INSTALLATION GUIDE
AXIS T91A61 Wall Mount
AXIS T91A62 Parapet Mount
AXIS T91A63 Ceiling Mount
AXIS T91A64 Corner Mount
AXIS T91A67 Pole Mount
ENGLISH DEUTSCH ITALIANO ESPAÑOL
FRAN
Ç
AIS
About this Document
This document includes instructions for installing the
AXIS T91A Mounting Accessories.
Equipment Modifications
This equipment must be installed and used in strict
accordance with the instructions given in the user
documentation.
Liability
Every care has been taken in the preparation of this
document. Please inform your local Axis office of any
inaccuracies or omissions. Axis Communications AB
cannot be held responsible for any technical or
typographical errors and reserves the right to make
changes to the product and documentation without
prior notice. Axis Communications AB makes no
warranty of any kind with regard to the material
contained within this document, including, but not
limited to, the implied warranties of merchantability
and fitness for a particular purpose. Axis
Communications AB shall not be liable nor responsible
for incidental or consequential damages in connection
with the furnishing, performance or use of this material.
Support
Should you require any technical assistance, please
contact your Axis reseller. If your questions cannot be
answered immediately, your reseller will forward your
queries through the appropriate channels to ensure a
rapid response. If you are connected to the Internet, you
can:
• find answers to resolved problems in the FAQ database.
Search by product, category, or phrases
• report problems to Axis support by logging in to your
private support area.
AXIS T91A Series Installation Guide Page 3
ENGLISH
AXIS T91A Mounting Accessories
This installation guide provides instructions for installing the wall/parapet/ceiling/corner/pole
mounting accessories for Axis network cameras. For all other aspects of using the Axis network
camera, please see the Installation Guide and User’s Manual, available from www.axis.com
Installation steps
1. Check the package contents against the list below
2. Hardware overview. See page 4
3. Install the hardware:
•
Install the AXIS T91A61 Wall Mount, see page 6
•
Install the AXIS T91A62 Parapet Mount, see page 7
•
Install the AXIS T91A63 Ceiling Mount, see page 9
•
Install the AXIS T91A64 Corner Mount, see page 11
•
Install the AXIS T91A67 Pole Mount, see page 12
Package contents
Model Item
AXIS T91A61 Wall Mount Wall bracket
Bracket holder
AXIS T91A62 Parapet Mount Parapet bracket
Bracket holder
AXIS T91A63 Ceiling Mount Ceiling bracket
Bracket holder
AXIS T91A64 Corner Mount Corner bracket (AXIS T91A61 required)
4 M8x22 screws
AXIS T91A67 Pole Mount Pole bracket
Steel straps (steel strap tool not supplied)
Important!
This product must be used in
compliance with local laws and
regulations.
Page 4 AXIS T91A Series Installation Guide
Hardware overview
Side cover
(remove for cable)
Torx T30 screws (4)
Pendant adapter
Parapet bracket
Side cover
Secure nut
Torx T30 screws (4)
Pendant adapter
(remove for cable)
Ceiling bracket
Side cover
(remove for cable)
Torx T30
Pendant adapter
screws (4)
AXIS T91A Series Installation Guide Page 5
ENGLISH
Note:
Some installations may require the supplied pendant adapter to be replaced which is done
by loosening the stop screw and unscrewing the adapter. In this case, refer to the Installa-
tion Guide included with the pendant kit.
Pole bracket
Steel straps
(requires steel strap
Corner mount bracket
Screw hole (top)
Mounted
this way up
Torx T30 screws (3)
Slots for
unit holders (3)
Safety wire
Stop screw
Pendant adapter
Pendant adapter
tool - not supplied)
Holes for
mounting
screws (6)
Metal tabs
for temporary
Bracket holder
support (4)
Locking tab
This way up
(when mounting
on wall)
Page 6 AXIS T91A Series Installation Guide
Install the Hardware
Install the AXIS T91A61 Wall Mount
1. Refer to
Hardware overview,
on page 4 for information on the supplied
parts.
2. Route the network cable through or along the wall.
3. Attach the bracket holder in the desired position using screws that are
appropriate for the wall material and the weight of the camera and
bracket.
4. The wall bracket can temporarily be hooked on the bracket holder, in order to easily route the
cable through the bracket:
5. Route the necessary cables through the wall bracket, securing them in the cable holder.
6. Pull the locking tab and unhook the wall bracket from the temporary position.
7. Use the Torx screws to secure the wall bracket to the bracket holder.
8. Refer to the Installation Guide for the network camera for instructions on how to attach the
camera to the bracket.
Tabs
Swing wall bracket
to the side for
temporary support
Slide bracket between the
tabs on the bracket holder
Locking tab
Cable
Cable
holder
AXIS T91A Series Installation Guide Page 7
ENGLISH
Install the AXIS T91A62 Parapet Mount
1. Refer to
Hardware overview,
on page 4 for information on the supplied
parts.
2. Route the network cable through or along the roof.
3. Attach the bracket holder in the desired position on the roof using
screws that are appropriate for the material and the weight of the
camera and bracket. Install the bracket maximum 80 mm (3.2 in.) from
the edge of the roof for the camera’s outer diameter to be aligned with
the edge of the roof. Maximum weight allowed 15 kg (33 lbs).
4. Route the necessary cables through the parapet bracket, securing them
in the cable holder.
Install bracket holder
Cable holder
Cable
from the edge of the roof
Bracket holder
Note
: Do not use bracket holder
as a temporary support
with the parapet bracket.
max. 80 mm (3.2 in.)
Page 8 AXIS T91A Series Installation Guide
5. Use the Torx screws to secure the parapet bracket to the bracket holder.
6. Rotate the bracket and tighten the secure nut to lock the bracket in a sideways position. The
camera can now be installed safely rather than hanging over the edge of the roof. The secure
nut is loose at delivery for this purpose.
7. Refer to the Installation Guide for the network camera for instructions on how to attach the
camera to the bracket.
8. Rotate the bracket into position and tighten the secure nut firmly.
Notes:
• Some installations may require the supplied pendant adapter to be replaced, which is done by
loosening the stop screw and unscrewing the adapter. In this case, refer to the Installation Guide
included with the pendant kit.
Secure nut
Safety wire
Torx T30 screws (3)
Slots for unit holders (3)
Torx T30 screws (4)
Rotate sideways to
install camera
AXIS T91A Series Installation Guide Page 9
ENGLISH
Install the AXIS T91A63 Ceiling Mount
1. Refer to
Hardware overview,
on page 4 and page 5 for information on the
supplied parts.
2. Route the network cable through or along the ceiling.
3. Attach the bracket holder in the desired position in the ceiling using screws
that are appropriate for the ceiling material and the weight of the camera
and bracket. Maximum weight allowed 15kg (33lbs).
4. Route the necessary cables through the ceiling bracket, securing them in the cable holder.
Note
: Do not use bracket holder
as a temporary support
with the ceiling bracket.
Page 10 AXIS T91A Series Installation Guide
5. Use the Torx screws to secure the ceiling bracket to the bracket holder.
6. Refer to the Installation Guide for the network camera for instructions on how to attach the
camera to the bracket.
Torx screws(4)
