Autres manuels Baby Jogger Poussette

Baby Jogger

Baby Jogger DELUXE PRAM Manuel utilisateur

Baby Jogger

Baby Jogger CITY MINI GT 2 Manuel utilisateur

Baby Jogger

Baby Jogger ATS Manuel utilisateur

Baby Jogger

Baby Jogger City tour 2 Manuel utilisateur

Baby Jogger

Baby Jogger Bassinet Kit Manuel utilisateur

Baby Jogger

Baby Jogger city tour LUX Manuel utilisateur

Baby Jogger

Baby Jogger CITY ELITE SINGLE Manuel utilisateur

Baby Jogger

Baby Jogger city mini GT Manuel utilisateur

Baby Jogger

Baby Jogger CITY CLASSIC DOUBLE Manuel utilisateur

Baby Jogger

Baby Jogger City Mini Single Manuel utilisateur

Baby Jogger

Baby Jogger CITY MINI 2 Manuel utilisateur

Baby Jogger

Baby Jogger CITY MINI GT 2 Manuel utilisateur

Baby Jogger

Baby Jogger city mini GT Manuel utilisateur

Baby Jogger

Baby Jogger SUMMIT X3 Manuel utilisateur

Baby Jogger

Baby Jogger F.I.T Manuel utilisateur

Baby Jogger

Baby Jogger SUMMIT X3 Manuel utilisateur

Baby Jogger

Baby Jogger ASTM F833-07A Manuel utilisateur

Baby Jogger

Baby Jogger City Mini Single Manuel utilisateur

Baby Jogger

Baby Jogger city premier Manuel utilisateur

Baby Jogger

Baby Jogger PERFORMANCE SINGLE Manuel utilisateur

Baby Jogger

Baby Jogger City Mini Zip Manuel utilisateur

Baby Jogger

Baby Jogger City tour 2 Manuel utilisateur

Baby Jogger

Baby Jogger SUMMIT 360 TRIPLE Manuel utilisateur

Baby Jogger

Baby Jogger CITY SELECT 2 Manuel utilisateur

Manuels Poussette populaires d'autres marques

Hauck

Hauck Priya Trioset Manuel utilisateur

CHILDHOME

CHILDHOME CWQDN Manuel utilisateur

Dreamer Design

Dreamer Design Rebound GST Manuel utilisateur

Britax

Britax STEELCRAFT AGILE Manuel utilisateur

Graco

Graco 7427 Manuel utilisateur

Comfort

Comfort COMPASS Manuel utilisateur

OBaby

OBaby Aura Manuel utilisateur

Tutek

Tutek Tirso Manuel utilisateur

Babify

Babify Dual Plus Manuel utilisateur

Graco

Graco Stroller Manuel utilisateur

Special Tomato

Special Tomato Jogger Manuel utilisateur

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manuel utilisateur

Otto Bock

Otto Bock Kimba neo Manuel utilisateur

Milly Mally

Milly Mally ROYAL Guide de démarrage rapide

Hauck

Hauck DUETT 3 PRAM Manuel utilisateur

BOB

BOB DUALLIE Manuel utilisateur

Nuna

Nuna Pepp Manuel utilisateur

Britax

Britax B2 Manuel utilisateur
