AVPro Edge AC-DA14-AUHD Manuel utilisateur

User Manual

AC-DA14-AUHD

A full 4K60 4:4:4 (Up to 18GBPS)

Distribution Amplifier with advanced EDID management

**Available in 1x2, 1x4, and 1x8

AC-DA14-AUHD

Page 1

Introduction

AC-DA14-AUHD is an 18GBPS, full bandwidth HDMI2.0a (HDR) with

HDCP2.2 four-way HDMI splitter. Functionally, distributes the input HDMI

signal to four identical HDMI outputs. These four outputs are synchronized.

AC-DA14-AUHD has the ability of pre-emphasis and equalization. Multiple

cascaded AC-DA14-AUHD achieves long distance transmission of HDMI signal of

more than 15 meters even in 4K (HDR) resolution.

AC-DA14-AUHD offers solutions for usage as a component of digital HDMI

distributions and entertainment systems also UHDTV/4K retail and general show

sites. Use in conjunction with UHDTV, UHD Projector, STB, UHD-BD, UHD Media

Player and in environment where noise, space and security are concerns. Fits

perfectly in data center control rooms, information distribution premises,

conference and presentation rooms, school educational facilities and

corporate training environments.

AC-DA14-AUHD

Page 2

Contents

HDMI Splitter .................................................................................................................... 2

Product Overview ............................................................................................................ 4

Features ............................................................................................................................. 4

Package Contents ............................................................................................................. 6

Connections and Operations ........................................................................................ 6

Specifications ................................................................................................................... 6

Panel Descriptions ........................................................................................................7-8

Typical Application .........................................................................................................15

Maintenance ................................................................................................................... 11

Product Service ..............................................................................................................12

Mail-In Service ............................................................................................................... 12

Warranty .......................................................................................................................... 12

Warranty Limits And Exclusions ................................................................................. 13

AC-DA14-AUHD

Page 3

Full 4K 60 (4:4:4) HDMI Splitter & Distribution Amplifier

■Product Overview ( Model Number: AC-DA14-AUHD)

■

Features

lEasy to Use: Install in seconds, no need for setting.

lDistribution: One HDMI input, four identical HDMI outputs.

lSupports up to 18GBPS with resolutions of 4K60(YUV444), 4K30, 1080p, 1080i, 720p and

other standard Video formats, PAL and NTSC.

lCustomer can configure EDID function to enable the best compatibility.

lSupports HDCP2.2

lHDMI 2.0(a) w/ HDR.

lMounting ears are included for easy fixation on wall, furniture or ceiling.

?Notice AVProEdge reserves the right to make changes in the hardware, packaging and

any accompanying documentation without prior written notice.

AC-DA14-AUHD

Page 4

AC-DA14-AUHD

Page 5

■

Package Contents

①Main unit. P/N: AC-DA14-AUHD

②5VDC Power Supply.

③Mounting Brackets

■

Connections and Operations

1) Connect the HDMI input source into AC-DA14-AUHD

2) Connect the HDMI output equipment (Displays) into AC-DA14-AUHD

3) Insert the DC side of 5v power supply into AC-DA14-AUHD and then

connect the AC side of the Power supply into the wall outlet.

4) Plugging in the unit automatically powers up the device.

&NOTE: Insert / Extract cables gently.

AC-DA14-AUHD

Page 6

■

Specifications

AC-DA14-AUHD

Page 7

①Power input.

②HDMI input.

③HDMI outputs (x4).

Device Top Cover

Device cover is labeled for DIP Switch (EDID setting) and ISP mini USB port and for

easy HDMI port recognition especially useful when Mounting Ears are used for

fixation. &NOTE: DIP Switch EDID setting index on next page.

Back Panel

AC-DA14-AUHD

Page 8

EDID Settings: The 5 DIP switches are located on the side of the device, and each switch

has two settings, 0 & 1 (UP=0, DOWN=1). The default mode is “00000” which is all up, in

this mode the device copies the EDID from the sink (display) plugged into OUTPUT 1.

Custom EDID settings are below.

10000: 1080P_2CH(PCM)_HDR

10001: 1080P_6CH_HDR

10010: 1080P_8CH_HDR

10011: 1080P_3D_2CH(PCM)_HDR

10100: 1080P_3D_6CH_HDR

10101: 1080P_3D_8CH_HDR

10110: 4K30Hz_3D_2CH(PCM)_HDR

10111: 4K30Hz_3D_6CH_HDR

11000: 4K30Hz_3D_8CH_HDR

11001: 4K60Hz(Y420)_3D_2CH(PCM)_HDR

11010: 4K60Hz(Y420)_3D_6CH_HDR

11011: 4K60Hz(Y420)_3D_8CH_HDR

11100: 4K60Hz_3D_2CH(PCM)_HDR

11101: 4K60Hz_3D_6CH_HDR

11110: 4K60Hz_3D_8CH_HDR

11111: Passthrough

EDID DIP Settings:

00000: EDID COPY (See NOTE 1)

00001: 1080P_2CH(PCM)

00010: 1080P_6CH

00011: 1080P_8CH

00100: 1080P_3D_2CH(PCM)

00101: 1080P_3D_6CH

00110: 1080P_3D_8CH

00111: 4K30Hz_3D_2CH(PCM)

01000: 4K30Hz_3D_6CH

01001: 4K30Hz_3D_8CH

01010: 4K60Hz(Y420)_3D_2CH(PCM)

01011: 4K60Hz(Y420)_3D_6CH

01100: 4K60Hz(Y420)_3D_8CH

01101: 4K60Hz_3D_2CH(PCM)

01110: 4K60Hz_3D_6CH

01111: 4K60Hz_3D_8CH

AC-DA14-AUHD

Page 9

Note1: EDID Copy mode: EDID will be copied from sink on OUTPUT 1. The

AC-DA14-AUHD is set this way by default for maximum “Plug & Play” Compatibility. If you

change sink (Display) plugged into OUTPUT 1, please follow the steps below if you wish to use

the new sink’s EDID.

1. Start with power off

2. Set DIP to ‘00000’ (all up).

3. Power on the unit

4. Power on the source device and connect the HDMI input port.

When Changing EDIDs, please follow the steps below

1. Start with power off

2. Set DIP to ‘00000’ (all up).

3. Power on the unit

4. Power on the source device and connect the HDMI input port.

AC-DA14-AUHD

Page 10
