AMR985 MOBILE INTERNET SOLUTION
Use Manual
1
Con en s
Antenna Installation.......................................................2
Installation Wa ning.......................................................5
AMR985 Basic Setup...................................................8
outer ..................................................................................................................................8
SMA T device...................................................................................................................11
Windows machine .............................................................................................................12
Connecting Avtex Television.............................................................................................13
Accessing Web-interface..................................................................................................14
SMA T Device View .........................................................................................................15
LTE / WiFi Toggle...............................................................................................................16
AM 985 Data Usage Control............................................................................................17
AM 985 e-boot / Factory eset ....................................................................................19
AMR985 Specification ................................................20
Mobile ................................................................................................................................20
Wireless .............................................................................................................................20
Power.................................................................................................................................20
Physical Specification.......................................................................................................21
Te ms and Conditions.................................................22
2
This antenna does not require a ground plane in order to operate, so
may be fitted on a metal or plastic roof panel.
Step 1
When the antenna is to be co-located with other antennas or roof mounted
equipment, try to achieve a minimum of 30cm (12”) clearance around the antenna
in order to avoid de-tuning and interference issues. The antenna will fit on a panel
up to 9mm (0.35in) thick – an extender kit is supplied for thicker panels.
Step 2
Mask the panel area around the hole position to protect the paintwork and
headliner. Drill a pilot hole, and then either use a hole cutter of correct size or
increase the hole diameter to 19mm (or 25mm if using extension bolt),
ensuring that drill/cutter bit does not contact the internal headliner. Clean area
around the hole, carefully removing all swarf, debris and any grease.
An enna Ins alla ion
* 25mm if u ing exten ion bolt
Step 3
The adhesive pad provides a means to affix the antenna and to prevent
rotation during installation, it also augments the sealing function of the
antenna to the mounting panel provided by the sealing boot – it is
recommended that the installation is not carried out in temperatures of less
than 50° (10°C).
Step 4
Remove the protective backing from the underside of the antenna and feed
the coaxial cables through the panel. Position the antenna over the hole
ensuring correct secure location and stick the antenna to the panel by
applying firm downward pressure. The antenna can be fixed in any orientation.
3
Step 5
If required an extension bolt is supplied which can be fixed over the existing
bolt enabling the antenna to be fitted with various panel depths.
Step 6
A slotted/split nut is provided in order to simplify fitting it over the coaxial
cables. When fitting the nut, it is important to ensure that the cables are
held centrally whilst the nut is correctly started on the threads. The nut should
fit freely by hand and only require a final tighten with a spanner. Assemble the
nut and washer from the underside and tighten to a recommended torque of
5Nm (3.6 ft/lbs). Ensure that the sealing boot is properly compressed.
Wherever possible we recommend you test the system before installation.
Avtex recommends installation to be carried out by a professional installer.
The antenna can be positioned in any orientation.
The antenna is designed for a permanent installation and under normal
circumstances once installed should not be removed.
If preferred some additional silicone can be applied around the base
4
Routin and terminatin coaxial cable(s)
Connect the extension coaxial cables to the antenna and route the cables to
the radio equipment.
When routing the cables take care to avoid running them adjacent to
any existing vehicle wiring or fouling any moving vehicle components.
The c ables must not be routed in front of any airbag device. it the
correct coaxial connectors or adapters to the cables as required. If
extension cables are needed please contact your retailer.
Commission and test
Check the comms cables:
•Earth continuity: connector body to vehicle ground should measure <0.2Ω
(where applicable).
•or LTE elements connector body to centre pin should measure low
resistance (elements are DC grounded). Wi i elements should measure open
circuit using the same test.
•Carry out VSWR check – the VSWR on all feeds should meet the
specification in product data sheet.
•Connect the Cellular/LTE and Wi i cables (if applicable) or secure
unused pigtails.
F Safety Note – Ensure that the antenna is mounted in such a way that
no person is likely to be within a distance of 30cms (12”) from the
antenna during use. Ensure that the antenna is used only as supplied.
The co-axial cables should not be cut shorter or otherwise modified.
General Safety Note – Make sure that the product is mounted so
that it cannot fall and cause injury. Do not chew the product or put it
in your mouth. Do not leave children unsupervised with the product
or packaging.
5
Ins alla ion Warning
Waste electrical products should not be disposed of with household
waste. All electronic products with the WEEE logo must be collected
and sent to approved operators for safe disposal or recycling.
Please recycle where facilities exist. Many electrical/electronic
equipment retailers facilitate “Distributor Take-Back scheme” for
household WEEE. Check with your Local Authority or electronic
retailers for designated collection facilities where WEEE can be
disposed of for free.
EACH (Registration, Evaluation, Authorisation and Restriction of Chemicals,
EC 1907/2006). This product contains Lead (CAS No. 7439-92-1) which is
classified as an SVHC (Substance of Very High Concern) as being toxic to
reproduction under Article 57c. of REACH. Do not chew part or put them in
mouth, keep away from un upervi ed children. Di po e of part a WEEE
wa te do not end to landfill.
6
EU Declaration of Conformity (RED)
Object eference: L45GA
Object Description: Low Profile MiMo Antenna with active
GNSS Antenna
Manufacturer: Avtex, Calon Point, 1 ountain Lane,
Cardiff, C 3 0 E, UK
This declaration is issued under the sole responsibility of the manufacturer.
The object of the declaration described above is in conformity with the
relevant Union Harmonization Legislation below:
Directive 2014/53/EU – Radio Equipment Directive (RED)
Harmonised Standards and References:
EN 301 489-1 (V2.1.1): “Electromagnetic compatibility and Radio spectrum
Matters (ERM); Electro Magnetic Compatibility (EMC) standard for radio
equipment and services; Part 1: Common technical requirements”.
Referencing EN 61000-4-2:2009 – Electrostatic Discharge Immunity and EN
61000-4-3:2006 +A1:2008 +A2:2010– Radiated R Immunity
EN 300 440-1 V1.6.1 (2010-08) – Electromagnetic compatibility and radio
spectrum matters (ERM); short range devices; radio equipment to be used in
the 1GHz to 40GHz frequency range; Part 1: Technical characteristics and
Test methods in accordance with EN 300 440-2 V1.4.1 (2010-8) –
Electromagnetic compatibility and radio spectrum matters (ERM); short range
devices; radio equipment to be used in the 1GHz to 40GHz frequency range.
Low Voltage Directive: Directive 2006/95/EC (Electrical Equipment
designed for use within certain voltage limits) of August 2007.
Compliance is declared according to:
EN62368-1: 2014 Audio/video, information and communication
technology equipment.
Safety requirements: RoHS 2 compliance is declared per Directive 2011/65/EU
and its subsequent amendments with exemption 6.c applied. This product
contains lead as an alloying element in a copper alloy containing up to 4%
lead by weight.
Avtex’s sole liability for incorrectly certifying a product shall be either
replacement of the product or, alternatively and in the sole discretion of Avtex,
return of the purchase price paid for the relevant Avtex Antenna product.
7
AMR985 Basic Se up
Router
Step 1
After SIM card activation (see details enclosed) please follow below:
• Insert the SIM card into the SIM 1 holder.
• A standard size SIM mu t he used.
• Push the SIM 1*holder button with the SIM needle
• Pull out the SIM 1*holder
• Insert your SIM card into the SIM 1*holder and insert back into AMR985.
8
* Please Note: Your AMR985 will function fully with only one SIM, but it
must be loaded into the SIM 1 slot.
If using 2 SIM cards installation same as above, but use SIM2.
