HDEX40

40m HDMI Extender

User Manual

Disclaimers

The information in this manual has been carefully checked and is

believed to be accurate. AV Access Technology Limited assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

AV Access Technology Limited assumes no responsibility for any

inaccuracies that may be contained in this document. AV Access

Technology Limited also makes no commitment to update or to keep

current the information contained in this document.

AV Access Technology Limited reserves the right to make

improvements to this document and/or product at any time and

without notice.

Copy, Reproduce, Distribute and/or Edit of this document or part of it

as well as utilization of its contents and communication thereof to

others without express authorization are prohibited. Offenders will be

held liable for payment of damages. All rights created by patent grant

or registration of a utility model or design patent are reserved.

Trademarks Notice

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

Business inquiry: services@avaccess.com

Technical problems: support@avaccess.com

Important Safety Instructions

Do not expose this device to rain, moisture, dripping or splashing.

No objects filled with liquids, such as vases, shall be placed on the

device.

Do not install or place this unit in a bookcase, built-in cabinet, or in

another confined space. Ensure the unit is well ventilated.

To prevent risk of electric shock or fire hazard due to overheating,

do not obstruct the unit’s ventilation openings with newspapers,

tablecloths, curtains, or similar items.

Do not install near any heat sources such as radiators, heat

registers, stoves, or other devices (including amplifiers) that

produce heat.

Do not place sources of naked flames, such as lighted candles, on

the unit.

Clean this device only with dry cloth.

Unplug this device during lightning storms or when unused for

long periods of time.

Protect the power cord from being walked on or pinched,

particularly at plugs.

Only use attachments / accessories specified by the manufacturer.

Refer all servicing to qualified service personnel.

Overview

Table of Contents

Overview...............................................................................................................2

Package Contents.................................................................................................................. 3

Panel .......................................................................................................................................... 4

Installation Instructions.......................................................................................6

Trouble Shooting..................................................................................................7

Specification .........................................................................................................9

Warranty .............................................................................................................10

www.avaccess.com 1

Overview

HDEX40 is a 40m Ultra-slim HDMI extender which offers the extension of full HD

video, audio and one-way IR control up to 40m/130ft along a single Cat5e/6a

cable.

With a feature set including transmission of uncompressed HD video

1080p@60Hz with 24bit color, 2ch audio and one-way IR control, it offers the

added benefit of an incredibly low-profile and ease of installation.

The receiver offers manual EQ settings to fine-tune transmissions by distance for

optimal signal delivery to the display.

Threaded bushings on the 12V DC power connections allow use of both standard

and locking DC power plugs.LED indicators for power supply to units and signal

status to show established connection between connected devices.

Simple and cost-effective HDMI Extender

Transmits 1080P/60Hz 2ch up to 40 meters over Cat5e/Cat6a

HDMI 1.3b and HDCP compliance

Independent HDMI equalization button to adjust high quality picture

One-way IR pass through

Built-in ESD: ±8kV (air-gap discharge) & ±4kV (contact discharge)

Built-in Surge protection: Voltage ± 1kV

Compact size for easy installation

www.avaccess.com 2

Overview

Package Contents

Before you start the installation of the product, please check the package

contents:

1 x Transmitter

1 x Receiver

2 x Power Supply (DC 12V 0.5A)

1 x IR Emitter

1 x IR Receiver (30-50KHz)

2 x Mounting Brackets with screws (Pair)

1 x User manual

www.avaccess.com 3

Overview

Panel

Front Panel

Transmitter/Receiver

No.

Name

Description

1 Power LED

On: The device is powered on.

Off: The device is powered off.

2 Status LED

On: HDMI signal is transmitting successfully.

Blinking/Off: HDMI signal is not transmitting

successfully.

Rear Panel

Transmitter

No.

Name

Description

1 DC 12V DC 12V 0.5A power supply input

www.avaccess.com 4

Overview

No.

Name

Description

2 UTP Out Connects to the receiver

3 IR Out Connects to an IR emitter cable. Secure the IR emitter on

the IR receiving sensor of source device with adhesive.

4 HDMI In Connects to an HDMI source

Receiver

No.

Name

Description

1 DC 12V DC 12V 0.5A power supply input

2 UTP In Connects to the transmitter

3 IR In

Connects to an IR receiver cable. Secure the IR receiver

with adhesive.

Note: The IR receiver enabled angle and distance:

Enabled

Angel

0° 30°(Horizontal) 15°(Vertical)

Distance 8m(Max) 4.5m(Max) 3m(Max)

4 HDMI Out Connects to an HDMI sink

5 EQ

Video Quality Equalization.

After connection, if the video quality is low, press this

button to equalize.

www.avaccess.com 5

Installation Instructions

www.avaccess.com 6

Trouble Shooting

Five Steps of Regular Troubleshooting Routine

1. Power: Please make sure all devices are powered on. (source, extender,

display devices)

2. Indicator: Please make sure LED indicators of transmitter and receiver are

normal according to user manual.

3. Devices: Please make sure picture can be shown normally when connecting

source to display devices directly.

4. Compatibility: Please test other source and display devices to determine

whether it is a compatibility issue.

5. Cable: Plug in and out HDMI/CatX cable or try another HDMI/CatX cable;

Cat 5e/6/6a/7 cable is recommended, do not use Cat 5 cable;

Please make sure CatX cable is less than 130ft for 1080p resolution;

Please make sure the two connectors of one CatX cable are same standard

(EIA/TIA 568B).

Typical questions

1. How to deal with video flash or cut off during the installation?

Indicators should be solid on. If not, please check if the power adapter is

well connected.

Check the cable refer to above Step 5.

Press the EQ button repeatedly, make sure the device match a suitable

EQ value.

2. How to deal with a weak or not working IR signal?

Make sure the IR cables are correctly installed according to the diagram

above.

Check if the IR emitter head is secured over the center of the device IR

www.avaccess.com 7
