Your 60Pot XL system

set-up guidelines

Ensuring that the AQUAvalve floods

and drains correctly

Care and maintenance

Making sure your AQUAvalve ﬂoods and

drains correctly is simply achieved and

only takes a few seconds.

Hold the AQUAvalve at eye level so that

you can see the silicon ﬁtted to the top ﬂoat

resting on the hole below it.

The silicon must create a tight seal when

touching the hole.

If it looks like it is not sitting parallel on the

hole below, simply lift the top ﬂoat and

apply pressure to one side of the silicon,

drop the ﬂoat and hold at eye level again.

Repeat the procedure if necessary.

At the end of your growing season, clean

the AQUAvalve using warm soapy water.

Using an old tooth brush will help.

The AQUAvalve is easily disassembled.

The top ﬂoat will slide all the way across

and the bottom ﬂoat is unclipped from its

pivoting position. The circular discs ﬁtted to

the top ﬂoat can also be removed by using

pliers to grip the raised point.

At this point is it advisable to remove the

silicones to avoid them being lost.

It is also handy to have a paper clip or

pipe cleaner to hand so that you can push

it through the AQUAvalve nozzle, this will

remove any lime scale build up that may

have occurred during the growing season.

Blowing through the AQUAvalve nozzle will

also help to remove any build up. Do not

under any circumstances use a drill & drill

bit to clear the AQUAvalve nozzle.

This will potentially damage the

AQUAvalve beyond repair.

Simple care

guidelines

Ensure the silicon is sitting parallel on

the hole below it. Hold at eye level

to check the position is correct

plants

Allow your

establish

before turning your

system

60Pot XL system

setup instructions

Using your front instruction sheet, repeat the module set up instructions for the number of trays.

If you require any guidance email - [email protected]

Advice

Allow your plants to establish for 7-10 days before turning system on

[email protected] I www.autopot.co.uk I +44 (0)844 8581520

Plan views

and options

Suggested layout

• 1x400ltrFlexiTank

• 60x1PotXLtrayandlid

• 60x25ltrpot

• 60xAQUAvalve

• 1x16mmtankadapterandfilter

• 3x16mmin-linetap

• 30x16-6mmcrossconnector

• 1x16mmcrossconnector

• 25metresof16mmpipe

• 30metresof6mmpipe

• 60xXLrootcontroldisc

60Pot XL system contents 1Pot XL dimensions

Advice

• Potupyourplants,waterthrough,thenallowyourplantstoestablishinthepotsforaperiodof7to10days

before turning your system on. This will encourage a stronger and healthier root system.

• Alwaysraiseyourtanktoaminimumof150mmabovethehighestAQUAvalveandre-fillthetankwhen

thereisapproximatelya1/3ofthesolutionleft-NEVERALLOWTHETANKTORUNEMPTY.

• Forbestresults,werecommendmineralfertilisers.Donotuseorganicfertilisers,astheyhaveatendencyto

block small pipe work.

• Clean all substrate from the bottom and sides of the pots before placing in each tray.

This will ensure your system is clean from the start.

• Always use free draining substrates, for example: soil/perlite, coco/perlite, soil/clay pebbles,

coco/claypebbles,rockwool/claypebbles.

Place circular

root control disc

gold face down

in the pot.

Position tray so it is

level.

3Remove collar.

Push 6mm pipe through

collar and attach to

AQUAvalve nozzle.

Rescrew collar - DON’T

overturn... when you feel

it grip STOP.

Connect AQUAvalve

so ‘half moon’ is on T

section in the tray.

Fill pot with medium

and pot up plants.

Water through pot

and allow to drain

outside the tray.

Place pot in the

tray, make sure it is

CLEAN!

Place lid over valve

onto tray.

Cut 6mm/16mm pipe

to appropriate length

380mm

285mm

25 ltr

pot

330mm

372mm

275mm

6mm pipe

16mm pipe

AQUAvalve

16mm click-ﬁt tank adaptor & ﬁlter

16mm in-line tap

16mm cross connector

16mm – 6mm cross connector

400 ltr

FlexiTank

Elevate tank

150mm from

floor to maintain

gravity pressure

System requires minimum

400litreFlexiTank(supplied)

400 ltr

FlexiTank

680mm

1110mm

According to the size of your system connect your

6mm/16mm pipe to relevant ﬁtting or tank...
