AXIOMTEK FDK series Manuel utilisateur

FDK Series

15” 17” 19” Flexible Display Panel PC

User’s Manual

Disclaimers

This manual has been carefully checked and believed to contain

accurate information. AXIOMTEK Co., Ltd. assumes no responsibility

for any infringements of patents or any third party’s rights, and any

liability arising from such use.

AXIOMTEK does not warrant or assume any legal liability or

responsibility for the accuracy, completeness or usefulness of any

information in this document. AXIOMTEK does not make any

commitment to update the information in this manual.

AXIOMTEK reserves the right to change or revise this document

and/or product at any time without notice.

No part of this document may be reproduced, stored in a retrieval

system, or transmitted, in any form or by any means, electronic,

mechanical, photocopying, recording, or otherwise, without the prior

written permission of AXIOMTEK Co., Ltd.

August 2010, Version A1

Printed in Taiwan

iii

Safety Approvals

CE Marking

FCC Class A

FCC Compliance

This equipment has been tested in compliance with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules. These

limits are meant to provide reasonable protection against harmful

interference in a residential installation. If not installed and used in

accordance with proper instructions, this equipment might generate or

radiate radio frequency energy and cause harmful interference to

radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following methods:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment to another outlet of a circuit that

doesn’t connect with the receiver.

4. Consult the dealer or an experienced radio/TV technician for

help.

Shielded interface cables must be used in order to comply with the

emission limits.

Safety Precautions

Before getting started, please read the following important safety

precautions.

1. The FDK does not come equipped with an operating system.

An operating system must be loaded first before installing

any software into the computer.

2. Be sure to ground yourself to prevent static charge when

installing the internal components. Use a grounding wrist

strap and place all electronic components in any static-

shielded devices. Most electronic components are sensitive

to static electrical charge.

3. Disconnect the power cord from the FDK before any

installation. Be sure both the system and external devices

are turned OFF. A sudden surge of power could ruin

sensitive components that the FDK must be properly

grounded.

4. The brightness of the flat panel display will be getting weaker

as a result of frequent usage. However, the operating period

varies depending on the application environment.

5. Turn OFF the system power before cleaning. Clean the

system using a cloth only. Do not spray any liquid cleaner

directly onto the screen. The FDK may come with or w/o a

touchscreen. Although the touchscreen is chemical resistant,

it is recommended that you spray the liquid cleaner on a

cloth first before wiping the screen. In case your system

comes without the touchscreen, you must follow the same

procedure and not spray any cleaner on the flat panel

directly.

6. Avoid using sharp objects to operate the touchscreen.

Scratches on the touchscreen may cause malfunction or

internal failure to the touchscreen.

7. The flat panel display is not susceptible to shock or vibration.

When assembling the FDK, make sure it is securely installed.

8. Do not open the system’s back cover. If opening the cover

for maintenance is a must, only a trained technician is

allowed to do so. Integrated circuits on computer boards are

sensitive to static electricity. To avoid damaging chips from

electrostatic discharge, observe the following precautions:

zBefore handling a board or integrated circuit, touch an

unpainted portion of the system unit chassis for a few

seconds. This will help to discharge any static

electricity on your body.

zWhen handling boards and components, wear a wrist-

grounding strap, available from most electronic

component stores.

Trademarks Acknowledgments

AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.

IBM, PC/AT, PS/2, VGA are trademarks of International

Business Machines Corporation.

Intel®and Atom™are registered trademarks of Intel Corporation.

MS-DOS, Microsoft C and Quick BASIC are trademarks of Microsoft

Corporation.

VIA is a trademark of VIA Technologies, Inc.

SST is a trademark of Silicon Storage Technology, Inc.

UMC is a trademark of United Microelectronics Corporation.

Other brand names and trademarks are the properties and registered

brands of their respective owners.

–

Table of Contents

Disclaimers..........................................................................ii

Safety Approvals.................................................................iii

Safety Precautions..............................................................iv

CHAPTER 1 INTRODUCTION......................................... 1

1.1General Description............................................1

1.2Specifications......................................................2

1.2.1Main CPU Board......................................................... 2

1.2.2I/O System .................................................................. 2

1.2.3System Specification .................................................. 3

1.3Product List.........................................................4

1.4Dimensions.........................................................5

1.4I/O Outlets.........................................................11

1.5Packing List ......................................................12

CHAPTER 2 HARDWARE INSTALLATION .............. 13

2.1Open and close back cover..............................13

2.2CF card Installation...........................................17

2.2Serial Ports Interface........................................19

2.3Ethernet............................................................21

2.4Openframe and VESA Mountings.....................22

2.4.1Openframe Mounting................................................ 22

2.4.2VESA Mounting......................................................... 23

2.5HDD Installation................................................24

2.6DRAM Installation.............................................26

2.7Wireless LAN Card Installation.........................28

CHAPTER 3 AMI BIOS SETUP UTILITY ..................... 32

3.1Starting .............................................................32

3.2Navigation Keys................................................32

3.3Main Menu........................................................33

3.4Advanced Menu................................................34

3.5PCI PnP Menu..................................................47

3.6Boot Menu ........................................................50

3.7Security Menu...................................................55

vii

3.8Chipset Menu....................................................57

3.9Exit Menu..........................................................62

CHAPTER 4 DRIVERS INSTALLATION ..................... 64

4.1System..............................................................64

4.2Touch Screen ...................................................65

4.2.1Specification.............................................................. 65

4.2.2Driver Installation- Windows XP ............................... 65

4.3Embedded O.S.................................................68

4.3.1Windows XP Embedded...........................................68

viii

MEMO

FDK User’s Manual

Introduction 1

CHAPTER 1

INTRODUCTION

This chapter contains general information and detailed specifications

of the FDK series. Chapter 1 includes the following sections:

General Description

Specification

Dimensions

I/O Outlets

Package List

1.1 General Description

The FDK series is an open frame touch panel computer, equipped

with a TFT LCD display and low power consumption Intel○RAtomTM

N270 1.6GHz processor with FSB 533MHz. The FDK series supports

Windows®7, Windows®XP, and Windows®XP embedded. The

panel computer is able to install a CompactFlash™card and provide

a Mini card slot for wireless module. This slim series is designed for

immediate integration and can be widely deployed in indoor kiosk,

HMI automation, and many more applications. Its slim ID can fits into

any space or encased in any chassis, this series comes with a front

panel open frame design, available currently in 15”, 17” and 19” LCD

sizes.

Other than offering above configuration advantages, this open frame

panel computer series also highlights an ultra slim profile and

compact footprint in thickness of 60mm for any space. Moreover, the

brightness adjustment knob located on the back cover makes

maintenance easier and faster. For WiFi & 3G connection, this slim

FDK series User’s Manual

Introduction

unit incorporates a Mini Card slot for expansion capability.

1.2 Specifications

1.2.1 Main CPU Board

zCPU

Intel○RAtomTM N270 1.6GHz processor with FSB 533MHz

onboard

zSystem Chipset

945GSE + ICH7M

zBIOS

America Megatrends BIOS

zSystem Memory

One 200-pin DDR2 SO-DIMM socket

Maximum memory up to 2GB

1.2.2 I/O System

zStandard I/O

Three RS-232 and one RS-232/422/485

Four USB 2.0

zEthernet

One RTL81111b Gigabit Ethernet

zAudio

One Line-out

zExpansion

One Mini card

zStorage

One slot for CF card

One SATA

zPower connector

Phoenix power connector
