AV Access HDW100 Manuel utilisateur



HDW100

1080PWirelessHDMIExtender



UserManual





Disclaimers

Theinformationinthismanualhasbeencarefullycheckedandisbelievedtobe

accurate.AVAccessTechnologyLimitedassumesnoresponsibilityforany

infringementsofpatentsorotherrightsofthirdpartieswhichmayresultfromits

use.

AVAccessTechnologyLimitedassumesnoresponsibilityforanyinaccuraciesthat

maybecontainedinthisdocument.AVAccessTechnologyLimitedalsomakesno

commitmenttoupdateortokeepcurrenttheinformationcontainedinthis

document.

AVAccessTechnologyLimitedreservestherighttomakeimprovementstothis

documentand/orproductatanytimeandwithoutnotice.



Copy,Reproduce,Distributeand/orEditofthisdocumentorpartofitaswellas

utilizationofitscontentsandcommunicationthereoftootherswithoutexpress

authorizationareprohibited.Offenderswillbeheldliableforpaymentofdamages.

Allrightscreatedbypatentgrantorregistrationofautilitymodelordesignpatent



TrademarksNotice

Allproductsorservicenamesmentionedinthisdocumentmaybetrademarksof

thecompanieswithwhichtheyareassociated.



ContactUs

Email:[email protected]

ImportantSafetyInstructions

 Donotexposethisdevicetorain,moisture,drippingorsplashing.Noobjects

filledwithliquids,suchasvases,shallbeplacedonthedevice.

 Donotinstallorplacethisunitinabookcase,built‐incabinet,orinanother

confinedspace.Ensuretheunitiswellventilated.

 Topreventriskofelectricshockorfirehazardduetooverheating,donot

obstructtheunit’sventilationopeningswithnewspapers,tablecloths,curtains,

orsimilaritems.

 Donotinstallnearanyheatsourcessuchasradiators,heatregisters,stoves,or

otherdevice(includingamplifiers)thatproduceheat.

 Donotplacesourcesofnakedflames,suchaslightedcandles,ontheunit.

 Cleanthisdeviceonlywithdrycloth.

 Unplugthisdeviceduringlightningstormsorwhenunusedforlongperiodsof

time.

 Protectthepowercordfrombeingwalkedonorpinched,particularlyatplugs.

 Onlyuseattachments/accessoriesspecifiedbythemanufacturer.

 Referallservicingtoqualifiedservicepersonnel.

www.avaccess.com1



[email protected]



TableofContents

Introduction.................................................................................................2

Overview.........................................................................................................2

Features..........................................................................................................2

PackageContents...........................................................................................2

Application..................................................................................................3

PanelLayout................................................................................................4

Installation..................................................................................................5

Specifications..............................................................................................6

FAQs............................................................................................................7

Warranty.....................................................................................................9

FCCStatement.............................................................................................9

ICStatement..............................................................................................10

DistanceStatement....................................................................................11

Introduction

www.avaccess.com2



[email protected]



Introduction

Overview

The1080PwirelessHDMIextendersetextendsHDMIsignalsfromasourcedevice

toadisplaydevicewirelesslyupto200metersorthroughaCat5e/6cableupto120

meters.Greatforhomesandoffices.

Features

 Transmits1080PHDMIsignalsupto200meterswirelessly.

 Transmits1080PHDMIsignalsupto120metersthroughaCat5e/6cable.

 HDMIloop‐outonthetransmittertoconnecttoalocaldisplay,allowseasy

monitoringofthesourcesignal.

 IRextensionallowsyoutocontrolthesourcedevicefromaremotelocation.

PackageContents

Beforeyoustarttheinstallationoftheproduct,pleasecheckthepackage

contents:

1xTransmitter;1xReceiver;Others:2xAntennas;2xPowerAdapters(DC5V1A);

2xExchangeableUSPlugs;1xIREmitter;1xIRReceiver;4xMountingEars(with

Screws);1xUserManual



Introduction

www.avaccess.com3



[email protected]



Application

(1)1‐1WirelessTransmission



(2)1‐1WiredTransmission



PanelLayout

www.avaccess.com4



[email protected]



Note:

"WorkMode"

SwitchSett ings

Fig1Fig2

TransmitterWirelessWire

ReceiverWirelessWire

PanelLayout

Transmitter



Receiver



Installation

www.avaccess.com5



[email protected]



Installation

Thedevicecanbeplacedonastablesurface.Toinstallthedevicetoasuitable

location,performthefollowing:

1. Posit ionandinstallthemountingbracketsusingthemountingscrews

provided.



2. Repeatabovestepfortheothersideofthedevice.

3. Attachthebracketstothesurfaceyouwanttoholdthedeviceagainstusing

thescrews(notincluded).



Installation

www.avaccess.com6



[email protected]



Specifications

Technical

InputA/VPortTransmitter:1xHDMI

Receiver:1xLAN,1xWLAN

InputResolutionsUpto1080P@60Hz

OutputA/VPortTransmitter:1xHDMI,1xLAN,1xWLAN

Receiver:1xHDMI

OutputResolutionsUpto1080P@60Hz

ComplianceHDMI1.3,HDCP1.4

Transmission

Distance

Wireless:200m/656ft(lineofsight)

Wired:120m/394ft



General

Operating

Temperature

+32°F~+113°F(0°C~+45°C)

10%~90%,non‐condensing

StorageTemperature



‐4°F~140°F(‐20°C~+70°C)

10%~90%,non‐condensing

PowerSupplyDC5V1A

PowerConsumptionTX:3.5W(Max)RX:1.6W(Max)

ESDProtection

Humanbodymodel:

• ±8kV(air‐gapdischarge)

• ±4kV(contactdischarge)

Product

Dimension(WxH

xD)

140mmx21mmx80mm/5.5''x0.83''x3.15"eachforTXand

RX(Antennasnotincluded)

NetWeightTX:0.31kg;RX:0.30kg

GrossWeight1.10kg



FAQs

www.avaccess.com7



[email protected]



FAQs

1. WhatshouldIdowhenLinkLEDison,butthere'snovideooutputonthe

remotedisplay?

• CheckandensuretheWorkModeswitchesonbothtransmitterand

receiver(s)aresettothesamepositions(bothat"Wireless"or"Wire").

• CheckandensuretheHDMIsourceispoweredon,andthe

transmitter'sHDMIInLEDison.

• ConnecttheHDMIsourcedevicedirectlytothedisplaytoseeifthere's

signaloutput.

2. Howtodealwithpoorvideoquality?

• CheckiftheHDMIcablesareconnectedproperly.UsedifferentHDMI

cablesifnecessary.

• Changetheanglesoftheantennasontransmitterandreceiverto

maketheantennasparalleltoeachother(refertoFiga).Operationin

Figb&cisnotrecommended.

 
