Axis T8144 Manuel utilisateur

AXIST814460WIndustrialMidspan

UserManual

AXIST814460WIndustrialMidspan

TableofContents

Systemoverview............................................3

Productoverview...........................................4

Specications..............................................5

LEDindicators..................................................5

Operatingconditions.............................................5

Powerinputandoutput..........................................5

Ethernetinterface...............................................5

Connectors....................................................6

Troubleshooting............................................7

AXIST814460WIndustrialMidspan

Systemovervie

AXIST814460WIndustrialMidspan

Productovervie

AXIST814460WIndustrialMidspan

Speciﬁcations

Tondthelatestersionoftheproduct’sdatasheet,gotoaxis.com>[product]>Support&Documentation.

LEDindicators

Note

SeeLEDlocationsinProductoverviewonpage4.

LEDColor,statusIndication

OffNopowersourceconnectedtoPWR1input.

PWR1

Green,staticPowersourceconnectedtoPWR1input.

OffNopowersourceconnectedtoPWR2input.

PWR2

Green,staticPowersourceconnectedtoPWR2input.

OffPoweraailableonbothPWR1andPWR2inputs.

ALARM

Red,staticNopoweraailableonPWR1orPWR2oroneitherinputs.

OffNoremotedeiceconnectedtoDATA&PWROUTport.

Green,blinkingRemotedeiceconnectedtoDATA&PWROUTportbutPoEnegotiation

hasfailed.

PoE

Green,staticRemotedeiceconnectedtoDATA&PWROUTportandPoEnegotiation

hassucceeded.

Operatinconditions

Temperatureumidity

-40°Cto75°C(-40°Fto167°F)10–95%RH(non-condensing)

Powerinputandoutput

Inputoltage20–60VDC

Maximuminputpower72W

Nominaloutputoltage55VDC

Maximumoutputpower

(HighPoweroerEthernet)

60W

Ethernetinterface

Note

SeeEthernetportlocationsinProductoverviewonpage4.

AXIST814460WIndustrialMidspan

Speciﬁcations

FunctionSpecication

DATAIN

Ethernet10/100/1000Base-T

RJ45femalesocket

DATA&PWROUT

Ethernet10/100/1000Base-T,55VDC

RJ45femalesocket,withDColtageonwirepairs

1–2,3–6,4–5and7–8

Connectors

6-pinDCpowerandalarmterminalconnector

Note

Seetheconnector’spinarrangementinProductoverviewonpage4.

FunctionPinDescriptionSpecication

1Ground0VDC

PWR2

2Powerinfrompowersupply20–60VDC

ALARM3–4RelaycontactCircuitopen(alarmon)

Circuitclosed(alarmoff)

5Ground0VDC

PWR1

6Powerinfrompowersupply20–60VDC

AXIST814460WIndustrialMidspan

Troubleshooting

SymptomCorrectiveaction

Verifythatthepowersourceoltageisbetween20–60VDC,andthatit’sworking.

Verifythattheterminalblockconnectorisproperlyconnected.

Themidspandoesnotpowerup

Verifythatthepowerinletcableisintact/functional.

VerifythattheremotedeiceisdesignedforPoEoperation.

Verifythattheremotedeiceisconnectedtothemidspan’sDATA&PWROUTportusing

astandardSTPCAT5orhigher,straight-wirednetworkcablewithfourpairs.

Ifanexternalpowersplitterisinuse,erifythatitworks.

VerifythatthereisnoshortcircuitonanyofthetwistedpaircablesorRJ45connectors.

Theremotedeiceconnectedtothe

midspandoesnotpowerup

Ifpossible,connecttheremotedeicetoadifferentmidspan.

Verifythattheremotedeiceisconnectedtothemidspan’sDATAINportusinga

standardSTPCAT5orhigher,straight-wirednetworkcablewithfourpairs.

IfusinganEthernetRJ45cable,erifythatitslengthbetweenthenetworkswitchand

theremotedeiceislessthan100m(330ft).

Theremotedeiceconnectedtothe

midspanpowersupbutthereisno

datalink

Ifpossibleconnecttheremotedeicetoadifferentmidspan.

UserManualVer.M1.5

AXIST814460WIndustrialMidspanDate:July2017

©AxisCommunicationsAB,2017PartNo.1743994
