Automotive Data Solutions AKX Manuel utilisateur
REVISION DATE
20150402
DOCUMENT NUMBER
NOTICE The manufacturer will accept no responsability for any electrical
damage resulting from improper installation of this product, be that either
damage to the vehicle itself or to the installed device. This device must be in-
stalled by a certified technician. Please review the Installation Guide carefully
before beginning any work.
BEFORE INSTALLATION
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
U.S. Patent No. 8,856,780
INSTALL GUIDE
AKXFORSFO1CAKXFO1EN
HARDWARE
AKXFO1/AKXFO14BAM/AKXFO12WSS
ACCESSORIES
ADSUSB REQUIRED
COMPATIBLE RFKIT OPTIONAL
DIRECTED SMARTSTART & ADSHRNRSSM01 OPTIONAL
FIRMWARE
AKXFORSFO1CAKXFO1
www.autokinetix.comAutomotive Data Solutions Inc. © 2015
21627
U.S. Patent No. 8,856,780
VEHICLE LIST - 1 OF 1
MAKE
MODEL
YEAR
INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS
3X LOCK START/STANDALONE MOD.
A/M ALARM CTRL FROM OEM REMOTES
DOOR LOCK
DOOR UNLOCK
ARM OEM ALARM
DISARM OEM ALARM
TRUNK/HATCH RELEASE
POWER LIFTGATE
RAP SHUTDOWN CTRL
HOOD STATUS (W/OEM SW)
DOOR STATUS
BRAKE PEDAL STATUS
TACHOMETER STATUS
PARKING LIGHT CTRL
FORD
C-MAX STD key AT* 13-15 2 • • • • • • • • • • • • • •
Escape STD key AT* 13-15 2 • • • • • • • • • • • • • •
Focus STD key AT 12-13 1 • • • • • • • • • • • • • •
Focus STD key AT* 14-15 2 • • • • • • • • • • • • • •
Transit Connect STD key AT* 14-15 2 • • • • • • • • • • • • •
* WARNING: Program unlock before start and relock after shutdown on the remote starter. Failure to comply will result in doorlocks not operating after the vehicle goes into deep sleep (approximately 1 hour).
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXFORSFO1CAKXFO1EN
PAGE 2 OF 20
• 20150402
DOC.: #21627
U.S. Patent No. 8,856,780
BOX CONTENTS - 1 OF 1
MS1MS1
MS2MS2
VS2VS2
VS1VS1
VS4VS4
VS3VS3
3
6
4
1
2
5
C
B
A
F
G
E
D
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
7
9
3
10
8
11
12
6
4
1
2
5
2
1
3
7
9
3
10
8
6
4
12
5
2
1
3
4
2
1
3
4
BOX CONTENTS
T-HARNESS 1
AFTERMARKET HOOD SWITCH AND CABLE
WARNING STICKER
10 PIN CONNECTOR
12 PIN CONNECTOR
BLUE
PROGRAMMING
BUTTON
LED 2
LED 1
MODULE
BLACK
BLACK
BLACK
RF PORT/
WEBLINK PORT
BLACK
BLUE
TELEMATIC
PORT
WHITE
WEBLINK CABLE (required accessory sold separately)
WEBLINK CABLE
COMPUTER
USB PORT
4 PIN BLACK CABLE
MODULE
WEBLINK PORT
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXFORSFO1CAKXFO1EN
PAGE 3 OF 20
• 20150402
DOC.: #21627
U.S. Patent No. 8,856,780
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXFORSFO1CAKXFO1EN
PAGE 4 OF 20
• 20150402
COMPATIBLE ACCESSORIES - 1 OF 1
RF KIT
RF KIT (Visit our website to see if this accessory is included with your product)
ANTENNA
FLASH RF DECODER
BEFORE INSTALLATION
RF DECODERBLUE CABLE BLACK CABLE
(NC) RED
(NC) BLACK
BLACK
BLUE
MODULE
RF PORT
TELEMATIC KIT (accessories sold separately)
(NC)
(NC)
(NC)
DIRECTED SMARTSTART
ADS-HRN(RS)-SM01
MODULE
TELEMATIC PORT
DOC.: #21627
U.S. Patent No. 8,856,780
B
D
A
C
COMPONENT LOCATOR - 1 OF 1
INTERIOR VIEW
DRIVER SIDE VIEW PASSENGER SIDE VIEW
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXFORSFO1CAKXFO1EN
PAGE 5 OF 20
• 20150402
DOC.: #21627
U.S. Patent No. 8,856,780
TYPE 1 - WIRE CHART - 1 OF 1
MAKE
MODEL
YEAR
WIRE
DESCRIPTION
CONNECTOR
NAME
CONNECTOR
COLOR
CONNECTOR
TYPE
POSITION
WIRE
COLOR
POLARITY
MODULE
LOCATION
COMPONENT
LOCATOR
FORD
Focus
STD key
AT
12-13
CanH C251 White 16 pin 03 Gray/Orange (DATA) OBDII connector C
CanL C251 White 16 pin 11 Purple/Orange (DATA) OBDII connector C
Parking Light Left C2280A LtGreen 42 pin 01 Yellow/Blue (+) BCM, behind glove box D
Parking Light Right C2280A LtGreen 42 pin 26 Brown/Yellow (+) BCM, behind glove box D
Horn C2280A LtGreen 42 pin 31 Purple/Green (-) BCM, behind glove box D
Driver Door Pin C2280B Brown 60 pin 45 Green/Purple (OPEN) BCM, behind glove box* D
Trunk Release C2280B Brown 60 pin 49 Brown (-) BCM, behind glove box D
Lock/Unlock C2280C Blue 60 pin 11 Brown (-) BCM, behind glove box D
12V C2280G ~ 02 pin 02 Red (+) BCM, behind glove box D
* Wire also found in driver door harness.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXFORSFO1CAKXFO1EN
PAGE 6 OF 20
• 20150402
DOC.: #21627
U.S. Patent No. 8,856,780
VS2VS2
VS1VS1
VS4VS4
VS3VS3
86
30
87
87A
85
MS1MS1
MS2MS2
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
10
1111
12 13 14 15 16
1 2
33
45678
9
10 AMPS
3 AMP
1N5401
DIODE
3 AMP
1N5401
DIODE
A
B C
G
B
C
3 4 5 612 17 18 19 207 8 15 1611 12 13 149 10
23 24 25 26
21
22 37 38 39 4027 28 35 36
31 32 33 3429 30 41 42
A
12
G
3456
12 17 18 19 207 8 15 1611 12 13 149 10
23 24 25 2621 22 37 38 39 4027 28 35 3631 32 33 3429 30
43 44 45 4641 42 57 58 59 6047 48 55 5651 52 53 54
49 50
3 4 5 61 2 17 18 19 207 8 15 1611 12 13 149 10
23 24 25 2621 22 37 38 39 4027 28 35 3631 32 33 3429 30
43 44 45 4641 42 57 58 59 6047 48 55 5651 52 53 5449 50
D
7
9
3
10
8
6
4
1
2
5
C
B
A
F
G
E
D
IMMOBILIZER CONNECTOR
IGNITION CONNECTOR
IGNITION HARNESS
IMMOBILIZER HARNESS
IGNITION SWITCH (UNDER STEERING COLUMN)
CANL - 11
CANH - 03
TRUNK RELEASE (-) - 49
12V (+) - 02
PARKING LIGHT LEFT (+) - 01
PARKING LIGHT RIGHT (+) - 26
HORN (-) - 31
LOCK/UNLOCK (-) - 11
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
02 GRAY (NC)
03 EMPTY
04 EMPTY
05 EMPTY
07 EMPTY
09 EMPTY
10 EMPTY
06 PURPLE/GREEN - LOCK/UNLOCK (-) OUTPUT
08 BLUE/GREEN - TRUNK (-) OUTPUT
11 GRAY/GREEN - HORN (-) OUTPUT
12 DKGREEN/GREEN (NC)
OPTIONAL
TYPE 1 - WIRING DIAGRAM - 1 OF 1
BCM
OBDII
MODULE
BROWN/RED
BROWN/YELLOW
GREEN/WHITE
GREEN/VIOLET
DRIVER DOOR PIN (OPEN) - 45
04 GRAY/WHITE - HOOD STATUS (-) INPUT
03 GRAY/BLACK (NC)
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
AFTERMARKET HOOD SWITCH (-)
TELEMATIC PORT
RF PORT/WEBLINK PORT
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXFORSFO1CAKXFO1EN
PAGE 7 OF 20
• 20150402
DOC.: #21627
U.S. Patent No. 8,856,780
TYPE 2 - WIRE CHART - 1 OF 2
MAKE
MODEL
YEAR
WIRE
DESCRIPTION
CONNECTOR
NAME
CONNECTOR
COLOR
CONNECTOR
TYPE
POSITION
WIRE
COLOR
POLARITY
MODULE
LOCATION
COMPONENT
LOCATOR
FORD
C-MAX
STD key
AT
13-15
CanH C251 White 16 pin 03 Gray/Orange (DATA) OBDII connector C
CanL C251 White 16 pin 11 Purple/Orange (DATA) OBDII connector C
Parking Light Left C2280A LtGreen 42 pin 01 Yellow/Blue (+) BCM, behind glove box D
Parking Light Right C2280A LtGreen 42 pin 26 Brown/Yellow (+) BCM, behind glove box D
Horn C2280A LtGreen 42 pin 31 Purple/Green (-) BCM, behind glove box D
Driver Door Pin C2280B Brown 60 pin 45 Green/Purple (OPEN) BCM, behind glove box* D
Trunk Release C2280B Brown 60 pin 49 Brown (-) BCM, behind glove box D
Lock C2280B Brown 60 pin 36 Gray/Yellow (-) BCM, behind glove box* D
Unlock C2280C Blue 60 pin 26 Purple/Gray (-) BCM, behind glove box* D
Driver Unlock C2280B Brown 60 pin 55 ~ (-) BCM, behind glove box* D
12V C2280G ~ 02 pin 02 Red (+) BCM, behind glove box D
Escape
STD key
AT
13-15
CanH C251 White 16 pin 03 Gray/Orange (DATA) OBDII connector C
CanL C251 White 16 pin 11 Purple/Orange (DATA) OBDII connector C
Parking Light Left C2280A LtGreen 42 pin 01 LtGreen/Orange (+) BCM, behind glove box D
Parking Light Right C2280A LtGreen 42 pin 26 Brown/Yellow (+) BCM, behind glove box D
Horn C2280A LtGreen 42 pin 31 Purple/Green (-) BCM, behind glove box D
Driver Door Pin C2280B Brown 60 pin 45 Green/Purple (OPEN) BCM, behind glove box* D
Trunk Release C2280B Brown 60 pin 49 Brown (-) BCM, behind glove box D
Lock C2280B Brown 60 pin 36 Gray/Yellow (-) BCM, behind glove box* D
Unlock C2280C Blue 60 pin 26 Purple/Gray or Purple/Orange (-) BCM, behind glove box* D
Driver Unlock C2280B Brown 60 pin 55 Blue/Brown (-) BCM, behind glove box* D
12V C2280G ~ 02 pin 02 Red (+) BCM, behind glove box D
Focus
STD key
AT
14-15
CanH C251 White 16 pin 03 Gray/Orange (DATA) OBDII connector C
CanL C251 White 16 pin 11 Purple/Orange (DATA) OBDII connector C
Parking Light Left C2280A LtGreen 42 pin 01 Yellow/Blue (+) BCM, behind glove box D
Parking Light Right C2280A LtGreen 42 pin 26 Brown/Yellow (+) BCM, behind glove box D
Horn C2280A LtGreen 42 pin 31 Purple/Green (-) BCM, behind glove box D
Driver Door Pin C2280B Brown 60 pin 45 Green/Purple (OPEN) BCM, behind glove box* D
Trunk Release C2280B Brown 60 pin 49 Brown (-) BCM, behind glove box D
Lock C2280B Brown 60 pin 36 Empty (-) BCM, behind glove box* D
Unlock C2280C Blue 60 pin 26 Empty (-) BCM, behind glove box* D
Driver Unlock C2280B Brown 60 pin 55 Green/Purple (-) BCM, behind glove box* D
12V C2280G ~ 02 pin 02 Red (+) BCM, behind glove box D
* Wire also found in driver door harness.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXFORSFO1CAKXFO1EN
PAGE 8 OF 20
• 20150402
DOC.: #21627
U.S. Patent No. 8,856,780
TYPE 2 - WIRE CHART - 2 OF 2
MAKE
MODEL
YEAR
WIRE
DESCRIPTION
CONNECTOR
NAME
CONNECTOR
COLOR
CONNECTOR
TYPE
POSITION
WIRE
COLOR
POLARITY
MODULE
LOCATION
COMPONENT
LOCATOR
FORD
Transit Connect
STD key
AT
14-15
CanH C251 White 16 pin 03 Gray/Orange (DATA) OBDII connector C
CanL C251 White 16 pin 11 Purple/Orange (DATA) OBDII connector C
Parking Light Left C2280A LtGreen 42 pin 01 Yellow/Blue (+) BCM, behind glove box D
Parking Light Right C2280A LtGreen 42 pin 26 Brown/Yellow (+) BCM, behind glove box D
Horn C2280A LtGreen 42 pin 31 Purple/Green (-) BCM, behind glove box D
Driver Door Pin C2280B Brown 60 pin 45 Green/Purple (OPEN) BCM, behind glove box* D
Trunk Release ~ ~ ~ ~ ~ ~ Do not connect ~
Lock C2280B Brown 60 pin 36 Gray/Yellow (-) BCM, behind glove box* D
Unlock C2280C Blue 60 pin 26 Purple/Gray (-) BCM, behind glove box* D
Driver Unlock C2280B Brown 60 pin 55 Green/Purple (-) BCM, behind glove box* D
12V C2280G ~ 02 pin 02 Red (+) BCM, behind glove box D
* Wire also found in driver door harness.
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXFORSFO1CAKXFO1EN
PAGE 9 OF 20
• 20150402
DOC.: #21627
U.S. Patent No. 8,856,780
VS2VS2
VS1VS1
VS4VS4
VS3VS3
86
30
87
87A
85
MS1MS1
MS2MS2
A
B
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
3
6
4
1
2
5
C
7
9
3
10
8
11
12
6
4
1
2
5
10
1111
12 13 14 15 16
1 2
33
45678
9
10 AMPS
3 AMP
1N5401
DIODE
3 AMP
1N5401
DIODE
1N5401
DIODE
1N5401
DIODE
A
B C
G
B
C
3 4 5 612 17 18 19 207 8 15 1611 12 13 149 10
23 24 25 26
21
22 37 38 39 4027 28 35 36
31 32 33 3429 30 41 42
A
12
G
3456
12 17 18 19 207 8 15 1611 12 13 149 10
23 24 25 2621 22 37 38 39 4027 28 35 3631 32 33 3429 30
43 44 45 4641 42 57 58 59 6047 48 55 5651 52 53 5449 50
3 4 5 61 2 17 18 19 207 8 15 1611 12 13 149 10
23 24 25 2621 22 37 38 39 4027 28 35 3631 32 33 3429 30
43 44 45 4641 42 57 58 59 6047 48 55 5651 52 53 5449 50
D
7
9
3
10
8
6
4
1
2
5
C
B
A
F
G
E
D
IMMOBILIZER CONNECTOR
IGNITION CONNECTOR
IGNITION HARNESS
IMMOBILIZER HARNESS
IGNITION SWITCH (UNDER STEERING COLUMN)
CANL - 11
CANH - 03
LOCK (-) - 36
DRIVER UNLOCK (-) - 55
TRUNK RELEASE (-) - 49
12V (+) - 02
PARKING LIGHT LEFT (+) - 01
PARKING LIGHT RIGHT (+) - 26
HORN (-) - 31
UNLOCK (-) - 26
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
02 GRAY (NC)
03 EMPTY
04 EMPTY
05 EMPTY
07 EMPTY
09 EMPTY
10 EMPTY
06 PURPLE/GREEN - LOCK (-) OUTPUT
08 BLUE/GREEN - TRUNK (-) OUTPUT
11 GRAY/GREEN - HORN (-) OUTPUT
12 DKGREEN/GREEN - UNLOCK (-) OUTPUT
OPTIONAL
CONNECT ONLY IF THE
WIRE IS PRESENT
TYPE 2 - WIRING DIAGRAM - 1 OF 1
BCM
OBDII
MODULE
BROWN/RED
BROWN/YELLOW
GREEN/WHITE
GREEN/VIOLET
DRIVER DOOR PIN (OPEN) - 45
04 GRAY/WHITE - HOOD STATUS (-) INPUT
03 GRAY/BLACK (NC)
WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
AFTERMARKET HOOD SWITCH (-)
TELEMATIC PORT
RF PORT/WEBLINK PORT
www.autokinetix.comAutomotive Data Solutions Inc. © 2015 AKXFORSFO1CAKXFO1EN
PAGE 10 OF 20
• 20150402
DOC.: #21627
Autres manuels Automotive Data Solutions Démarreur à distance
Automotive Data Solutions
Automotive Data Solutions iDatastart TR3450AF Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions iDatastart TR2450A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR2310A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR2650A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR2350ACT Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR2410A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions 99997 2450RF Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions iDatastart Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR4450A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions iDatastart TR2350AC Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions AKX-CH7-2WSS Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR3450A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR1150A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions FlashLogic FLRSBA Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions OBTR2352A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR2350AK Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR2310AC Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR2550A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions OBTR1151A Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR2450AR Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions iDatastart TR2350ACR Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR2310ACT Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions TR1150AT Manuel utilisateur
Automotive Data Solutions
Automotive Data Solutions iDatastart TR3450AE Manuel utilisateur
