AVTECH ELECTROSYSTEMS LTD. AVR-E5-B Manuel utilisateur

INSTRUCTIONS

MODEL AVR-E5-B

50 VOLTS, 500 ps RISE TIME

HIGH PERFORMANCE PULSE GENERATOR

WITH IEEE 488.2 AND RS-2 2 CONTROL

SERIAL NUMBER: ____________

A V T E C H E L E C T R O S Y S T E M S L T D .

N A N O S E C O N D W A V E F O R M E L E C T R O N I C S

S I N C E 1 9 7 5

P.O. BOX 265

OGDENSBURG, NY

U.S.A. 1 669-0265

TEL: 888-670-8729 (USA & Canada) or +1-61 -686-6675 (Intl)

FAX: 800-561-1970 (USA & Canada) or +1-61 -686-6679 (Intl)

info@avtechpulse.com - http://www.avtechpulse.com/

BOX 5120, LCD MERIVALE

OTTAWA, ONTARIO

CANADA K2C H5

WARRANTY

Avtech Electrosystems Ltd. warrants products of its manufacture to be free

from defects in material and workmanship under conditions of normal use. If,

within one year after delivery to the original owner, and after prepaid return by

the original owner, this Avtech product is found to be defective, Avtech shall at

its option repair or replace said defective item. This warranty does not apply to

units which have been dissembled, modified or subjected to conditions

exceeding the applicable specifications or ratings. This warranty is the extent of

the obligation assumed by Avtech with respect to this product and no other

warranty or guarantee is either expressed or implied.

TECHNICAL SUPPORT

Phone: 888-670-8729 (USA & Canada) or +1-61 -686-6675 (International)

Fax: 800-561-1970 (USA & Canada) or +1-61 -686-6679 (International)

E-mail: info@avtechpulse.com

World Wide Web: http://www.avtechpulse.com

TABLE OF CONTENTS

WARRANTY......................................................................................................................2

TECHNICAL SUPPORT...................................................................................................2

TABLE OF CONTENTS....................................................................................................3

INTRODUCTION...............................................................................................................5

AVAILABLE OPTIONS.....................................................................................................6

SPECIFICATIONS.............................................................................................................7

REGULATORY NOTES....................................................................................................8

FCC PART 18.......................................................................................................................... 8

EC DECLARATION OF CONFORMITY..................................................................................8

DIRECTIVE 2011/65/EU (RoHS)............................................................................................9

DIRECTIVE 2002/96/EC ( EEE)............................................................................................9

FIRM ARE LICENSING.......................................................................................................10

INSTALLATION..............................................................................................................11

VISUAL CHECK....................................................................................................................11

PO ER RATINGS................................................................................................................11

CONNECTION TO THE PO ER SUPPLY...........................................................................11

PROTECTION FROM ELECTRIC SHOCK...........................................................................12

ENVIRONMENTAL CONDITIONS........................................................................................13

LABVIE DRIVERS.............................................................................................................13

FUSES.............................................................................................................................14

AC FUSE REPLACEMENT...................................................................................................14

DC FUSE REPLACEMENT...................................................................................................15

FUSE RATINGS.................................................................................................................... 15

FRONT PANEL CONTROLS..........................................................................................16

REAR PANEL CONTROLS............................................................................................18

GENERAL INFORMATION............................................................................................2

BASIC PULSE CONTROL....................................................................................................20

TRIGGER MODES................................................................................................................21

GATING MODES...................................................................................................................22

OPTIONAL FEATURES..................................................................................................23

RACK MOUNTING, -R5 OPTION..........................................................................................23

DC OFFSET, -OS OPTION...................................................................................................23

PROTECTING YOUR INSTRUMENT.............................................................................24

TURN OFF INSTRUMENT HEN NOT IN USE...................................................................24

DO NOT EXCEED 1 MHz......................................................................................................24

USE A 50Ω LOAD.................................................................................................................24

OPERATIONAL CHECK.................................................................................................25

PROGRAMMING YOUR PULSE GENERATOR............................................................29

KEY PROGRAMMING COMMANDS....................................................................................29

ALL PROGRAMMING COMMANDS.....................................................................................30

MECHANICAL INFORMATION......................................................................................32

TOP COVER REMOVAL.......................................................................................................32

RACK MOUNTING................................................................................................................ 32

ELECTROMAGNETIC INTERFERENCE..............................................................................32

MAINTENANCE..............................................................................................................33

REGULAR MAINTENANCE..................................................................................................33

CLEANING............................................................................................................................ 33

TRIGGER DAMAGE..............................................................................................................33

WIRING DIAGRAMS.......................................................................................................34

IRING OF AC PO ER.......................................................................................................34

PCB 158R2 - LO VOLTAGE PO ER SUPPLY................................................................35

PCB 235B - HIGH VOLTAGE DC PO ER SUPPLY...........................................................36

PCB 216E - PRF / P T EAKS..........................................................................................37

PCB 104F - KEYPAD / DISPLAY BOARD, 1/3....................................................................38

PCB 104F - KEYPAD / DISPLAY BOARD, 2/3....................................................................39

PCB 104F - KEYPAD / DISPLAY BOARD, 3/3....................................................................40

MAIN IRING....................................................................................................................... 41

PERFORMANCE CHECKSHEET...................................................................................42

Manual Reference: /fileserver2/officefiles/instructword/avr-e/AVR-E5-B,ed .odt.

Last modified October 5, 2017.

INTRODUCTION

The AVR-E5-B is a high performance, GPIB and RS2 2-equipped instrument capable

of generating up to 50V into 50Ω loads. The rise time (20%-80%) is less than 500 ps,

and the fall time (80%-20%) is less than 1 ns. The output pulse width is variable from

<1 ns to 10 ns, at repetition rates up to 1 MHz.

Instruments with the "-P" model suffix can generate up to +50V, whereas instruments

with the "-N" model suffix can generate up to -50V. Instruments with the "-PN" suffix

can generate both polarities.

A 50 Ohm load is required for proper operation. The output stage may be damaged if

the output is not terminated into a 50Ω load.

The AVR-E5-B is a highly flexible instrument. Aside from the internal trigger source, it

can also be triggered or gated by external TTL-level signals. A front-panel pushbutton

or a computer command can also be used to trigger the instrument.

The AVR-E5-B features front panel keyboard and adjust knob control of the output

pulse parameters along with a four line by 40-character backlit LCD display of the

output amplitude, pulse width, pulse repetition frequency, and delay. The instrument

includes memory to store up to four complete instrument setups. The operator may use

the front panel or the computer interface to store a complete “snapshot” of all key

instrument settings, and recall this setup at a later time.

This instrument is intended for use in research, development, test and calibration

laboratories by qualified personnel.

AVAILABLE OPTIONS

The AVR-E5-B is available with several options, including:

-OS Option: an externally generated DC offset can be added to the output.

-R5 Option: This is the optional rack-mounting kit. The R5 rack-mount kit may also be

ordered separately.

-VXI Option: Adds a rear-panel Ethernet connector, allowing the instrument to be

remotely controlled using the VXI-11. , ssh (secure shell), telnet, and http (web)

protocols. In particular, the VXI-11. features allows software like LabView to control an

instrument using standard VISA communications drivers and network cabling, instead

of using old-style GPIB cabling. (This eliminates the need for a GPIB controller card

and its proprietary drivers.)

SPECIFICATIONS

Model: AVR-E5-B2

Amplitude : (50 Ohm load8) Up to 50V

Rise time (20%-80%): 0.5 ns

Fall time (80%-20%): 1.0 ns

Pulse width (FWHM): 1 to 10 ns

Maximum PRF: 1 MHz

Polarity: Positive or negative or both (specify4)

DC offset or bias insertion: Option available5. Apply required DC offset or bias in the range of ± 25 Volts,

(250 mA max) to back panel solder terminals.

Trigger modes: Internal trigger, external trigger (TTL level pulse, > 10 ns, 1 kΩ input impedance),

front-panel “Single Pulse” pushbutton, or single pulse trigger via computer command.

Variable delay: 0 to 1.0 seconds, for all trigger modes (including external trigger).

Propagation delay: ≤ 160 ns (Ext trig in to pulse out)

Jitter: (Ext trig in to pulse out) ± 5ps ± 0.015% of sync delay

Sync output: Standard: + Volts, 100 ns, will drive 50 Ohm loads

Gate input: Synchronous or asynchronous, active high or low, switchable. Suppresses triggering when

active.

Connectors: Out: SMA, Other: BNC

Power requirements: 100 - 240 Volts, 50 - 60 Hz

GPIB and RS-2 2 control2: Standard on -B units.

LabView drivers: Check http://www.avtechpulse.com/labview for availability and downloads

Ethernet port, for remote control

using VXI-11. , ssh, telnet, &

web:

Optional6. Recommended as a modern alternative to GPIB / RS-2 2.

See http://www.avtechpulse.com/options/vxi for details.

Settings resolution: The resolution of the timing parameters varies, but is always better than 0.15% of the set value.

The amplitude resolution is typically 0.02% of the maximum amplitude.

Settings accuracya: Typically ± % (±2 ns or ± 2% of max. amplitude) after 10 minute warmup. For high-accuracy

applications requiring traceable calibration, verify the output with a calibrated oscilloscope.

Dimensions (H x W x D): 100 mm x 4 0 mm x 75 mm ( .9” x 17” x 14.8”)

Chassis material: cast aluminum frame and handles, blue vinyl on aluminum cover plates

Temperature range: +5°C to +40°C

1) -C suffix indicates stand-alone lab instrument with internal clock and line powering. (See http://www.avtechpulse.com/formats for additional details of

the four basic instrument formats).

2) -B suffix indicates IEEE-488.2 GPIB and RS-2 2 control of amplitude, pulse width, PRF and delay (see http://www.avtechpulse.com/gpib).

) For operation at amplitudes of less than 10% of full-scale, best results will

be obtained by setting the amplitude near full-scale and using external attenuators on the output.

4) Indicate desired polarity by suffixing model number with -P or -N (i.e. positive or negative) or -PN for dual polarity option. Polarity reversal achieved

by means of a two-position switch that controls the polarity of the signal output port on -C units, and via keypad control on -B units. -PN option not

available on -W units.

5) For DC offset option suffix model number with -OS.

6) Add the suffix -VXI to the model number to specify the Ethernet port..

7) Fall time increases to < ns for pulse widths less than 15 ns.

8) A 50Ω load is required. Other loads may damage the instrument. Consult Avtech (info@avtechpulse.com) if you need to drive other

load impedances.

REGULATORY NOTES

FCC PART 18

This device complies with part 18 of the FCC rules for non-consumer industrial,

scientific and medical (ISM) equipment.

This instrument is enclosed in a rugged metal chassis and uses a filtered power entry

module (where applicable). The main output signal is provided on a shielded connector

that is intended to be used with shielded coaxial cabling and a shielded load. Under

these conditions, the interference potential of this instrument is low.

If interference is observed, check that appropriate well-shielded cabling is used on the

output connectors. Contact Avtech (info@avtechpulse.com) for advice if you are unsure

of the most appropriate cabling. Also, check that your load is adequately shielded. It

may be necessary to enclose the load in a metal enclosure.

If any of the connectors on the instrument are unused, they should be covered with

shielded metal “dust caps” to reduce the interference potential.

This instrument does not normally require regular maintenance to minimize interference

potential. However, if loose hardware or connectors are noted, they should be

tightened. Contact Avtech (info@avtechpulse.com) if you require assistance.

EC DECLARATION OF CONFORMITY

We Avtech Electrosystems Ltd.

P.O. Box 5120, LCD Merivale

Ottawa, Ontario

Canada K2C H5

declare that this pulse generator meets the intent of Directive 2004/108/EG for

Electromagnetic Compatibility. Compliance pertains to the following specifications as

listed in the official Journal of the European Communities:

EN 50081-1 Emission

EN 50082-1 Immunity

and that this pulse generator meets the intent of the Low Voltage Directive 2006/95/EC.

Compliance pertains to the following specifications as listed in the official Journal of the

European Communities:

EN 61010-1:2001 Safety requirements for electrical equipment for

measurement, control, and laboratory use

DIRECTIVE 2011/65/EU (RoHS)

We Avtech Electrosystems Ltd.

P.O. Box 5120, LCD Merivale

Ottawa, Ontario

Canada K2C H5

declare that, to the best of our knowledge, all electrical and electronic equipment (EEE)

sold by the company are in compliance with Directive 2011/65/EU of the European

Parliament and of the Council of 8 June 2011 on the restriction of the use of certain

hazardous substances in electrical and electronic equipment (also known as “RoHS

Recast”). In addition, this declaration of conformity is issued under the sole

responsibility of Avtech Electrosystems Ltd. Specifically, products manufactured do not

contain the substances listed in the table below in concentrations greater than the listed

maximum value.

Material/Substance Threshold level

Lead (Pb) < 1000 ppm (0.1% by mass)

Mercury (Hg) < 1000 ppm (0.1% by mass)

Hexavalent Chromium (Cr6+) < 1000 ppm (0.1% by mass)

Polybrominated Biphenyls (PBB) < 1000 ppm (0.1% by mass)

Polybrominated Diphenyl ethers (PBDE) < 1000 ppm (0.1% by mass)

Cadmium (Cd) < 100 ppm (0.01% by mass)

DIRECTIVE 2002/96/EC (WEEE)

European customers who have purchased this equipment directly from Avtech will have

completed a “WEEE Responsibility Agreement” form, accepting responsibility for WEEE

compliance (as mandated in Directive 2002/96/EC of the European Union and local

laws) on behalf of the customer, as provided for under Article 9 of Directive

2002/96/EC.

Customers who have purchased Avtech equipment through local representatives

should consult with the representative to determine who has responsibility for WEEE

compliance. Normally, such responsibilities with lie with the representative, unless other

arrangements (under Article 9) have been made.

Requirements for WEEE compliance may include registration of products with local

governments, reporting of recycling activities to local governments, and financing of

recycling activities.

FIRMWARE LICENSING

Instruments with firmware versions 5.00 or higher use open-source software internally.

Some of this software requires that the source code be made available to the user as a

condition of its licensing. This source code is available upon request (contact

[email protected]om).

Earlier firmware versions do not contain any open source software.

Table des matières

Autres manuels AVTECH ELECTROSYSTEMS LTD. Générateur d'impulsions

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVOZ-DF5-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AV-1011B1-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVRQ-4-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVR-3HE-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVIR-4D-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVRQ-5-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVMP-2-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVR-2B-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVR-8A-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AV-1021-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVL-AV-1-W-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVR-7B-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AV-1010-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVIR-2-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AV-1015-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVRK-4-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVI-V-HV2B-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVR-GHV1-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVIR-3-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVOZ-D6-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVG-4A-B Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVRK-3-B Manuel utilisateur

Manuels Générateur d'impulsions populaires d'autres marques

HP 8082a Manuel de service

Schwarzbeck

Schwarzbeck IGUU 2916 Manuel utilisateur

Anaheim Automation

Anaheim Automation MBC10P31 Manuel utilisateur

BIOTRONIK

BIOTRONIK Philos DR-T Manuel utilisateur

BNC

BNC 575 Series Manuel utilisateur

Hioki

Hioki U8793 Manuel utilisateur

Agilent Technologies

Agilent Technologies 8114A Manuel utilisateur

HP 8012A Manuel utilisateur

Bradley

Bradley 233 Manuel utilisateur

Agilent Technologies

Agilent Technologies E4438C Manuel utilisateur

DEI

DEI PCX-7500 Manuel utilisateur

Kiepe Elektrik

Kiepe Elektrik DG Series Manuel utilisateur

Hagerman Technology

Hagerman Technology FryBaby Manuel utilisateur

BNC

BNC MOD745T Manuel utilisateur

Avtech

Avtech AVR-G1-B Manuel utilisateur

Avtech

Avtech AVOZ-D2-B Manuel utilisateur

Tektronix

Tektronix 114 Manuel utilisateur

BNC

BNC 505-2C Manuel utilisateur
