AVPro Edge AC-DA28-AUHD Manuel utilisateur
pg. 1
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
User)Manual
AC-DA28-AUHD)
AC-DA28-AUHD)
Introduction
AC-DA28-AUHD is an 18GBPS, full bandwidth HDMI2.0a (HDR)
with HDCP2.2 eight-way HDMI splitter. Functionally, distributes the two
input HDMI signals to eight HDMI outputs (two switchable zones).
AC-DA28-AUHD has the ability of pre-emphasis and equalization.
Multiple cascaded AC-DA28-AUHD achieves long distance transmission
of HDMI signal of more than 15 meters even in 4K (HDR) resolution.
The outstanding and proprietary clock jitter cleaner enable this splitter to
out preform the competition when in cascading mode no matter the signal is
4K or 1080P.
AC-DA28-AUHD offers solutions for usage as a component of digital
HDMI distributions and entertainment systems also UHDTV/4K retail and
general show sites. Use in conjunction with UHDTV, UHD Projector, STB,
UHD-BD, UHD Media Player and in environment where noise, space and
security are concerns. Fits perfectly in data center control rooms,
information distribution premises, conference and presentation rooms,
school educational facilities and corporate training environments.
pg. 2
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
Contents
Introduction.............................................................................................................2
Product Overview and Features.............................................................................. 4
Warnings ................................................................................................................ 5
Package Contents ., Connections & Operations...................................................... 6
Front Panel Description........................................................................................... 7
Back Panel and Top Panel Description ................................................................. 8
Connection Diagram........................................................................................... 9
Network and Web Interface Switching................................................................ 10
EDID Settings..................................................................................................11-12
Web Interface System Settings and RS232 Commands................................13-14
RS232 Connection Diagram.................................................................................15
Specification..........................................................................................................16
Maintenance and Service Info.. ............................................................................17
AC-DA28-AUHD)
pg. 3
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
Support And Warranty Information.......................................................................18
■Product Overview ( Model Number: AC-DA28-AUHD)
■
Features
lEasy to Use: Install in seconds, no need for setting.
lDistribution: Two HDMI inputs, two switchable output zones.
lSupports up to 18GBPS with resolutions of 4K60(YUV444), 4K30, 1080p,
1080i, 720p and other standard Video formats, PAL and NTSC.
lFull HDR Support (HDR 10 & 12 Bit)
lDolby Vision, HDR10 (10+) and HLG Support
lHDCP 2.2 (and all earlier versions supported)
lLAN Web GUI Control and full API
lRemote Status Monitoring
lAdvanced EDID Management
lDigital Toslink Out
lLocking Power Connector
lHDMI 2.0(a/b) w/ HDR.
lCascadable
lMounting ears are included for easy fixation on wall, furniture or ceiling.
?Notice
AVProEdge reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
AC-DA28-AUHD)
pg. 4
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
Warning
To reduce the risk of fire, electric shock or product damage:
1. Do not expose this apparatus
to rain, moisture, dripping or
splashing and that no objects
filled with liquids, such as vases,
shall be placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit
in a bookcase, built-in cabinet or
in another confined space.
Ensure the unit is well ventilated.
3. To pre v e n t ri sk of electr i c
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
5. Do not place sources of naked
flames, such as lighted candles,
on the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.
AC-DA28-AUHD)
pg. 5
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
■
Package Contents
①Main unit. P/N: AC-DA28-AUHD
②12V 2A Locking Power Supply (100-240V
input).
③Mounting Ears
■
Connections and Operations
1) Connect the HDMI input source into AC-DA28-AUHD
2) Connect the HDMI output equipment (Displays) into AC-DA28-AUHD
3) Insert the DC side of 12V power supply into AC-DA28-AUHD and then
connect the AC side of the Power supply into the wall outlet.
4) Plugging in the unit automatically powers up the device.
&NOTE: Insert / Extract cables gently.
AC-DA28-AUHD)
pg. 6
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
■
Panel Descriptions
Front Panel
Activity Display (Front):
a) When Power is applied all lights flash BLUE and the machine begins
to function. If no devices are plugged in, you can verify power by
looking at the zone A/B buttons on the right side of the unit, they
should be lit up blue.
b) When the INPUT device is plugged in, the INPUT light stays SOLID
BLUE.
c) When a sink (display) is plugged into an OUTPUT, the OUTPUT light
will go SOLID.
AC-DA28-AUHD)
pg. 7
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
Back Panel
·Power input
·HDMI inputs (x2)
·HDMI outputs (x8)
·IR, RS-232 and LAN Control Options (Micro USB on side)
·Balanced Analog Out, for extractable 2Ch Audio
·Toslink Audio Port - Supports PCM, LPCM (up to 7CH), Dolby Digital, Dolby Digital Plus, DTS,
DTS-HD, DTS Master Audio, which is ideal for multi-channel audio systems and older AVRs that do
not support 18Gbps.
Device Top Cover
Device cover is labeled with functionality diagram, instructions for front panel
switching and scaling options.
AC-DA28-AUHD)
pg. 8
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
AC-DA28-AUHD)
pg. 9
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
AC-DA28-AUHD)
pg. 10
AVProEdge ~ 2222 E52nd Street N Sioux Falls, SD 57104~ 1.877.886.5112 ~ +1.605.274.6055 ~ [email protected]
Quick Network Connect to Web Interface:
Use the following steps to quickly and immediately connect to the matrix switch:
1. Connect the LAN port into an active router port.
2. On most networks you can simply type the Default IP address into any web browser. The Default IP
Address is 192.168.1.239.
Web Interface: Switching
Use this page to switch between inputs and outputs from the web interface.
