AXIOMTEK GOT-3100T Manuel utilisateur

GOT-3100T/3100TL/3108T

All-in-One

10.4” TFT SVGA Fanless Touch Panel

Computer

User’s Manual

Disclaimers

The information in this manual has been carefully checked and is believed to

be accurate. AXIOMTEK Co., Ltd. assumes no responsibility for any

infringements of patents or other rights of third parties, which may result from

its use.

AXIOMTEK assumes no responsibility for any inaccuracies that may be

contained in this document. AXIOMTEK makes no commitment to update or

to keep current the information contained in this manual.

AXIOMTEK reserves the right to make improvements to this document and/or

product at any time and without notice.

No part of this document may be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means, electronic, mechanical,

photocopying, recording, or otherwise, without the prior written permission of

AXIOMTEK Co., Ltd.

February 2006, Version A1

Printed in Taiwan

iii

Safety Approvals

CE Marking

FCC Class A

FCC Compliance

This equipment has been tested and complies with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. If not installed and used in

accordance with proper instructions, this equipment might generate or

radiate radio frequency energy and cause harmful interference to

radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measurers:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for

help.

Shielded interface cables must be used in order to comply with

emission limits.ou

Safety Precautions

Before getting started, read the following important cautions.

1. The GOT-3100T/3100TL/3108T does not come equipped with

an operating system. An operating system must be loaded first

before installing any software into the computer.

2. Be sure to ground yourself to prevent static charge when

installing the internal components. Use a grounding wrist strap

and place all electronic components in any static-shielded

devices. Most electronic components are sensitive to static

electrical charge.

3. Disconnect the power cord from the

GOT-3100T/3100TL/3108T before making any installation. Be

sure both the system and the external devices are turned OFF.

Sudden surge of power could ruin sensitive components.

Make sure the GOT-3100T/3100TL/3108T is properly

grounded.

4. The brightness of the flat panel display decreases with usage.

However, hours of use vary depending on the application

environment.

5. Turn OFF the system power before cleaning. Clean the

system using a cloth only. Do not spray any liquid cleaner

directly onto the screen. The GOT-3100T/3100TL/3108T may

come with or w/o a touchscreen. Although the touchscreen is

chemical resistant, it is recommended that you spray the liquid

cleaner on a cloth first before wiping the screen. In case your

system comes without the touchscreen, you must follow the

same procedure and not spray any cleaner on the flat panel

directly.

6. Avoid using sharp objects to operate the touchscreen.

Scratches on the touchscreen may cause malfunction or

internal failure to the touchscreen.

7. The flat panel display is not susceptible to shock or vibration.

When assembling the GOT-3100T/3100TL/3108T, make sure

it is securely installed.

8. Do not open the system’s back cover. If opening the cover for

maintenance is a must, only a trained technician is allowed to

do so. Integrated circuits on computer boards are sensitive to

static electricity. To avoid damaging chips from electrostatic

discharge, observe the following precautions:

9Before handling a board or integrated circuit, touch an

unpainted portion of the system unit chassis for a few seconds.

This will help to discharge any static electricity on your body.

9When handling boards and components, wear a

wrist-grounding strap, available from most electronic

component stores.

Trademarks Acknowledgments

AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.

IBM, PC/AT, PS/2, VGA are trademarks of International

Business Machines Corporation.

Intel and Pentium are trademarks of Intel Corporation.

MS-DOS, Microsoft C and QuickBASIC are trademarks of

Microsoft Corporation.

VIA is a trademark of VIA Technologies, Inc.

SST is a trademark of Silicon Storage Technology, Inc.

UMC is a trademark of United Microelectronics Corporation.

Other brand names and trademarks are the properties of their

respective owners.

This page does not contain any information.

Table of Contents vii

Table of Contents

Disclaimers........................................................................... ii

Safety Approvals................................................................iii

Safety Precautions ............................................................. iv

C h a p t e r 1.....................................................................1

Introduction ..........................................................................1

1.1 General Description................................................1

1.2 Specifications..........................................................2

1.2.1 Main CPU Board...................................................... 2

1.2.2 I/O System............................................................... 2

1.2.3 System Specification.............................................. 3

1.3 Dimensions..............................................................4

1.4 I/O Outlets................................................................4

1.4 I/O Outlets................................................................5

1.5 Package List ............................................................6

C h a p t e r 2.....................................................................7

Hardware Installation.........................................................7

2.1 HDD Installation ......................................................7

2.2 CF card Installation.................................................9

2.3 Wireless Card Installation....................................10

2.4 3 x Serial Ports......................................................12

2.5 VGA ........................................................................14

2.6 Ethernet..................................................................14

2.7 Mountings: Panel / Wall / Desktop / VESA..........15

2.7.1 VESA-ARM/Wall-Mount........................................... 15

2.7.2 Desktop Kit Assembly ............................................. 16

2.7.3 Panel-mount Kit Assembly ..................................... 17

C h a p t e r 3......................................................................18

Driver Installation .............................................................18

3.1 Touch Screen ........................................................18

Table of Contents

viii

3.1.1 Driver Installation- Windows 2000/XP.................... 19

3.2 Embedded O.S.........................................................22

3.2.1 Windows XP Embedded.......................................... 22

3.2.2 Windows CE.NET 5.0 ................................................ 22

GOT-3100T/3100TL/3108TT User’s Manual

Introduction 1

C h a p t e r 1

Introduction

This chapter contains the general information and the detail

specifications of the GOT-3100T/3100TL/3108T. Chapter 1 includes

the following sections:

General Description

System Specification

Dimensions

I/O Outlets

Utilities Supported

Package List

1.1 General Description

The GOT-3100T/3100TL/3108T is a fan-less and compact-size touch

panel computer, and is equipped with a 10.4" TFT LCD display and

low power consumption CPU, Celeron M 1GHz/0K. The

GOT-3100T/3100TL/3108T supports Windows® 2000/XP, Windows®

CE.NET, Windows® XP embedded, and Linux. The panel is able to

install in a CompactFlash™ card and provides a MiniPCI slot for

wireless module.

GOT-3100T: 10.4” TFT SVGA Fanless Touch Panel Computer

w/ High brightness

GOT-3100TL: 10.4” TFT SVGA Fanless Touch Panel

Computer(Light version)

GOT-3108T: 10.4” TFT SVGA Fanless Touch Panel Computer

w/ NEMA4X Stainless Front Bezel

Reliable and Stable Design

The GOT-3100T/3100TL/3108T adopts a fan-less cooling system and

a CompactFlash™ card, which makes it especially suitable for

vibration-heavy environments, best for the transportation, ship, and

industrial machinery markets.

Embedded O.S. Supported

The GOT-3100T/3100TL/3108T not only supports Windows®2000/XP,

but also supports embedded OS, such as Windows®CE.NET, and

GOT-3100T/3100TL/3108T User’s Manual

Introduction

Windows®XP embedded. For storage device, the

GOT-3100T/3100TL/3108T supports 2.5" HDD or CompactFlash™

card.

Industrial-grade Product Design

The GOT-3100T/3100TL/3108T has an incredible design that can be

used in different industrial harsh environments.

A fuse helps prevent over-voltage for power input.

Stainless steel back chassis and Aluminum front bezel meets

the IP65/NEMA4 standard.

For connecting other devices, the GOT-3100T/3100TL/3108T

also features several interfaces: USB, Ethernet, and

RS-232/422/485.

1.2 Specifications

1.2.1 Main CPU Board

CPU: Intel® Celeron® M ULV 1GHz/0K onboard.

System Chipset: Intel® 852GM+ICH4

BIOS: Award 4Mbit with RPL/PEX LAN boot ROM,

SmartView and customer CMOS backup.

System Memory: One 200-pin DDR DIMM socket.

Maximum up to 1GB

1.2.2 I/O System

Standard I/O:

−3 x serial ports

−2xRS-232,

1 x RS-232/422/485

−2 x USB 2.0
