AVID LP Series

With SPDT V3 Micro Switches,

V3 Inductive Proximity Sensors

Or T-Switches

INSTALLATION AND OPERATION MANUAL

IOM: TECHUK-74 Revision: 4

Prepared By: C.Irwin Date: 4/6/09 Drafting Work Order:23127 ECN: 13247

Reviewed By: T. Lee Date:10/30/17 Approved By: R.Frey Date: 11/1/17

This IOM contains confidential information and is issued in confidence on the condition that it be returned on demand and not be copied,

reproduced, disclosed to others or used in manufacture of the subject matter thereof without the written consent of Crane Co.



CRANECO.

280N.MIDLANDAVE.,STE258,SADDLEBROOK,NJ07663WWW.AVIDCONTROLS.COM

4/6/16 TECHUK-74/ D.W.O. 22926 Page 2 of 7

RevisionHistory



15December2009Initialrelease



19May,2014Rev.1



13October,2015Rev.2



6April,2016Rev.3



CraneCo.Locations



USA:+12017947650



Europe,MiddleEast&Africa:+44(0)1892516277



AsiaPacific:+6568698909



CRANECO.

280N.MIDLANDAVE.,STE258,SADDLEBROOK,NJ07663WWW.AVIDCONTROLS.COM

4/6/16 TECHUK-74/ D.W.O. 22926 Page 3 of 7



Thefollowingdocumentdetailstheinstallation,operationandmaintenanceinstructionsforthe

AVIDLP(LowProfile)giving360°visualandelectricalvalveposition.



Thissymbolwarnstheuserofpossibledanger.Failuretoobservethiswarningmayleadto

personalinjuryordeathand/orseveredamagetoequipment.



 

Thissymbolidentifiesinformationaboutoperatingtheequipmentinaparticularmannerthat

maydamageitorresultinasystemfailure.Failuretoobservethiswarningcanleadtototal

failureoftheequipmentoranyotherconnectedequipment.



Thissymboldrawsattentiontoinformationthatisessentialforunderstandingthe

operationand/orfeaturesoftheequipment.



1.0 MountingInstructions.



AllAVIDLPswitchboxesarefactoryequippedwithdirectandNAMURmounting.



1.1 Pleaserefertothefigures1and2belowtodeterminethetypeofmountingthatisrequired.

Figure1indicatestheconventionaldirectmountandfigure2detailstheNAMURoption.







1.2 Operatetheactuatortothefullyclosedposition.



1.3 DirectMount.



1.3aBeforemountingtheAVIDLPitwillbenecessarytoremovethecover.



AVIDCoupler

11x16mm

Actuator

Namur

Slot.

Fig1.Fig2.

Bracket–

Customer

Supply.

Namur

Shaft

Drive.



CRANECO.

280N.MIDLANDAVE.,STE258,SADDLEBROOK,NJ07663WWW.AVIDCONTROLS.COM

4/6/16 TECHUK-74/ D.W.O. 22926 Page 4 of 7

1.3bTodothis,loosenthe4offM5captivescrewswitheithera8mmA/Fspanner/socketdrive

oranappropriatelysizedflatbladescrewdriver.



1.3cRemovethecoverassemblybyliftingthecoververtically.Keepthecoversafetakingcarenot

todamagethecoversealdetail.



1.3dMounttheAVIDLPswitchboxtotheactuatorbyaligningthe11x16mmshaftadaptortothe

actuatorpinioncoupler.



1.3eEnsurethatthebaseoftheAVIDLPhousingsitsflushwiththetopoftheactuator.



1.3fLocateandtightenthe4offM5captivescrewsinthebaseofthehousingwitheithera8mmA/F

socketdriveoranappropriatelysizedflatbladescrewdriver.



1.3gTightenthescrewstoatorquevalueof18to22Lb/Ins.



1.4 NAMURMount.

Note: DuetothemountingholepatternoftheAVIDLPhousingbeing93.5x41.3mmequal

aboutthecenteroftheshaft,amodifiedNamurbracketisrequired.

Themodificationcaneitherbe4offM5tappedholesor4offM5clearanceholes.



1.4aSecuretheappropriatelysizedmodifiedNamurbrackettotheactuatorusingthescrews/

washerssuppliedwiththeNamurkitfingertightonly.



1.4b(1) Formountingbracketswith(4)M5tappedholes,mounttheLPswitchboxtothe

mountingbracketbyengagingtheNamurshaftdriveintotheactuatorNamurpinionslot.



1.4b(2)Locateandtightenthe(4)M5captivescrewsinthebaseofthehousingwitheithera8mm

A/Fspanner/socketdriveoranappropriatelysizedflatbladescrewdriver.



1.4b(3) Tightenthescrewstoatorquevalueof18to22Lb/Ins.



1.4c(1)Formountingbracketsthathave4offM5clearanceholesitwillbenecessarytoreplacethe

(4)M5captiveLPhousingmountingscrewswithM5x16mmscrewstobesealedwithnew

sealingcaps.

1.4c(2) Tightenthescrewstoatorquevalueof18to22Lb/Ins.



3.0FieldWiring.



Beforeinstallingtheconduitentrygland,pleaseensurethatitisthecorrectsizeandthreadform.

Theincorrectglandmayaffecttheenclosureingressprotectionrating.



3.1Theterminalstripbasehasbeendesignedtooffereasyaccessforwiretermination.



3.1aItisnotnecessarytoremovetheterminalstriptoconnectthefieldwiring,butifrequired,first

removetheterminalstripretainingscrewandkeepsafeasthiswillberequiredtosecurethe

terminalstripwhencomplete.



CRANECO.

280N.MIDLANDAVE.,STE258,SADDLEBROOK,NJ07663WWW.AVIDCONTROLS.COM

4/6/16 TECHUK-74/ D.W.O. 22926 Page 5 of 7

3.1bLifttheterminalstripevenlyoffofthetwobasepinsandterminatethewiringinaccordancewith

thewiringdiagramwhichislocatedontheofthecover.



Note:ForspecialbuildsoftheAVIDLPproductitmaybenecessarytohaveanadditionalA4wiring

diagramplacedinthepackingbox.



3.1cPositiontheterminalstripoverthetwobasepinsandpressevenlyinthedirectionofthepins.



3.1dSecurewiththeretainingscrewremovedinstep3.1a.



4.0EasiFixCamSetting.



4.1Tosettheswitchorsensorcam,liftthebottomcamandturn

untilswitch/sensorisactivatedandthenrelease.Thespring 

willpushthecambackontothesplinedshaft.



4.2Operatetheactuatortotheoppositeextreme,pushdownon 

thetopcamandturnuntiltheupperswitch/sensoris 

activated.



4.3Operatetheactuatorfromoneextremetotheotherseveral

 timestoensurethattheswitches/sensorsactivatecorrectly.



5.0Coverassembly.



5.1BeforeassemblingthecoverassemblytotheAVIDLPhousing,checkthecoversealdetailtoensure

thatitisnotdamagedandfreeofdebris.



5.1Engagetheshaftintothebeaconboreandrotatethecoverassemblysothattheshaftdriveflats

fullyengage.



5.2Approximatelyalignthecoverwiththehousingflangeandsecureusingeithera8mmA/Fspanner/

socketdriveoranappropriatelysizedflatbladescrewdriver.



5.3Tightenthescrewstoatorquevalueof18to22Lb/Ins.



6.0ReadyForUse.



6.1TheAVIDLPswitchboxisnowreadyforuse.



6.2Ifthereareanyun‐usedconduitentries,pleaseensurethattheyarepluggedusingcorrectlyrated

IPblankingplugs.



BottomCam

(CLOSED).

Lift,turn&

release.

TopCam

(OPEN)

Push

down,

turn&

release.



CRANECO.

280N.MIDLANDAVE.,STE258,SADDLEBROOK,NJ07663WWW.AVIDCONTROLS.COM

4/6/16 TECHUK-74/ D.W.O. 22926 Page 6 of 7

7.0TechnicalData.



AreaClassification‐ NonHazardous.



IngressProtection‐ IP66/67



Switch/sensoroptions



MechanicalSwitch– SPDTFormC,

Electricalrating‐ 15A–125/250VAC;6A–24VDC



AlternativeInductiveProximitySensors;



P&F‐ NJ2‐V3‐N,NBB3‐V3‐Z4,NBB2‐V3‐E2

IFM‐ IS5026,IS5001,IS0003,IS5003,NS5002

Turck‐Bi2‐Q10S‐AP6X,Bi2‐Q10S‐YOX

Telemecanique‐XS7‐H10PA340



TerminalStrip:6or8points

ConduitOptions:Upto2xM20x1.5por½”‐14NPT

AmbientTemperatureRange:‐20°Cto+80°C



OverallDimensionsmm(in)


