Axis P9106-V Manuel utilisateur

AXISP9106-VNetworkCamera

UserManual

AXISP9106-VNetworkCamera

TableofContents

Solutionoverview...........................................3

Productoverview...........................................4

Findthedeviceonthenetwork................................5

Additionalsettings..........................................6

Needmorehelp?................................................6

Imagequality...................................................6

Overlays.......................................................8

Streamingandstorage...........................................9

Events........................................................2

Applications....................................................3

Addaudio.....................................................3

Troubleshooting............................................5

Resettofactorydefaultsettings...................................5

Checkthecurrentrmware.......................................5

Upgradethermware............................................5

Technicalissues,cluesandsolutions................................6

Performanceconsiderations.......................................7

Specications..............................................9

LEDIndicators..................................................9

SDcardslot....................................................9

Buttons.......................................................9

Connectors....................................................9

AXISP9106-VNetworkCamera

Solutionoeriew

AXISP9106-VNetworkCamera

Productoeriew

1StatusLED

2microSDcardslot

3Focusring

4Controlbutton

5Networkconnector(PoE

AXISP9106-VNetworkCamera

Findthedeiceonthenetwork

TondAxisdevicesonthenetworkandassignthemIPaddressesinWindows®,useAXISIPUtilityorAXISDeviceManager.Both

applicationsarefreeandcanbedownloadedfromaxis.com/support.

FormoreinformationabouthowtondandassignIPaddresses,seethedocumentHowtoassignanIPaddressandaccessyour

deviceonthedevicepageataxis.com.

Accessthedevice

.OpenabrowserandentertheIPaddressorhostnameoftheAxisdevice.

IfyouhaveaMaccomputer(OSX),gotoSafari,clickBonjourandselectthedevicefromthedrop-downlist.Toadd

Bonjourasabrowserbookmark,gotoSafari>Preferences.

IfyoudonotknowtheIPaddress,useAXISIPUtilityorAXISDeviceManagertondthedeviceonthenetwork.

2.Entertheusernameandpassword.Ifyouaccessthedeviceforthersttime,youmustsettherootpassword.SeeSeta

newpasswordfortherootaccountonpage5.

3.Theliveviewpageopensinyourbrowser.

Secureasswords

Important

Axisdevicessendtheinitiallysetpasswordincleartextoverthenetwork.Toprotectyourdeviceaftertherstlogin,set

upasecureandencryptedHTTPSconnectionandthenchangethepassword.

Thedevicepasswordistheprimaryprotectionforyourdataandservices.Axisdevicesdonotimposeapasswordpolicyasthey

maybeusedinvarioustypesofinstallations.

Toprotectyourdatawestronglyrecommendthatyou:

•Useapasswordwithatleast8characters,preferablycreatedbyapasswordgenerator.

•Don’texposethepassword.

•Changethepasswordatarecurringinterval,atleastonceayear.

Setanewasswordfortherootaccount

Important

Thedefaultadministratorusernameisroot.Ifthepasswordforrootislost,resetthedevicetofactorydefaultsettings.

.Typeapassword.Followtheinstructionsaboutsecurepasswords.SeeSecurepasswordsonpage5.

2.Retypethepasswordtoconrmthespelling.

3.ClickCreatelogin.Thepasswordhasnowbeencongured.

AXISP9106-VNetworkCamera

Additionalsettings

Needmorehel?

Youcanaccessthebuilt-inhelpfromthedevice’swebpage.Thehelpprovidesmoredetailedinformationonthedevice’sfeaturesand

theirsettings.

Imagequality

Selectexosuremode

Therearedifferentexposuremodeoptionsinthecamerathatadjustsaperture,shutterspeed,andgaintoimproveimagequalityfor

specicsurveillancescenes.GotoSettings>Image>xposureandselectbetweenthefollowingexposuremodes:

•Formostusecases,selectAutomaticexposure.

•Forenvironmentswithcertainarticiallighting,forexampleuorescentlighting,selectFlicker-free.

•Forenvironmentswithcertainarticiallightandbrightlight,forexampleoutdoorswithuorescentlightingatnightand

sunduringdaytime,selectFlicker-reduced.

•Tolockthecurrentexposuresettings,selectHoldcurrent.

Viewarea

Aviewareaisacroppedpartofthefullview.Youcanstreamandstoreviewareasinsteadofthefullviewtominimizebandwidth

andstorageneeds.IfyouenablePTZforaviewarea,youcanpan,tiltandzoomwithinit.Byusingviewareasyoucanremoveparts

ofthefullview,forexample,thesky.

Whenyousetupaviewarea,werecommendyoutosetthevideostreamresolutiontothesamesizeasorsmallerthantheviewarea

size.Ifyousetthevideostreamresolutionlargerthantheviewareasizeitimpliesdigitallyscaledupvideoaftersensorcapture,

whichrequiresmorebandwidthwithoutaddingimageinformation.

Privacymasks

Aprivacymaskisauser-denedareathatpreventsusersfromviewingapartofthemonitoredarea.Inthevideostream,privacy

masksappearasblocksofsolidcolor.

You’llseetheprivacymaskonallsnapshots,recordedvideo,andlivestreams.

YoucanusetheVAPIX®applicationprogramminginterface(API)toturnofftheprivacymasks.

Important

Ifyouusemultipleprivacymasksitmayaffecttheproduct’sperformance.

AXISP9106-VNetworkCamera

Additionalsettings

Hideartsoftheimagewithrivacymasks

Youcancreateoneorseveralprivacymaskstohidepartsoftheimage.

.GotoSettings>Privacymask.

2.ClickNew.

3.Adjustthesize,color,andnameoftheprivacymaskaccordingtoyourneeds.

Imrovefacialrecognition

Tobetterrecognizethefaceofapersonpassingbythecamera,youcansettheoptimalpixelresolutionwiththecamera’spixel

counter.

.GotoSettings>System>Orientationandclick.

2.Inthecamera’sliveview,adjustthesizeandplacementoftherectanglearoundtheareaofinterest,forexample,where

thefacesofpassingpersonsareexpectedtoappear.Youcanthenseethenumberofpixelsrepresentedbythesidesof

therectangle.

Note

Youcanuseanobjectofaknownsizeintheviewasareferencetodecidehowmuchresolutionisneededforrecognition.

Reducenoiseinlow-lightconditions

Toreducenoiseinlow-lightconditions,youcanadjustoneormoreofthefollowingsettings:

•Settheexposuremodetoautomatic.

Note

Ahighmaxshuttervaluecanresultinmotionblur.

•Toslowdowntheshutterspeed,setmaxshuttertothehighestpossiblevalue.

•Reducesharpnessintheimage.

Handlesceneswithstrongbacklight

Dynamicrangeisthedifferenceinlightlevelsinanimage.Insomecasesthedifferencebetweenthedarkestandthebrightest

areascanbesignicant.Theresultisoftenanimagewhereeitherthedarkorthebrightareasarevisible.Widedynamicrange

(WDR)makesbothdarkandbrightareasoftheimagevisible.

AXISP9106-VNetworkCamera

Additionalsettings

.GotoSettings>Image>Widedynamicrange.

2.Ifrequired,turnonWDR.

ImagewithoutWDR.

ImagewithWDR.

Note

WDRmaycauseartifactsintheimage.

FindoutmoreaboutWDRandhowtouseitataxis.com/web-articles/wdr.

Maximizedetailsinanimage

Important

Ifyoumaximizedetailsinanimage,thebitratewillprobablyincreaseandyoumightgetareducedframerate.

•Makesuretoselectthecapturemodethathasthehighestresolution.

•Setthecompressionaslowaspossible.

•SelectMJPEGstreaming.

•TurnoffZipstreamfunctionality.

Overlays

Overlaysaresuperimposedoverthevideostream.Theyareusedtoprovideextrainformationduringrecordings,suchasatimestamp,

orduringproductinstallationandconguration.Youcanaddeithertextoranimage.

Showatextoverlayinthevideostreamwhenthedevicedetectsmotion

Thisexampleexplainshowtodisplaythetext“Motiondetected”whenthedevicedetectsmotion:

AXISP9106-VNetworkCamera

Additionalsettings

MakesurethatAXISVideoMotionDetectionisrunning:

.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.

Addtheoverlaytext:

4.GotoSettings>Overlay.

5.Enter#Dinthetexteld.

6.Choosetextsizeandappearance.

Createarule:

7.GotoSystem>vents>Rulesandaddarule.

8.Typeanamefortherule.

9.Inthelistofconditions,selectAXISVideoMotionDetection.

0.Inthelistofactions,selectUseoverlaytext.

.Selectaviewarea.

2.Type“Motiondetected”.

3.Settheduration.

4.ClickSave.

Streamingandstorage

Bitratecontrol

Withbitratecontrol,youcanmanagethebandwidthconsumptionofyourvideostream.

Variablebitrate(VBR)

Withvariablebitrate,thebandwidthconsumptionvariesbasedonthelevelofactivityinthescene.Themoreactivityinthescene,

themorebandwidthyouneed.Youareguaranteedconstantimagequalitybutitrequiresstoragemargins.

kbit/s

Maximumbitrate(MBR)

Withmaximumbitrate,youcansetatargetbitratetohandlebitratelimitationsinyoursystem.Youmayseeadeclineinimage

AXISP9106-VNetworkCamera

Additionalsettings

qualityorframeratewhentheinstantaneousbitrateiskeptbelowthespeciedtargetbitrate.Youcanchoosetoeitherprioritize

imagequalityorframerate.Werecommendthatyoucongurethetargetbitratetoahighervaluethantheexpectedbitrate.This

givesyouamarginforadditionalcomplexitythatneedstobecaptured.

kbit/s

1Targetbitrate

Averagebitrate(ABR)

Withaveragebitrate,thebitrateisautomaticallyadjustedoveralongertimescale.Thisissoyoucanmeetthespeciedtargetand

providethebestvideoqualitybasedonyouravailablestorage.Bitrateishigherinsceneswithalotofactivity,comparedtostatic

scenes.Youaremorelikelytogetbetterimagequalitywhenneededwhenusingtheaveragebitrateoption.Youcandenethetotal

storagerequiredtostorethevideostreamforaspeciedamountoftime(retentiontime)whenimagequalityisadjustedtomeetthe

speciedtargetbitrate.Specifytheaveragebitratesettingsinoneofthefollowingways:

•Tocalculatetheestimatedstorageneed,setthetargetbitrateandtheretentiontime.

•Tocalculatetheaveragebitrate,basedonavailablestorageandrequiredretentiontime,usethetargetbitratecalculator.

kbit/s

1Targetbitrate

2Actualaveragebitrate

Youcanalsoturnonmaximumbitrateandspecifyatargetbitratewithintheaveragebitrateoption.
