3
2. Product specification
The
control system was designed for fixed installation at projection systems for business presentations and/or home cinema
applications.
analysis The Control Unit
can be used in slave mode as controller with external control systems (intelligent building installations).
BETA control system is dedicated to control Avers electric projection screens, projector lifts Avers Prolift, electric
courtain systems Avers Virgo and other electric appliances controlled by applying power supply to control terminals.
Electric devices connected to BETA system are controlled automatically based on the attached projector
power consumption . In case of projector malfunction manual control is possible as an option.
BETA control
system is equipped with accessories allowing to transmit IR control signals send from the projectors remote transmitter to
the projector installed behind an IR barrier (like ceiling, wall, etc). This feature sloves common problem to control remotely
projector installed at the projector lift.
Frequently examine the control system installation for imbalance and signs of wear or damage to cables. Do not use if
repair or adjustment is necessary.
Watch the moving screen and keep the people away until the screen is completely rolled in/out. It will help to avoid
injuries caused with moving screen.
All installation work should be carried out by the qualified technician.
Improper installation can cause device damage or health breakdown.
Do not do anything that may damage the power cables.
Operation of the control system with damaged power cords can result with electric shock, electric short circuit and fire.
Do not touch the power cables and the control unit with wet hands.
Do not allow nor Control Unit nor Trigger Transmitter to flood with water, it can result with electric shock, electric short
circuit and fire.
Do not apply any metallic objects into the Trigger Transmitter though the venting holes, it can result with electric shock,
electric short circuit and control system damage.
Always follow the instructions described in the operating manual.
1.1 Declaration of Conformity CE
AVERS Screens Sp. z o.o.
Under it’s own responsibility declares:
All screensand accessories mentioned below are manufactured in Polandaccording to the essential safety
requirements of Council Directive 98/79/WE
The above mentioned products are in conformity with the European Directives
and especially with the norms:
PN-EN 55014-1:2007(U)
PN-EN 50082-1:1997
PN-EN 60335-1:2004
PN-EN 61000-3-2:2007
PN-EN 61000-3-3:1997
IEC 60335-2-97:2007
Manufacturer’s Declaration of ConformityCE
Control systems: ALFA TRIGGER, WIRELESS ALFA TRIGGER
ALFA IR, ALFA RADIO, BETA, DELTA
