Axis Q6055-S Manuel utilisateur

AXISQ6055-SPTZDomeNetworkCamera

InstallationGuide

AXISQ6055-SPTZDomeNetworkCamera

Packaecontents

•AXISQ6055-SPTZDomeNetworkCamera

•AXIST8607MediaConverterSwith

•Multiable(IP66),7m(23ft)

•DINraillip

•Printedmaterials

-InstallationGuide(thisdoument)

-Extraserialnumberlabel(2x)

-AVHSAuthentiationkey

AXISQ6055-SPTZDomeNetworkCamera

Hardwareoverview

Forspeiationsofthehardwareomponents,seeTechnicalspecicationsonpage19.

NO NO

NOTICE TICE

TICE

Makesurethedomeisattahedinoperationmode,otherwisefousmaybeaffeted.

1Pressurereliefvalve

2Multiconnector

3Hookforsafetwire

4Inletvalve

5Mountinghole(3x)

6Partnumber(P/N)&Serialnumber(S/N)

7Dome

8SDcardslot(SDHC)

9StatusLEDindicator

10Controlbutton

AXISQ6055-SPTZDomeNetworkCamera

1Domeattachmentring

2O-ring

3DomebracketscrewT20(4x)

4Dome

5O-ring

6Domering

7DomeringscrewT25(4x)

AXISQ6055-SPTZDomeNetworkCamera

1Powerconnector(DCinput)

2Powerconnector(DCoutput)

3Networkconnector(internal)

4NetworkconnectorSFP(external)(2x)

5NetworkconnectorRJ45(external)(2x)

6CameranetworkLEDindicator

7NetworkLEDindicator(4x)

8PowerLEDindicator

9Groundclip

10I/Oconnector(internal)

11I/Oconnector(external)

12Multicable

13Groundscrew

AXISQ6055-SPTZDomeNetworkCamera

Howtoinstalltheproduct

Readalltheinstrutionsbeforeinstallingtheprodut.Someinstallationstepswouldbenetfrom

beingompletedtogetherbeausetheyrequireremovalofthedomeover.

NO NO

NOTICE TICE

TICE

•Duetoloalregulationsortheenvironmentalandeletrialonditionsinwhihthe

produtistobeused,ashieldednetworkable(STP)maybeappropriateorrequired.

Allablesonnetingtheproduttothenetworkandthatareroutedoutdoorsorin

demandingeletrialenvironmentsshallbeintendedfortheirspeiuse.Makesurethat

thenetworkdeviesareinstalledinaordanewiththemanufaturer’sinstrutions.For

informationaboutregulatoryrequirements,seeRegulatorinformationonpage32.

•Mounttheprodutwiththedomeoverfaingdownward.

•Bearefulnottosrath,damageorleavengerprintsonthedomeoverbeausethis

oulddereaseimagequality.Ifpossible,keeptheprotetiveplastionthedomeover

untiltheinstallationisomplete.

Theprodutanbemountedwiththeablesroutedthroughoralongthewallorroof.

Recommendedtools

NO NO

NOTICE TICE

TICE

Stainlesssteelisorrosion-resistant,butextraneousrustanappearifthematerialis

handledinorretly.Usestainlesstoolstoavoidruststainsorpittingorrosion.

•Torx®srewdriverT10(lid,ablelamping,mediaonverterswith)

•Cableshoepliers(groundable,mediaonverterswith)

•7mmwrenh(groundsrew,mediaonverterswith)

•Slottedsrewdriver2.5mm(soket,mediaonverterswith)

•Torx®srewdriverT20(domeoverremoval)

•Torx®srewdriverT25(domereplaement)

•8mm(5/16”)wrenh/soket(hoselamp,AXIST91C67PoleBraket)

•10mm(3/8”)wrenh/soket(braketadapterAXIST91C61,AXIST94S01D,AXIST91C67

PoleBraket)

•Diagonalpliers(ables)

•Wirestrippingtool(ableonneting)

AXISQ6055-SPTZDomeNetworkCamera

Howtoreplacethedomecover(optional)

Thepremountedleardomeoveranbereplaedifyouwanttouseasmokeddomeoverorifthe

domeoverissrathedordamaged.Smokeddomeoversandspareleardomeoversanbe

purhasedfromyourAxisreseller.

UsetheInstallationGuidedeliveredwiththedomeover.

HowtoinstallanSDcard

InstallinganSDardisoptional.AstandardorhighapaitySDard(notinluded)anbeusedto

storereordingsloallyintheprodut.

1.Loosenthedomeringsrewsandremovethedomeover.

2.InsertanSDardintotheSDardslot.

3.Attahthedomeovertothetopoverandtightenthesrews(torque3.2Nm).

Howtopressurizethecamera(recommended)

TheamerahousinganbelledwithNitrogengastopreventondensation.

Thellingproessisrepeatedthreetimes,releasingthepressurebetweenllings,tomakesurethat

allairandhumidityispurgedfromthehousing.

Note

Theamerahousinghasanpressurereliefvalvethatlimitsthellingpressureto0.5bar

(7psi).Duringnormalusethepressureinsidetheamerahousingmaydropbelowthat

pressure.Forfullprotetionmakesurethatthepressureisabove0.2bar(3psi).

1.Settheregulatorgaugeonthegasylinderto0.5bar(7psi).

2.Removetheapsfromtheinletvalveandthepressurereliefvalve.

3.Plaethehukontheinletvalveandpressdowntolltheamerawithnitrogen.

4.Whenthepressureinsidetheamerahousingreahes0.5bar(7psi)thepressurerelief

valvewillopen.Plaeyourhandoverthepressurereliefvalvetoverifythatthegas

isowingout.

5.Liftthepressurereliefvalvetolettheoverpressureoutoftheameraunit.

6.Repeatthellingproessatotalof3times,leavingthetheamerapressurizedthe

lasttime.

7.Puttheapsbakontheinletvalveandthepressurereliefvalve.

AXISQ6055-SPTZDomeNetworkCamera

HowtoinstallAXIST860MediaConverterSwitch

Thesuppliedmediaonverterswithenablesthemultiabletosendpowerfromthepowersupply

(soldseparately)andtosendandreeivedatatoandfromexternalalarmdeviesandthenetwork.

NO NO

NOTICE TICE

TICE

•Makesuretheonnetionstothemainssupplyandonduitshavebeeninstalledbya

trainedprofessional,aordingtothemanufaturer’sinstrutionsandinompliane

withloalregulations.

•Thepowersupply(soldseparately)andthemediaonverterswithshallbeinstalledinan

environmentprotetedagainstdustandwater,forexampleindoorsorinanappropriate

abinet.

Important

Axisanonlyguaranteefullfuntionalitywiththesuppliedmediaonverterswith.No

otherdeviesaresupported.

1.Makesurethemainssupplyisswithedoff.

2.Mountthepowersupplyandthemediaonverterswithonthewallor,ifappliable,

attahthemtoaDINrailintheabinet.Ifdrillingisrequired,makesuretousedrillbits,

srews,andplugsthatareappropriateforthematerial.

3.Loosenthesrewsandremovetheoverfromthemediaonverterswith.

1Screw(2x)

2Cover

3Mediaconverterswitch

4.Stripoff40mm(1.57in)ofthemultiablejaket.

AXISQ6055-SPTZDomeNetworkCamera

5.Leavethebraidedshieldintatandfoldbakthebraidedshield.

6.Cutoffabout7–8mm(0.27–0.32in)oftheEthernetwirefoilshields.

7.Stripoffabout4–5mm(0.16–0.20in)ofthepowerwirejakets.

1Multicablejacket

2Braidedshield

3Ethernetwirefoilshield(2x)

8.ConnetthenetworkandI/OwirestotheinternalnetworkandI/Oonnetors.Open

thelid,insertthewiresandlose.

9.Connetthegroundandpowerwirestothepoweronnetor(DCoutput).
