Avigilon 16MP-HD-PRO-C Manuel utilisateur

Operating and

Installation Instructions

* lens sold separately

Avigilon High Definition Professional IP Camera Models 16MP-HD-PRO-C, 16MP-HD-PRO-M,

11MP-HD-PRO-C, 11MP-HD-PRO-M, 4.2MP-HD-PRO-C, 4.2MP-HD-PRO-M,

4.2MP-HD-PRO-M, 2.0MP-HD-PRO-C, and 2.0MP-HD-PRO-M

Avigilon Corporation

Vancouver, BC

Canada, V6H 4E4

TEL 604.629.5182

FAX 604.629.5183

avigilon.com

2This page is intentionally left blank.

Contents

Important Safety Information 4

Regulatory Notices 6

FCC Notice 6

Disposal and Recycling Information 6

Other Notices 7

Compilation and Publication Notice 7

Intellectual Property Notice 7

Overview 8

Rear View 8

Front View 9

Installation 10

Installation Steps 10

Package Contents 10

Required Tools and Materials 10

Mounting the Lens 10

Mounting the Camera 11

Connecting Power 11

Aiming and Focusing the Camera 13

Connecting the Camera to a Network Video Recorder (NVR) 13

IP Address Selection 14

Advanced Features 15

Upgrading the Firmware 15

Connecting to External Devices 16

Cleaning 17

Image Sensor 17

Body 17

Specifications 18

Limited Warranty & Technical Support 19

Notes 20

Important Safety Information

This manual provides installation and operation information and precautions for the use of

this equipment. Incorrect installation could cause an unexpected fault. Before installing this

equipment read this manual carefully. Please provide this manual to the owner of the equip-

ment for future use.

This symbol indicates the presence of dangerous voltage within and outside

the product enclosure that may constitute a risk of electric shock, serious

injury or death to persons if proper precautions are not followed.

This symbol alerts the user to the presence of hazards that may cause minor

or moderate injury to persons, damage to property or damage to the device

itself if proper precautions are not followed.

Warning – Failure to observe the following instructions may result in severe injury

or death.

Do not use the camera near water or expose the camera to dripping or splashing. Do not

place objects filled with liquids, such as vases above the camera.

Do not expose the camera to rain or moisture.

This camera is designed for indoor use only. For outdoor use, a suitable UL listed out-

door enclosure rated type 3 or better shall be used.

Installation of this camera must be performed by qualified personnel only and conform

to all local codes.

Use only UL listed mounting bracket suitable for the mounting surface and minimum

1.15 kg (2.5 lbs) weight, plus the weight of attached lens.

This product is intended to be supplied by a UL Listed Power Unit marked “Class 2” or

“LPS” or “Limited Power Source” with output rated between 12-24 VDC or 24 VAC, 9 W

min. or Power over Ethernet (PoE), rated 48 VDC, 9 W min.

Do not connect the camera directly to mains power for any reason.

•

Caution – Failure to observe the following instructions may result in injury or dam-

age to the device.

Do not install near any heat sources such as radiators, heat registers, stoves, or other

sources of heat.

Do not subject the cables to excessive stress, heavy loads or pinching.

Do not open or disassemble the camera. The camera contains no user serviceable

parts.

Refer all servicing to qualified personnel. Servicing may be required when the appara-

tus has been damaged, such as when liquid has spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, the apparatus does not

operate normally, or the apparatus has been dropped.

Do not use strong or abrasive detergents when cleaning the camera body.

Use only lenses and accessories recommended by Avigilon.

Avoid leaving the image sensor exposed for extended periods of time. Always cover the

image sensor with either a lens or a dust cap.

Do not allow dust, moisture or any other foreign debris to enter the lens mount.

Never touch the image sensor or any glass elements inside the lens mount except with

the recommended cleaning apparatus.

Do not point the lens directly at the sun or other extremely bright objects otherwise dam-

age to the image sensor could occur.

•

Regulatory Notices

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must ac-

cept any interference received, including interference that may cause undesired operation.

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

FCC Notice

Note: This equipment has been tested and found to comply with the limits for a Class A digi-

tal device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reason-

able protection against harmful interference when the equipment is operated in a commercial

environment.This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful interfer-

ence to radio communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the interference

at his own expense.

Changes or modifications made to this equipment not expressly approved by Avigilon Corpo-

ration or parties authorized by Avigilon Corporation could void the user’s authority to operate

this equipment.

Disposal and Recycling Information

When this product has reached the end of its useful life, please dispose of it according to your

local environmental laws and guidelines.

European Union:

This symbol means that according to local laws and regulations your product

should be disposed of separately from household waste. When this product

reaches its end of life, take it to a collection point designated by local authori-

ties. Some collection points accept products for free. The separate collection

and recycling of your product at the time of disposal will help conserve natu-

ral resources and ensure that it is recycled in a manner that protects human

health and the environment.

Other Notices

Compilation and Publication Notice

This manual has been compiled and published covering the latest product descriptions and

specifications. The contents of this manual and the specifications of this product are subject

to change without notice. Avigilon reserves the right to make changes without notice in the

specifications and materials contained herein and shall not be responsible for any damages

(including consequential) caused by reliance on the materials presented, including but not

limited to typographical and other errors relating to the publication.

Intellectual Property Notice

No license is granted by implication or otherwise under any industrial design, industrial de-

sign rights, patent, patent rights, or copyrights of Avigilon Corporation or its licensors. Trade-

marks and registered trademarks are the property of their respective owners.

Portions of the software in this product are licensed under the eCos License. Distribution

of eCos requires that the eCos source code be made available to Avigilon customers. The

eCos License and eCos source code are available to the public at http://www.avigilon.com/

ecoslicense. Avigilon reserves all rights to all software not covered under the eCos license.

This includes all portions of software that were not distributed to Avigilon as part of the eCos

operating system.

Overview

Rear View

Connection Status LED

I/O Terminals

Power Connector Block Ethernet Port

Serial Number Tag

Feature Symbol Description

Connection Status

LED

Provides information about the camera’s operation. See the

“Connecting the Camera to a Network Video Recorder” sec-

tion for more information on the Connection Status LED.

It can be turned off during operation for covert installations.

See the Avigilon Control Center software documentation for

details on how to turn off the camera’s LEDs.

Ethernet Port Provides connection to NVR for communication and image

data transmission. Provides power to camera when connected

to a network that provides Power over Ethernet.

The Ethernet Port has two status lights indicating link (left) and

activity (right).

Power Connector

Block

Provides power to camera where Power over Ethernet is not

available. Accepts a terminal block with either AC or DC power

connected. DC input can be either polarity.

I/O Terminals Provides connections to external input/output devices. See

the “Connecting to External Devices” section for more informa-

tion on the I/O Terminals.

Serial Number Tag Shows the camera’s serial and part numbers.

Front View

Camera Mounts

(top and bottom)

Lens Mount

Lens Release

Button

Feature Description

Lens Mount Accepts Canon® EF and EF-S lenses.

Lens Release Button Releases lenses that are mounted to the camera.

Camera Mounts Provide mounting points for the camera. Mounts accept 1/4”-20

UNC bolts commonly found on tripods and mounting brackets.

Installation

Installation Steps

Follow these steps to install the camera. Details on how to complete each of these steps are

in the following sections.

Check the package contents against the list below.

Mount a lens to the camera.

Mount the camera.

Connect power if necessary.

Aim and focus the camera.

Connect the camera to Avigilon Control Center software.

Package Contents

The package contains the following:

Avigilon High Definition Professional IP Camera

Dust Cap

Terminal Block

Required Tools and Materials

The following items are required to complete the installation. Items marked with (*) might not

be needed for your installation:

Lens

mounting bracket, tripod or enclosure

(*) small slotted screwdriver with 5/64” or 2 mm blade width (only needed for connecting

power when not using Power over Ethernet)

Mounting the Lens

Important: Avigilon cameras require high-quality lenses to take full advantage of their ad-

vanced imaging capabilities. To avoid poor image quality caused by incorrect lens selection,

use only lenses that are recommended by Avigilon for use with this camera model. For a

list of lenses recommended for use with this camera model, contact your Avigilon dealer or

representative.

Canon® EF or EF-S lenses can be mounted to the camera.

To mount a lens to the camera, complete the following steps:

Remove the dust cap from the lens mount.

Locate the mount index on the lens. The mount index is a red or white dot or square on

the circumference of the camera-end of the lens.

Align the mount index on the lens with the camera’s mount index of the same color.

Turn the lens clockwise until it locks into place.

•
