Avtech AVIR-2-B Manuel utilisateur

INSTRUCTIONS

MODEL AVIR-2-B

0 TO 200 VOLT

HIGH PERFORMANCE PULSE GENERATOR

WITH IEEE 488.2 AND RS-232 CONTROL

SERIAL NUMBER: ____________

A V T E C H E L E C T R O S Y S T E M S L T D .

N A N O S E C O N D W A V E F O R M E L E C T R O N I C S

S I N C E 1 7 5

P.O. BOX 265

OGDENSBURG, NY

U.S.A. 1366 -0265

TEL: 888-670-872 (USA & Canada) or +1-613-686-6675 (Intl)

FAX: 800-561-1 70 (USA & Canada) or +1-613-686-667 (Intl)

info@avtechpulse.com - http://www.avtechpulse.com/

BOX 5120, LCD MERIVALE

OTTAWA, ONTARIO

CANADA K2C 3H5

WARRANTY

Avtech Electrosystems Ltd. warrants products of its manufacture to be free from

defects in material and workmanship under conditions of normal use. If, within

one year after delivery to the original owner, and after prepaid return by the

original owner, this Avtech product is found to be defective, Avtech shall at its

option repair or replace said defective item. This warranty does not apply to

units which have been dissembled, modified or subjected to conditions

exceeding the applicable specifications or ratings. This warranty is the extent of

the obligation assumed by Avtech with respect to this product and no other

warranty or guarantee is either expressed or implied.

TECHNICAL SUPPORT

Phone: 888-670-872 (USA & Canada) or +1-613-686-6675 (International)

Fax: 800-561-1 70 (USA & Canada) or +1-613-686-667 (International)

E-mail: info@avtechpulse.com

World Wide Web: http://www.avtechpulse.com

TABLE OF CONTENTS

WARRANTY......................................................................................................................2

TECHNICAL SUPPORT....................................................................................................2

TABLE OF CONTENTS....................................................................................................3

INTRODUCTION...............................................................................................................5

AVAILABLE OPTIONS......................................................................................................6

SPECIFICATIONS.............................................................................................................7

REGULATORY NOTES.....................................................................................................8

FCC PART 18..........................................................................................................................8

EC DECLARATION OF CONFORMITY...................................................................................8

DIRECTIVE 2002/95/EC (RoHS).............................................................................................9

DIRECTIVE 2002/96/EC (WEEE)............................................................................................9

AC POWER S PPLY REG LATORY NOTES......................................................................10

FIRMWARE LICENSING........................................................................................................10

INSTALLATION...............................................................................................................11

VIS AL CHECK..................................................................................................................... 11

POWER RATINGS.................................................................................................................11

CONNECTION TO THE POWER S PPLY............................................................................11

PROTECTION FROM ELECTRIC SHOCK...........................................................................12

ENVIRONMENTAL CONDITIONS.........................................................................................13

LABVIEW DRIVERS..............................................................................................................13

FUSES.............................................................................................................................14

AC F SE REPLACEMENT...................................................................................................14

DC F SE REPLACEMENT...................................................................................................15

F SE RATINGS.....................................................................................................................15

FRONT PANEL CONTROLS..........................................................................................16

REAR PANEL CONTROLS............................................................................................18

GENERAL INFORMATION.............................................................................................2

BASIC P LSE CONTROL....................................................................................................20

TRIGGER MODES................................................................................................................ 21

GATING MODES...................................................................................................................22

OPTIONAL FEATURES..................................................................................................23

RACK MO NTING, -R5 OPTION..........................................................................................23

DC OFFSET, -OS OPTION....................................................................................................23

MONITOR O TP T, -M OPTION..........................................................................................23

ELECTRONIC AMPLIT DE CONTROL, -EA OPTION.........................................................23

PROTECTING YOUR INSTRUMENT.............................................................................24

T RN OFF INSTR MENT WHEN NOT IN SE....................................................................24

DO NOT EXCEED 20 kHz.....................................................................................................24

SE A 50Ω LOAD.................................................................................................................24

OPERATIONAL CHECK.................................................................................................25

PROGRAMMING YOUR PULSE GENERATOR............................................................29

KEY PROGRAMMING COMMANDS.....................................................................................29

ALL PROGRAMMING COMMANDS......................................................................................30

MECHANICAL INFORMATION......................................................................................32

TOP COVER REMOVAL.......................................................................................................32

RACK MO NTING................................................................................................................ 32

ELECTROMAGNETIC INTERFERENCE..............................................................................32

MAINTENANCE..............................................................................................................33

REG LAR MAINTENANCE...................................................................................................33

CLEANING............................................................................................................................ 33

WIRING DIAGRAMS.......................................................................................................34

WIRING OF AC POWER.......................................................................................................34

WIRING OF DC POWER.......................................................................................................35

PCB 158N - LOW VOLTAGE POWER S PPLY, 1/3.............................................................36

PCB 158N - LOW VOLTAGE POWER S PPLY, 2/3.............................................................37

PCB 158N - LOW VOLTAGE POWER S PPLY, 3/3.............................................................38

PCB 235A - HIGH VOLTAGE DC POWER S PPLY.............................................................39

PCB 216D - PRF / PW / TR ADJ ST....................................................................................40

PCB 104E - KEYPAD / DISPLAY BOARD, 1/3.....................................................................41

PCB 104E - KEYPAD / DISPLAY BOARD, 2/3.....................................................................42

PCB 104E - KEYPAD / DISPLAY BOARD, 3/3.....................................................................43

MAIN WIRING........................................................................................................................ 44

PERFORMANCE CHECKSHEET...................................................................................45

Manual Reference: /fileserver2/officefiles/instructword/avir/AVIR-2-B,edition1.odt.

Last modified August 12, 2013.

INTRODUCTION

The AVIR-2-B is a high performance, GPIB and RS232-equipped instrument capable of

generating 200V into 50Ω loads at repetition rates up to 20 kHz. The output pulse width

is variable from 3 to 10 ns. The sync delay is variable up to ±1 second. The rise times

are 1.5 ns or less (20%-80%), and the fall times are 2 ns or less (80%-20%).

Instruments with the "-P" model suffix can generate up to +200V, whereas instruments

with the "-N" model suffix can generate up to -200V. Instruments with the "-PN" suffix

can generate both polarities.

A 50 Ohm load is required for proper operation. The output stage may be damaged if

the output is not terminated into a 50Ω load.

The AVIR-2-B is a highly flexible instrument. Aside from the internal trigger source, it

can also be triggered or gated by external TTL-level signals. A front-panel pushbutton

or a computer command can also be used to trigger the instrument.

The AVIR-2-B features front panel keyboard and adjust knob control of the output pulse

parameters along with a four line by 40-character backlit LCD display of the output

amplitude, pulse width, pulse repetition frequency, and delay. The instrument includes

memory to store up to four complete instrument setups. The operator may use the front

panel or the computer interface to store a complete “snapshot” of all key instrument

settings, and recall this setup at a later time.

This instrument is intended for use in research, development, test and calibration

laboratories by qualified personnel.

AVAILABLE OPTIONS

The AVIR-2-B is available with several options:

-EA Option: the amplitude can be controlled by an externally generated 0 to +10V

analog control voltage.

-M Option: a monitor output is provided.

-OS Option: an externally generated DC offset can be added to the output.

-R5 Option: A rack mounting kit is available. The "-R5" rack mount kit may be installed

after first removing the one Phillips screw on the side panel adjacent to the front

handle.

-VXI Option: Adds a rear-panel Ethernet connector, allowing the instrument to be

remotely controlled using the VXI-11.3, ssh (secure shell), telnet, and http (web)

protocols. In particular, the VXI-11.3 features allows software like LabView to control an

instrument using standard VISA communications drivers and network cabling, instead

of using old-style GPIB cabling. (This eliminates the need for a GPIB controller card

and its proprietary drivers.)

SPECIFICATIONS

Model: AVIR-2-B2

Amplitude3,4,5, : < 20 to 200 Volts (50Ω load required)

Pulse width (FWHM)4: 3 - 10 ns

Rise time (20%-80%): ≤ 1.5 ns

Fall time (80%-20%): ≤ 2 ns

PRF: 0 to 20 kHz

Polarity6: Positive or negative or both (specify)

GPIB & RS-232 control2: Standard on -B units.

LabView Drivers: Check http://www.avtechpulse.com/labview for availability and downloads

Ethernet port, for remote

control using VXI-11.3,

ssh, telnet, & web:

Optional7. Recommended as a modern alternative to GPIB / RS-232.

See http://www.avtechpulse.com/options/vxi for details.

Settings resolution: The resolution varies, but is always better than 0.15% of the set value.

Settings accuracy: Typically ± 5% (plus ±2 V or ± 2 ns) after 10 minute warmup.

For pulse widths below ~10 ns, the amplitude accuracy degrades to ± 10% ± 10 V.

For high-accuracy applications requiring traceable calibration,

verify the output parameters with a calibrated oscilloscope.

Propagation delay: ≤ 100 ns (Ext trig in to pulse out)

Jitter: ± 35ps ± 0.015% of sync delay (Ext trig in to pulse out)

DC offset or

bias insertion:

Optional8. Apply required DC offset or bias in the range of

± 50 Volts (250 mA max) to back panel solder terminal..

Trigger required: Ext trig mode: + 5 Volts, 50 ns or wider (TTL)

Sync delay: Sync out to pulse out, variable 0 to ± 500 ns

Sync output +3 Volts, 100 ns, will drive 50 Ohm loads

Connectors: Out: SMA, Trig/Sync, Gate (-B only): BNC

Power requirement: 100 - 240 Volts, 50 - 60 Hz

Dimensions: H x W x D: 100 × 430 × 375 mm (3. × 17 × 14.8”)

Chassis material: Aluminum

Rack-mount kit: Optional. To specify, add the -R5 suffix to the model number.

Temperature range: +5°C to +40°C

1) -C suffix indicates stand-alone lab instrument with internal clock and line powering.

2) -B suffix indicates IEEE-488.2 GPIB and RS-232 control of amplitude, pulse width, PRF and delay (see http://www.avtechpulse.com/gpib for details).

3) For electronic control (0 to +10V) of amplitude, suffix the model number with -EA. Includes standard front-panel controls. Not available on AVIR-4

models.

4) For 10-turn dial control of pulse width (or amplitude) suffix model number with -PWT (or -AT). Not applicable for -B units.

5) For operation at amplitudes of less than 10% of full-scale, best results will be obtained by setting the amplitude near full-scale and using external

attenuators on the output.

6) Indicate desired polarity by suffixing model number with -P or -N (i.e. positive or negative) or -PN for dual polarity option. Polarity reversal is achieved

by means of a two-position switch.

7) Add the suffix -VXI to the model number to specify the Ethernet port.

8) For DC offset option suffix model number with -OS.

REGULATORY NOTES

FCC PART 18

This device complies with part 18 of the FCC rules for non-consumer industrial,

scientific and medical (ISM) equipment.

This instrument is enclosed in a rugged metal chassis and uses a filtered power entry

module (where applicable). The main output signal is provided on a shielded connector

that is intended to be used with shielded coaxial cabling and a shielded load. Under

these conditions, the interference potential of this instrument is low.

If interference is observed, check that appropriate well-shielded cabling is used on the

output connectors. Contact Avtech (info@avtechpulse.com) for advice if you are unsure

of the most appropriate cabling. Also, check that your load is adequately shielded. It

may be necessary to enclose the load in a metal enclosure.

If any of the connectors on the instrument are unused, they should be covered with

shielded metal “dust caps” to reduce the interference potential.

This instrument does not normally require regular maintenance to minimize interference

potential. However, if loose hardware or connectors are noted, they should be

tightened. Contact Avtech (info@avtechpulse.com) if you require assistance.

EC DECLARATION OF CONFORMITY

We Avtech Electrosystems Ltd.

P.O. Box 5120, LCD Merivale

Ottawa, Ontario

Canada K2C 3H4

declare that this pulse generator meets the intent of Directive 2004/108/EG for

Electromagnetic Compatibility. Compliance pertains to the following specifications as

listed in the official Journal of the European Communities:

EN 50081-1 Emission

EN 50082-1 Immunity

and that this pulse generator meets the intent of the Low Voltage Directive 72/23/EEC

as amended by 3/68/EEC. Compliance pertains to the following specifications as

listed in the official Journal of the European Communities:

EN 61010-1:2001 Safety requirements for electrical equipment for

measurement, control, and laboratory use

DIRECTIVE 2002/ 5/EC (RoHS)

This instrument is exempt from Directive 2002/ 5/EC of the European Parliament and

of the Council of 27 January 2003 on the Restriction of the use of certain Hazardous

Substances (RoHS) in electrical and electronic equipment. Specifically, Avtech

instruments are considered "Monitoring and control instruments" (Category ) as

defined in Annex 1A of Directive 2002/ 6/EC. The Directive 2002/ 5/EC only applies to

Directive 2002/ 6/EC categories 1-7 and 10, as stated in the "Article 2 - Scope" section

of Directive 2002/ 5/EC.

DIRECTIVE 2002/ 6/EC (WEEE)

European customers who have purchased this equipment directly from Avtech will have

completed a “WEEE Responsibility Agreement” form, accepting responsibility for

WEEE compliance (as mandated in Directive 2002/ 6/EC of the European Union and

local laws) on behalf of the customer, as provided for under Article of Directive

2002/ 6/EC.

Customers who have purchased Avtech equipment through local representatives

should consult with the representative to determine who has responsibility for WEEE

compliance. Normally, such responsibilities with lie with the representative, unless

other arrangements (under Article ) have been made.

Requirements for WEEE compliance may include registration of products with local

governments, reporting of recycling activities to local governments, and financing of

recycling activities.

AC POWER SUPPLY REGULATORY NOTES

This instrument converts the AC input power to the +24V DC voltage that powers the

internal circuitry of this instrument using a Tamura AAD130SD-60-A switching power

supply. According to the manufacturer, the Tamura AAD130SD-60-A has the following

certifications:

UL60 50-1

IEC60 50 -1

CSA C22.2 No. 60 50- 1

EN60 50 -1

and is compliant with:

EN61000-3-2

EN61000-4-2 Level 2

EN61000-4-2 Level 3 (Air Only)

EN61000-4-4 Level 3

EN61000-4-5 Level 3

EN61000-4-11

CISPR 11 and 22 FCC Part 15 Class B (conducted)

FIRMWARE LICENSING

Instruments with firmware versions 5.00 or higher use open-source software internally.

Some of this software requires that the source code be made available to the user as a

condition of its licensing. This source code is distributed on the device itself. To access

it, log in as user “source” with password “source”. The source files are provided in this

user's home directory, and are accessible using standard viewing and file transfer tools

(such as vim, sz, and scp).

Earlier firmware versions do not contain any open source software.

Table des matières

Autres manuels Avtech Générateur d'impulsions

Avtech

Avtech AVOZ-D9-B Manuel utilisateur

Avtech

Avtech AVR-E2-B Manuel utilisateur

Avtech

Avtech AV-1023-C Manuel utilisateur

Avtech

Avtech AVPP-1-B Manuel utilisateur

Avtech

Avtech AVP-AV-1-B Manuel utilisateur

Avtech

Avtech AVR-E3-B Manuel utilisateur

Avtech

Avtech AVR-G1-B Manuel utilisateur

Avtech

Avtech AV-1030-B Manuel utilisateur

Avtech

Avtech AVPP-2A-B Manuel utilisateur

Avtech

Avtech AVO-6-B Manuel utilisateur

Avtech

Avtech AVR-8F-B-P-ADB1A Manuel utilisateur

Avtech

Avtech AVMR-2D-B Manuel utilisateur

Avtech

Avtech AVR-G1-B-P-EMRA-R5-RP-IM Manuel utilisateur

Avtech

Avtech AVL-2D-B Manuel utilisateur

Avtech

Avtech AVR-A-1-S2-C Manuel utilisateur

Avtech

Avtech AVR-5B-B Manuel utilisateur

Avtech

Avtech AVRF-4A-B Manuel utilisateur

Avtech

Avtech AVI-V-B-N-VCB Manuel utilisateur

Avtech

Avtech AVR-E2-B-P-TEK1C Manuel utilisateur

Avtech

Avtech AVRF-2-B Manuel utilisateur

Avtech

Avtech AVOZ-D7-B Manuel utilisateur

Avtech

Avtech AVP-AV-HV3-B Manuel utilisateur

Avtech

Avtech AVR-3HG-B Manuel utilisateur

Avtech

Avtech AVRH-2-B Manuel utilisateur

Manuels Générateur d'impulsions populaires d'autres marques

HP 8082a Manuel de service

Schwarzbeck

Schwarzbeck IGUU 2916 Manuel utilisateur

Anaheim Automation

Anaheim Automation MBC10P31 Manuel utilisateur

BIOTRONIK

BIOTRONIK Philos DR-T Manuel utilisateur

BNC

BNC 575 Series Manuel utilisateur

Hioki

Hioki U8793 Manuel utilisateur

Agilent Technologies

Agilent Technologies 8114A Manuel utilisateur

HP 8012A Manuel utilisateur

Bradley

Bradley 233 Manuel utilisateur

Agilent Technologies

Agilent Technologies E4438C Manuel utilisateur

DEI

DEI PCX-7500 Manuel utilisateur

Kiepe Elektrik

Kiepe Elektrik DG Series Manuel utilisateur

Hagerman Technology

Hagerman Technology FryBaby Manuel utilisateur

BNC

BNC MOD745T Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVG-4A-B Manuel utilisateur

Tektronix

Tektronix 114 Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVR-E5-B Manuel utilisateur

BNC

BNC 505-2C Manuel utilisateur
