AXIS 540/640

User’s Printing Guide

Ethernet and Token Ring Print Servers

for

NetWare •Windows •OS/2 • Unix • Macintosh

User’s Printing Guide

This guide covers the procedures needed to setup your workstation

for printing through the AXIS 540/640 network print server, once it

has been properly installed. If you need further assistance, please ask

your Network Administrator or refer to the AXIS 540/640 User’s

Manual, or the AXIS 540/640 Quick Installation Guide.

AXIS 540/640 makes printing easier

The AXIS 540/542 and AXIS 640/642 are stand alone network print

servers for Ethernet and Token Ring environments respectively.

Using the AXIS 540/640 makes it possible to connect your printers

anywhere in the network, giving all users access to shared printer

resources.

The AXIS 540/640 plugs directly in to your printer and makes it

appear as a normal printer when printing from your workstation.

Your Network Administrator will have given this printer a name

during the installation of the AXIS 540/640. You will need this

name when making your printer selection.

Fast and easy to use

You will find that printing via the AXIS 540/640 is very fast due to

its rapid data throughput of up to 390 kbytes per second. Also high

speed Centronics communication, such as Hewlett-Packard Fast

Mode, is supported.

The AXIS 540/640 is extremely user friendly, because of its powerful

built in features. It can communicate with all the major computer

systems and network protocols. These different protocols can be

handled simultaneously making the AXIS 540/640 the ideal print

server solution for a mixed environment.

Unix

Choose the print instruction appropriate to your type of system:

BSD systems: lpr -P<printer name> <file name>

System V systems: pr -d<printer name> <file name>

AIX systems: qprt -P<printer name> <file name>

Your NetworkAdministrator will be able to supply you with the

name of the printer that is suitable forthe type of file you wish to

print.

Windows

To print via the AXIS 540/640 from Windows 3.1, Windows for

Workgroups, Windows 95 or Windows NT, proceed as follows:

1. Select Print... from the File menu within your application. If the

printer you want to use is the default printer, just proceed with

printing from your application as normal.

2. If the required printer is not selected as default, select the name

of the required printer in the Print dialogue box; the name that

was assigned during installation. The Network Administrator

will supply you with the printer name.

3. Set up any of the parameters as needed, e.g. paper size, and then

click OK.

You may now proceed with printing.

OS/2

To print via the AXIS 540/640 from an OS/2 workstation, proceed

as follows:

1. Select Print... from the File menu within your application.

2. In the Print Document window, select the Queue name for the

required printer. Your Network Administrator will supply you

with the name.

You may now proceed with printing.

Macintosh

Open the Chooser window by selectingChooser in the Apple menu.

Follow these steps to choose a printer:

1. Click on the LaserWriter (or LaserWriter 8.0) Icon.

2. If your network has more than one zone, click the name of the

default zone.

3. Click the name of the printer you want. Your Network

Administrator will supply you with the printer name.

4. For LaserWriter 8.0 printer driver only:

Click Setup..., and then click Auto Setup. If the printer, just as

the print server, supports bi-directional printing the installation

will then be automatically performed. If not, you will be

prompted to select a PPD file matching your printer, then click

OK.

5. Click the close box. This completes the selection of a printer and

you may now print from within applications as normal.

Axis Communications AB

Scheelevägen 16, S-223 70 Lund, Sweden

Phone: +46 46 19 18 00 Fax: +46 46 13 61 30

Email: info@axis.seURL: http://www.axis.se/

Axis Communications Inc.

4 Constitution Way, Suite G, Woburn, MA 01801-1030, USA

Phone: (617) 938-1188, 1-800-444-AXIS

Fax: (617) 938-6161 Email: info@axisinc.com

Axis Communications K.K.

8th Center Plaza 5F, 1-10-16 Nihombashi Horidome-cho,

Chuo-ku, Tokyo 103, Japan

Phone: +81 3 3663 8801 Fax: +81 3 3663 8802

Email: info@axiscom.co.jp

Axis Communications Ltd.

Room 602, Asian House, 1 Hennessy Road,

Wanchai, Hong Kong

Phone: +852 2836 0813 Fax: +852 2573 5935

Email: info@axis.com.hk

AXIS 540/640 User’s Printing Guide

Part No: 14678

Revision: 1.0, Date: May 1996
