1 Normal constant 240V Green is on when fully charged
2 Normal constant 240v Red is on when NOT fully charged
3 Waing for self-tesng Red is flashing slowly in 1Hz. (1 second)
4 Self-tesng is going on Green is flashing slowly in 1Hz. (1 second)
5 Quick start Self-tesng Green is flashing fast in 4Hz. (0.25 second)
6 Self-tesng Pass (90min) Red and Green flash slowly one aer the other in 0.5 Hz
(Each is on for 2 seconds)
7 Self-tesng Fail Yellow is always on
8 Baery Fault Yellow is flashing slowly in 1Hz
9 Light Source Fault Yellow is flashing quickly in 4Hz
2. Imitaon of Power-off status:
Press test buon to trigger off emergency mode.
Baery kicks in and start supplies power to the light. Release test buon and return to normal.
3. Manual Self-tesng funcons:
Press test buon 5 mes (Each within 4 seconds), the light goes into Self-tesng mode.
When the baery is Not fully charged, the Red indicator light flashes slowly.
When the baery is fully charged, the Green light flashes slowly and goes to baery discharge and emergency
mode.
Self-tesng goes on unl the baery is fully discharged, it then goes back to normal.
If the discharge period is less than 90 minutes, the Yellow indicator light is always on.
If the discharge period is more than 90 minutes, the Red and Green flash slowly one aer the other.
The Self-tesng result keeps showing for 5 days. Press test buon once and quickly to clear the
self-tesng result and goes back to normal.
If no one clears the result aer 5 days, it goes back to normal by itself.
Press the test buon again, it will show the last test result for 1mins.
Press the test buon for 2 seconds during the self-tesng period anyme to exit self-tesng, and it won’t
show any results because self-tesng is not completed.
4. Syncronising and Re-seng test date funcon:
Turn off and on the main power 4 mes (Each within 4 seconds). The annual inspecon me for all the lights
on the same circuit will be reset and go into Self-tesng mode at same No.182 days automacally. The red
indicator or green indicator (depends on the charging status) will flash quickly for 5mins.
5. Automac Self-tesng funcons:
The light goes into Self-tesng mode at No.182 days automacally. The light performs all the funcon and
displays as described in Point 3. When everything goes normal without any faults, it automacally goes back
to normal 240v status aer baery over-discharge protecon kicks-in.
6. Group Manual Self-tesng funcon:
Turn off and on the main power 6 mes (Each within 4 seconds). All the lights on the same circuit start
Self-tesng. It is the same methods and philosophies as point 3.
7. Special notes:
a). Under the automac self-tesng mode, the light will restart counng 182 days aer the baery is
fully discharged and goes back to normal 240v operaon. Manual self-tesng and Group self-tesng
do NOT affect recounng 182 days when manually exit during the tesng.
b). All self-tesng funcons needs the baery to be fully charged. When the baery is not full, the red
flashes to wait for self-tesng.
