AUVIO HBT6000 Manuel utilisateur
THE PERFORMANCE YOU NEED
®
®
HBT6000 Home
HBT6000 Home
Bluetooth
Bluetooth
®Speaker
Speaker
User’s Guide 4000438
Please read this user’s guide before using your new
speaker.
2
2
Package Contents
HBT6000 Home Bluetooth Speaker
Power Adapter
AC Cable
Remote Control
User’s Guide
Features
Sonic Emotion Absolute 3D technology* produces
rich, full sound that permeates every inch of your room
Remote for conveniently controlling the speaker from
a distance
USB charging port charges your devices
Compatible with most Bluetooth enabled tablets,
laptops, MP3 players, and smartphones with iOS or
Android™ platforms
*Sonic Emotion Absolute 3D is
the listening experience.
nNote: You can download the free Auvio EQ App from
the App StoreSM and Google PlayTM to customize your
music.
3
3
Power Your Speaker
Assemble the AC power adapter and connect your speaker
to a standard wall outlet. The standby indicator lights red.
Bluetooth Indicator
Fully insert AC cable
Power Indicator
Standby Indicator
4
4
Use Your Speaker
1. Press the power button (G). The Bluetooth indicator
flashes red and blue as
the speaker searches for a
Bluetooth-enabled device.
2. Activate your device’s Bluetooth function (refer to your
device’s user’s guide).
3. When AUVIO4000438 appears in the Bluetooth
devices list, pair it to your device.
4.
You can control your speaker through your device or the
remote or with the speaker’s buttons.
Press and hold §for 4 seconds to disconnect Bluetooth.
The speaker starts searching for other Bluetooth devices.
In both Bluetooth and AUX modes, the speaker
automatically turns off to save power if it is paused
and receives no operation for 10 minutes or if the
Bluetooth connection is broken for 10 minutes.
After you turn the speaker on, it attempts to resume
Bluetooth connection with the formerly connected
Volume +/–
Previous/Next
Power On/Off
Play/Pause/ Disconnect
Bluetooth
Sonic Emotion
Absolute 3D Indicator
5
5
device. If the connection fails again, the speaker will
start searching for other Bluetooth devices.
nNote:
If the connected device moves too far away from the
speaker, the speaker disconnects from the device but
resumes connection once the device is close.
If your device uses Bluetooth 2.0 and below, enter the
password 0000 for Bluetooth connection.
If the speaker malfunctions, reset it by pressing §
twice when the Bluetooth indicator flashes red and
blue.
Charge Your Device
1. Set the A/B switch for charging your device: Select A
for 5V/1A Apple devices or Bfor other 5V/1A devices.
2.
Use a USB cable (not included) to connect your device
to the speaker’s USB port.
nNote: Consult your device’s specifications before
using the speaker’s charging function.
A/B Switch USB Port
6
6
Use AUX IN
For audio devices without
Bluetooth function, use an
audio cable (not included) to
connect it to your speaker’s
AUX IN jack. The Bluetooth
indicator lights red and then
turns off.
nNote:
Connecting a device to both the AUX IN
port and the USB port may produce interference noise.
Disconnect one of the cables to avoid this noise.
Bluetooth is automatically deactivated when AUX IN
is connected.
When AUX IN is connected, the speaker controls only the
volume. Use the controls on your device to control music
playback.
Use the Remote Control
1. Open the battery compartment
and install one AAA battery (not
included), matching the polarity
symbols (+ and –) marked inside.
2. Point the remote
at the front of
the speaker
to operate
the speaker.
Power On/Off
MUTE
Play/Pause
§
Volume +/–
Previous/Next
/
3D (Turns Sonic Emotion
Absolute 3D effect on or off.)
AAA
7
7
Care and Caution
Do not operate the speaker if it has been damaged in
any way.
Do not place heavy objects on top of the speaker.
Place the speaker on a flat surface. To avoid
electromagnetic interference, do not place the speaker
on top of a TV or other electrical appliance.
Specifications
Power Input .........................................................................DC 15V, 4A
Output ..........................................................10W × 6 RMS (THD 10%)
USB Charging Output........................................................... 5V DC, 1A
Frequency Response ..................................................... 100Hz – 18kHz
Remote Control Range ......................................................19 ft. (5.8 m)
Bluetooth Connection Range............................................. 30 ft. (9.1m)
Bluetooth Protocol ................................................ V2.1 + EDR Class 2
Drivers .............................................................50mm × 4 & 75mm × 2
S/N Ratio...............................................................≥70dB (A weighted)
Impedance..................................................................... 8Ω× 2, 4Ω× 4
Dimensions (HWD) ..................... 4.7 × 14 × 5.2 in (118×355×131mm)
Weight ............................................................................ 5.7 lb (2580g)
Specifications are subject to change and improvement without notice.
Actual product may vary from the images found in this document.
FCC Information
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
8
8
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
If you cannot eliminate the interference, the FCC requires that you
stop using your product. Changes or modifications not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Limited Warranty
Ignition L.P. warrants this product against defects in materials and
workmanship under normal use by the original purchaser for ninety
(90) days after the date of purchase. IGNITION L.P. MAKES NO
OTHER EXPRESS WARRANTIES.
This warranty does not cover: (a) damage or failure caused by or
attributable to abuse, misuse, failure to follow instructions, improper
installation or maintenance, alteration, accident, Acts of God (such
as floods or lightning), or excess voltage or current; (b) improper or
incorrectly performed repairs by persons who are not a Ignition L.P.
Authorized Service Facility; (c) consumables such as fuses or batteries;
(d) ordinary wear and tear or cosmetic damage; (e) transportation,
shipping or insurance costs; (f) costs of product removal, installation,
set-up service, adjustment or reinstallation; and (g) claims by persons
other than the original purchaser.
Should a problem occur that is covered by this warranty, take the
product and the sales receipt as proof of purchase date to the place
of purchase. Ignition L.P. will, at its option, unless otherwise provided
by law: (a) repair the product without charge for parts and labor;
9
9
(b) replace the product with the same or a comparable product; or
(c) refund the purchase price. All replaced parts and products, and
products on which a refund is made, become the property of Ignition
L.P. New or reconditioned parts and products may be used in the
performance of warranty service. Repaired or replaced parts and
products are warranted for the remainder of the original warranty
period. You will be charged for repair or replacement of the product
made after the expiration of the warranty period.
IGNITION L.P. EXPRESSLY DISCLAIMS ALL WARRANTIES AND
CONDITIONS NOT STATED IN THIS LIMITED WARRANTY. ANY
IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW,
INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY
AND, IF APPLICABLE, THE IMPLIED WARRANTY OF FITNESS FOR
A PARTICULAR PURPOSE, SHALL EXPIRE ON THE EXPIRATION OF
THE STATED WARRANTY PERIOD.
EXCEPT AS DESCRIBED ABOVE, IGNITION L.P. SHALL HAVE NO
LIABILITY OR RESPONSIBILITY TO THE PURCHASER OF THE
PRODUCT OR ANY OTHER PERSON OR ENTITY WITH RESPECT
TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR
INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR
ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING,
BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM
INCONVENIENCE AND ANY LOSS OF TIME, DATA, PROPERTY,
REVENUE, OR PROFIT AND ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES, EVEN IF IGNITION L.P. HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied warranty
lasts or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state. You may contact Ignition
L.P. at:
Ignition L.P., 3102 Maple Ave., Suite 450, Dallas, TX 75201 02/09
For product support, call
1-866-315-0426
10
10
Printed
in China
04A13
4000438
© 2013. Ignition L.P. All rights reserved. Auvio is
a registered trademark used by Ignition L.P.
Package and user documentation are recyclable.
User documentation contains recycled material.
The Bluetooth®word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Ignition L.P. is under license.
Other trademarks and trade names are those of their respective owners.
Sonic Emotion and are registered trademarks of sonic emotion ag.
Google Play and Android are trademarks of Google Inc.
Apple is a trademark of Apple Inc., registered in the United States
and other countries. App Store is a service mark of Apple Inc.
Table des matières
Autres manuels AUVIO Intervenants
AUVIO
AUVIO HBT18600SE Manuel utilisateur
AUVIO
AUVIO 4000013 Manuel utilisateur
AUVIO
AUVIO 4000438 Manuel utilisateur
AUVIO
AUVIO 40-268 Manuel utilisateur
AUVIO
AUVIO 4000016 Manuel utilisateur
AUVIO
AUVIO SBT32210 Manuel utilisateur
AUVIO
AUVIO 4000451 Manuel utilisateur
AUVIO
AUVIO XB40210WS Manuel utilisateur
AUVIO
AUVIO Auvio 40-293 Manuel utilisateur
AUVIO
AUVIO Auvio 40-289 Manuel utilisateur
AUVIO
AUVIO SBT32600SE Manuel utilisateur
AUVIO
AUVIO 4000334 Manuel utilisateur
AUVIO
AUVIO Auvio 40-294 Manuel utilisateur
AUVIO
AUVIO 4000708 Manuel utilisateur
AUVIO
AUVIO PBT1000 Manuel utilisateur
AUVIO
AUVIO PBT4000 Manuel utilisateur
AUVIO
AUVIO Auvio 40-290 Manuel utilisateur
AUVIO
AUVIO HBT200W Manuel utilisateur
AUVIO
AUVIO PBT4000 Manuel utilisateur
AUVIO
AUVIO SBT32210 Manuel utilisateur
Manuels Intervenants populaires d'autres marques
Bowers & Wilkins
Bowers & Wilkins 4 Manuel utilisateur
Sonance
Sonance SONOS OUTDOOR Series Manuel utilisateur
Electro-Voice
Electro-Voice EVID FM4.2 Manuel utilisateur
Pioneer
Pioneer XW-HTD630 Manuel utilisateur
Onn
Onn BWA16AA002 Manuel utilisateur
HP
HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
