Avocent LongView Wireless Instructions d'installation et d'entretien

590-836-501D

LONGVIEW® IP KVM EXTENDERS

Installer/User Guide

For Technical Support:

www.avocent.com/support

USA Notification

WARNING: Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

Canadian Notification

This digital apparatus does not exceed the Class A limits for radio noise emissions from

digital apparatus set out in the Radio Interference Regulations of the Canadian Department of

Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables

aux appareils numériques de la classe A prescrites dans le Règlement sur le brouillage radioélectrique

édicté par le Ministère des Communications du Canada.

Safety and EMC Approvals and Markings

UL, FCC, cUL, VCCI, C-Tick, CE

Safety certiﬁcations and EMC certiﬁcations for this product are obtained under one or more of the

following designations: CMN (Certiﬁcation Model Number), MPN (Manufacturer’s Part Number) or

Sales Level Model designation. The designation that is referenced in the EMC and/or safety reports

and certiﬁcates are printed on the label applied to this product.

Japanese Approvals

Sound Level Measure

The measured sound level of this appliance is 44.7 dB(A).

Die arbeitsplatzbezogene Geräuschemission des Gerätes beträgt 44,7 dB(A).

LongView® IP KVM

Extenders

Installer/User Guide

Avocent, the Avocent logo and LongView are registered trademarks of

Avocent Corporation or its affiliates in the U.S. and other countries. All

other marks are the property of their respective owners.

Instructions

This symbol is intended to alert the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the appliance.

Dangerous Voltage

This symbol is intended to alert the user to the presence of uninsulated dangerous voltage within the

product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

Power On

This symbol indicates the principal on/off switch is in the on position.

Power Off

This symbol indicates the principal on/off switch is in the off position.

Protective Grounding Terminal

This symbol indicates a terminal which must be connected to earth ground prior to making any other

connections to the equipment.

iii

Chapter 1: Product Overview.......................................................................................... 1

Introduction ....................................................................................................................................... 1

LongView IP KVM extender system features.............................................................................. 1

Transmitter features ................................................................................................................... 3

User station features................................................................................................................... 4

User station modes ..................................................................................................................... 5

Safety Precautions ............................................................................................................................. 6

Chapter 2: Installation ..................................................................................................... 9

Getting Started................................................................................................................................... 9

Items needed to install your LongView IP KVM extender system .............................................. 9

Optional items............................................................................................................................. 9

Mounting Option.............................................................................................................................. 10

Installation Options ......................................................................................................................... 10

Point-to-point installation ........................................................................................................ 11

Connecting power..................................................................................................................... 18

Networked installation.............................................................................................................. 18

Chapter 3: Operations ................................................................................................... 21

Overview .......................................................................................................................................... 21

LED identification .................................................................................................................... 21

Accessing the System ....................................................................................................................... 22

OSD functions .................................................................................................................................. 22

Displaying system information using the OSD......................................................................... 22

Configuring networking parameters using the OSD ................................................................ 23

Setting the OSD timeout............................................................................................................ 24

The Serial Menu............................................................................................................................... 25

Accessing the serial menu......................................................................................................... 25

Navigating the serial menu....................................................................................................... 26

Configuring Network Settings.......................................................................................................... 26

Detecting a transmitter IP address........................................................................................... 32

Authentication.................................................................................................................................. 33

Flash Upgrading your LongView IP KVM Extender System .......................................................... 35

Restoring Factory Default Settings.................................................................................................. 38

TABLE OF CONTENTS

iv LongView® IP KVM Extenders Installer/User Guide

Resetting the LongView IP KVM Extender System.......................................................................... 39

Viewing System Information ............................................................................................................ 39

Configuring Video Input Settings .................................................................................................... 41

Preferred monitor resolutions (EDID preferred timing).......................................................... 42

Session retry settings ................................................................................................................ 43

Configuring the OSD Hotkey Sequence........................................................................................... 44

OSD Inactivity Time-out .................................................................................................................. 45

Audio Performance Settings ............................................................................................................ 46

Display power saving mode......................................................................................................48

Chapter 4: Share Mode .................................................................................................. 51

Using Share Mode ........................................................................................................................... 51

Using a USB device with Share Mode...................................................................................... 51

Using Share Mode .................................................................................................................... 52

Chapter 5: Advanced Operations ................................................................................. 55

Appendices..................................................................................................................... 59

Appendix A: Technical Specifications ............................................................................................. 59

Appendix B: Factory Default Settings ............................................................................................. 69

Appendix C: Technical Support ....................................................................................................... 71

Appendix D: Troubleshooting.......................................................................................................... 72

License Information ....................................................................................................... 77

Product Overview

Introduction

The Avocent LongView® IP KVM extender system, which includes a transmitter and a user

station, provides users with a full workstation desktop experience from anywhere on the corporate

TCP/IP network, while maintaining the target computers securely housed in a corporate data

center. Desktop users can access keyboard, mouse, video, audio, USB mass storage devices and

other USB devices from target computers via the LongView IP KVM extender system.Virtual USB

support is also featured in the LongView IP KVM extender system.

NOTE: References to the LongView IP KVM extender system in this document refer to both the LongView IP

KVM user station (LongView IP, LongView IP DH [Dual-Head], LongView IP HR and LongView IP VG user

stations) and the LongView IP KVM transmitter. The LVIP-T transmitter accompanies the LVIP-R user station, the

LVIPVG-T transmitter accompanies the LVIPVG-R user station, the LVIPHR-T transmitter accompanies the

LVIPHR-R user station and the LVIPDH-T transmitter accompanies the LVIPDH-R user station. See Transmitter

features on page 3 for more information.

LongView IP KVM extender system features

The LongView IP KVM extender system contains the following features.

NOTE: This product contains certain free and/or open source components. To request an open source software

kit for the open source components used in this product, please complete a FOSS Request Form at

http://www.avocent.com/x_For_The_User/Policies/Open_Source_Policy.aspx.

Security

The LongView IP KVM extender system supports Secure Sockets Layer (SSL) over a TCP/IP

connection. All media streams transmitted between the user station and the transmitter are

encrypted. Password protection is also provided to control access to all administration functions.

Flash upgradable

Upgrade your firmware at any time using the XMODEM or HTTP protocols to ensure that your

LongView IP KVM extender system is always running the most current version available. Both the

transmitter and the user station are Flash upgradable.

CHAPTER

2LongView® IP KVM Extenders Installer/User Guide

Ethernet addressing

The user station and the transmitter are IP-addressable devices, giving you the flexibility to locate

them anywhere within your enterprise and at any distance from your desktop users. The user station

and transmitter use standard network protocols to transfer data between the target computer and the

peripheral devices located at the user’s desk. The user station can operate on a network connection

of 100 Mbps or 1 Gbps. For optimum performance, a 1 Gbps connection is recommended.

Support for keyboards, mice and mass storage devices

USB and PS/2 keyboards (up to 109 keys) and mice are fully supported by the LongView IP KVM

extender system. The target computer default keyboard and mouse drivers are fully supported,

enabling the LongView IP KVM extender system to support two, three and five-button mice with

scroll and tilt-wheel capability. Composite mouse and keyboard devices are also supported, along

with mass storage devices and other types of USB devices. CD and DVD/ROM drives, thumb

drives and other non-isochronous USB devices such as printers, touch screens, smart card readers,

and pen tablets are supported as well.

NOTE: The LongView IP KVM extender system does not support isochronous USB devices such as speakers or

web cams.

Support for mass storage devices is also provided on the user stations automatically. Support for

other USB devices is provided on the LVIPHR-R and LVIPDH-R user stations automatically, but

can be overridden by the user. In a LongView IP KVM user station, the first device that is not

keyboard, mouse or mass storage is assigned to the virtual USB channel (vUSB channel) and

passed to the target computer. In the event you want to use the vUSB channel for a keyboard or

mouse, the on-screen display (OSD) allows the default vUSB device to be disabled and a keyboard

or mouse to be assigned to that vUSB channel.

NOTE: The vUSB channel will only be used for devices other than the standard keyboard, mouse and mass

storage devices.

A firmware upgrade is required to utilize mass storage instead of another vUSB device on the

LVIP-R user station. Default support for other USB devices in the LVIP-R user stations is provided

in place of support for a mass storage device. If you need to use mass storage in place of another

vUSB device, go to www.avocent.com and download the LVIP-R user station firmware upgrade.

NOTE: A hub cannot be used to expand the number of USB ports available.

The LVIP-T transmitter provides two USB interfaces:

• One port is low speed while the second video port is set to full speed. These ports are used for

all keyboard and mouse peripheral devices interfacing with the target computer, along with

providing power for the LVIP-T transmitter.

Chapter 1: Product Overview 3

• The other is a high-speed port that is used for virtual media (mass storage devices) peripheral

devices or other USB devices interfacing with the target computer, along with providing power

for the LVIP-T transmitter.

NOTE: The LVIPDH-T and LVIPHR-T transmitters provide a single USB interface, and use an integrated hub

within the transmitter.

Video

Video of 24-bit color depth up to a resolution of 1280 x 1024 at 60 Hz is supported by the LVIP-R

user station and LVIP-T transmitter. Both CRT and flat-panel LCD monitors are supported, and

can be connected to the LongView IP KVM extender system via a DVI-I video connector. VGA

monitors can be attached to the system by using a DVI to VGA adaptor. The system supports DDC

version 2B.

The LVIPHR-R user station and LVIPHR-T transmitter support 24-bit color depth up to a

resolution of 1920 x 1200 at 60 Hz. Both DVI-D and VGA video sources are supported at the

transmitter via a dual connector, allowing the user to choose the appropriate video source.

The LVIPDH-R user station and LVIPDH-T transmitter also support 24-bit color depth up to a

resolution of 1920 x 1200 at 60 Hz. DVI-D computer video sources are supported at the transmitter.

Since DVI-I is supported at the user station, a VGA adaptor can be used to connect to a VGA

monitor.

Both the LVIPHR-R and LVIPDH-R user stations feature support for 1680 x 1050 at 60 Hz.

Transmitter features

The LongView IP KVM transmitter connects externally to the video, audio and USB ports of the

target computer.

The LVIP-T transmitter is attached directly to the target computer and draws its power directly

from two USB ports on the target computer. The LVIPDH-T and LVIPHR-T transmitters are

The transmitter captures, compresses and encrypts the target computer’s media streams and

transmits them to the user station over a standard TCP/IP network.

Interoperability

The LVIPHR-T and LVIPDH-T transmitters are compatible with each other, enabling users with

combined single and dual video computers to gain access from either a single or dual display desks.

NOTE: The LVIPHR-R and LVIPDH-R user stations will only show a single A channel video of the LVIPHR-T and

LVIPDH-T transmitters, respectively.

4LongView® IP KVM Extenders Installer/User Guide

Multiplatform support

The LongView IP KVM transmitter is connected to the target computer via USB connectors. This

enables the user station to interoperate seamlessly with PC, Sun®and Macintosh®workstations.

PS/2 keyboards and mice can also be used.

Screen aspect ratio

The LongView IP KVM transmitter can be configured through the serial console to allow either

normal aspect resolutions or wide screen resolutions as preferred settings.

User station features

The LongView IP KVM user station enables the desktop user’s peripherals to connect to the target

computer via a network connection to the transmitter directly connected to the target computer.

Multiplatform support

LongView IP KVM user stations are compatible with the following operating systems:

• Microsoft®Windows®

• Linux®

•Solaris

• Microsoft Windows Vista®

• Mac OS®

The default keyboard drivers for these operating systems are supported by the user station.

Flexible installation

The LongView IP KVM user station provides you with the following flexible installation features:

• The LongView IP KVM user station can be desk mounted or mounted on the back of a monitor

• Installation requires no new drivers or software

• Standard UTP cabling makes installation simple and keeps costs low

On-Screen Display (OSD)

The LongView IP KVM user station includes an OSD that allows you to view information about

the configuration of your system.

Operations administration and maintenance

The LongView IP KVM user station incorporates a serial menu that allows you to perform

administration and maintenance tasks for both the user station and the transmitter. Examples of

tasks you can perform include configuration of network settings and firmware Flash upgrades.

Autres manuels pour LongView Wireless

Table des matières

Autres manuels Avocent Extenseur

Avocent

Avocent Emerge MPX1550 Manuel utilisateur

Avocent

Avocent AutoView AutoView Wireless Switch Instructions d'installation et d'entretien

Avocent

Avocent Emerge MPX Manuel utilisateur

Avocent

Avocent LongView LongView Wireless Installer Instructions d'installation et d'entretien

Avocent

Avocent Emerge MPX Instructions d'installation et d'entretien

Avocent

Avocent Emerge MPX Instructions d'installation et d'entretien

Avocent

Avocent LongView Wireless Manuel utilisateur

Avocent

Avocent LongView LongView Wireless Instructions d'installation et d'entretien

Avocent

Avocent Emerge 1000 Manuel utilisateur

Avocent

Avocent LongView Wireless Manuel utilisateur

Avocent

Avocent LongView LV1000P Manuel utilisateur

Avocent

Avocent LongView IP Instructions d'installation et d'entretien

Avocent

Avocent LongView IP Manuel utilisateur

Avocent

Avocent LongView 5000 series Instructions d'installation et d'entretien

Avocent

Avocent Emerge MPX1550 Manuel utilisateur

Avocent

Avocent LongView Wireless Instructions d'installation et d'entretien

Avocent

Avocent LONGVIEW 1000 Instructions d'installation et d'entretien

Avocent

Avocent Emerge ECMS2000U Instructions d'installation et d'entretien

Avocent

Avocent LongView Wireless Manuel utilisateur

Avocent

Avocent LONGVIEW 1000 Manuel utilisateur

Avocent

Avocent Emerge MPX1500 Instructions d'installation et d'entretien

Avocent

Avocent HMX 1050 Manuel utilisateur

Avocent

Avocent LongView Companion Manuel utilisateur

Avocent

Avocent Emerge EMS2000 series Instructions d'installation et d'entretien

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
