SafetyCam™
Steps to start
securing your rides
TM
1. Prepare for Installation …………………..…………………………
2. Mounting SafetyCam in vehicles (3 ways of doing it)
2.1 Using the mirror mount ………………..
2.2 Using 3M tape mount .………….………………………..
2.3 Using suction cup holder …………………………………..
3. Powering the Safetycam™ ……………………………………….
4. Verify SafetyCam integration on our App ………………
Recommended
Page 1
Page 2
Page 4
Page 5
Page 6
Page 7
Check out our installation video
on YouTube!
Scan the QR code on the right
: https://youtu.be/i7j2zK4r1BY
Azuga SafetyCam™ | Installation Guide | V 27.04.21
Steps to get started
Prepare for Installation
A
Check the Compatability of your GPS device
(Skip this step if you received a new device in the box)
The SafetyCam works in conjunction with a Plug-and-Play GPS
Tracker in the vehicle.
Note that it only works with a 4G-LTE device that began
shipping from Azuga in July 2019. If you have an older device
that runs on the 3G network, it will need to be replaced with a
newer device.
You can determine 4G or 3G by looking on the Azuga Web
portal under Admin-Devices and check the Product Code
column. If the code starts with DCM970, you have the correct
device that works with SafetyCam.
CVerify the vehicle mapping in Azuga Fleet App
(If you have received an Azuga GPS device in the box)
In packages with SafetyCam and GPS device bundled together,
they are paired to each other by default. If you have changed
the pairing of the device and SafetyCam, you can refer to Step
3 of this guide to update the associated vehicle with the proper
SafetyCam.
DChoose your preferred way to mount & power Safetycam in vehicle
By default, your kit includes a mirror mount and an OBD - II
Power Cable for easy installation
BInsert the Device
Once you have ensured you have the latest device, plug it into
the diagnostic port in your vehicle.
(888) 777-9718 | [email protected] | www.azuga.com
© 2019 Azuga, Inc. All rights reserved.
1
Mounting the Safetycam™ in vehicle
The Safetycam™ can be mounted in 3 di!erent ways, Using the Safetycam™ Mirror
mount or on the windshield using 3M adhesive Tape Holder or the suction cup
mount
Option 1: Using the Mirror Mount
Recommended
2 Sets of screws included,one set long and
the other set short, choose the proper one
that fit your vehicle.
2
(888) 777-9718 | [email protected] | www.azuga.com
© 2019 Azuga, Inc. All rights reserved.
Step 1.
Insert one screw into
the slot of the lower
half of clip as shown
Step 2.
Install the silicone
rubber pad properly as
shown
Step 4.
Install the other screw as
shown and be prepared
for mouning this clip onto
the car rearview mirror.
Step 3.
Mount the upper half of
clip and tighten the
screw with buterfly nut
Step 5.
Tightened the clip on the rearview mirror with butterfly nuts
Step 6.
mount the clam to the clip on the rearview
mirror as shown.
Mounting the Safetycam™ in vehicle
Option 1: Using the Mirror Mount (continued)
2 Sets of screws included,one set long and
the other set short, choose the proper one
that fit your vehicle.
3
(888) 777-9718 | [email protected] | www.azuga.com
© 2019 Azuga, Inc. All rights reserved.
Step 7.
Connect one end of connector to
the mount
Step 8.
Insert the holder into the slot on the safetycam
Mounting the Safetycam™ in vehicle
While mounting, please ensure that the mounting location is clean, free of
dust and cleaned with the alcohol rubs that’s provided in the box. It is
recommended to install the mounts under normal temperatures ranges and
not in very high/low temperatures.
Option 2: Using 3M tape mount
Step 1.
Insert the holder into the
slot on the safetycam
Step 2.
Peel o!the 3M tape cover
Step 3.
Place the mount and safetycam as high
as possible on the driver side of the
vehicle on the windshield such that
it does not obstruct the driver’s view
4
(888) 777-9718 | [email protected] | www.azuga.com
© 2019 Azuga, Inc. All rights reserved.
Mounting the Safetycam™ in vehicle
Note: While mounting, please ensure that the mounting location is clean,
free of dust and cleaned with the alcohol rubs that’s provided in the box. It is
recommended to install the mounts under normal temperatures ranges and
not in very high/low temperatures.
Option 3: Using suction cup holder
5
(888) 777-9718 | [email protected] | www.azuga.com
© 2019 Azuga, Inc. All rights reserved.
Step 1.
Insert the holder into the
slot on the safetycam
Step 2.
Place the mount and safetycam as high
as possible on the driver side of the
vehicle on the windshield such that
it does not obstruct the driver’s view
Powering the Safetycam™
The safetycam can be powered using 3 methods.
6
(888) 777-9718 | [email protected] | www.azuga.com
© 2019 Azuga, Inc. All rights reserved.
Option 1: Power through the OBD-II power cable Recommended
Option 2: Power through the CLA
−Plug the Y cable into the OBD port.
−Starting at the safetycam, lay out the power cable roughly where it will run once hidden behind the
vehicle's interior panels. This gives you an idea of where to route the cable and how much slack to leave
on the way down to the OBD port
−Route the SafetyCam power cable using the provided tool and adhesive cable holders.
oThe SafetyCam power cable can be routed:
−and tucked under the headliner.
−along the top of thewindshield.
−along the weather strip of the vehicle.
−
under the dash.
−Plug the SafetyCam power cable into one end of the Y cable, which is connected to the OBD port.
−Plug the other end of theY cable into the OBD-II device
Option 3: Power by hardwired connection
We have a 3-wire connection, which will be required to connect under the dash of the car in the way
mentioned below:
RED wire - this must be connected to the hot wire or battery.
BLACK wire - this must be the ground wire
YELLOW wire - this must be connected to either the fuse box or the ignition line.
(We recommend connecting to the fuse box.)
−Plug one end of the USB cable in the SafetyCam
−Route the SafetyCam power cable using the provided tool and adhesive cable holders.
oThe SafetyCam power cable can be routed:
−and tucked under the headliner.
−along the top of thewindshield.
−along the weather strip of the vehicle.
−
under the dash.
−Plug the other end of SafetyCam power cable into the Cigarette Lighter Adapter
Verify SafetyCam integration on our App
ALog in to Azuga Fleet and Navigate to the Devices tab under
Admin.
BNavigate to the SafetyCam tab under the Devices tab
CSearch for your SafetyCam and click on Edit (the pencil icon)
DUpdate the associated vehicle by selecting the proper vehicle
from the dropdown list.
Safetycam
(In Packages with SafetyCam and OBD bundled together, the SafetyCam & your OBD comes
automatically paired out of the box. In case you have changed the pairing of the OBD device &
SafetyCam you can follow these steps to update the associated vehicle in Azuga’s system.)
7
(888) 777-9718 | [email protected] | www.azuga.com
© 2019 Azuga, Inc. All rights reserved.
Watch your Videos Anytime, Anywhere
On the Azuga Fleet Web & Mobile Apps
(under the SafetyCam Tab)
SAFETYCAM
SafetyCamSafetycam
