Auto Page RST-2050KE Manuel utilisateur

RST-2050KE

PROFESSIONAL REMOTE CAR STARTER

KEYLESS ENTRY

OPERATION MANUAL

THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY

SYSTEM OPERATIONS

KEYLESS ENTRY FEATURES (optional)

The keyless entry features are activated using the remote control

transmitters.

LOCK:

a) Press the Lock button on the transmitter

b) The vehicle’s parking lights will flash once and doors will

lock. The vehicle’s horn will chirp one time for confirmation.

UNLOCK:

a) Press the Unlock button on the transmitter

b) The vehicles parking lights will flash 2 times and doors

will unlock. The vehicle’s horn will chirp 2 times for

confirmation.

AUXILIARY FUNCTIONS (OPTIONAL)

You may use the CAR icon button on your transmitter for a

separate function. For example, if your vehicle is equipped with

an electric trunk release, the keyless entry system can be

interfaced with it. To release your trunk press and hold the Car

icon button on the transmitter for 2 seconds.

REMOTE START FEATURES

The remote start feature is activated using the remote control

transmitters.

START:

a) Press the red * (star) button for 2 seconds.

b) The vehicles parking lights will flash 2 times and stay “ON”.

c) All doors will lock.

d) The ignition will turn ON and check the system; after 3

seconds the vehicle will start.

e) Three seconds after start the Accessory will turn “ON”.

f) The vehicle will run for the length of run-time selected.

LIMITED LIFETIME WARRANTY PROVISIONS

( U.S. and Continental U.S. Only)

1. AutoPage, Inc. WARRANTS that this new unit has been thoroughly inspected and

tested at the factory prior to delivery. Your AutoPage equipment is guaranteed for

life to the original purchaser/user of the equipment under the following conditions: If

the product proves defective (according to AutoPages testing) within the first year, the

defective unit may be exchanged or repaired free of charge. Proof of Purchase

(dated sales receipt) must accompany all warranty returns; otherwise, your return

will be rejected and sent back. After one (1) year, the purchaser should ship the unit

prepaid to AutoPage with a money order in the amount of $20.00 to cover shipping

and handling charges. Note: The enclosed Warranty Card may be required to receive

warranty services.

2. This WARRANTY will be considered void if the equipment has been misused,

neglected, improperly serviced, altered, dropped or damaged by water, contrary to the

AutoPage OPERATIONS MANUAL. Or, if used with accessories not approved b

AutoPage, which may have contributed to the defect.

3. The purchaser s remedies under this WARRANTY shall be limited to the repair or

replacement of electronic components only. THE FOLLOWING IS NOT COVERED:

Damages or deterioration to cases, batteries, covers and cabinets; the cost of repairs,

replacement and labor of which shall be borne by the purchaser even if occurring

during the WARRANTY period.

4. Any equipment or parts which are claimed to be defective under this WARRANTY

must be sent to the AutoPage Service center with proof of purchase at the

purchaser s expense prior to such return, a Return Authorization Number should be

obtained. AutoPage will return the equipment, charges prepaid. Warranty Service

can be provided through the dealer where the equipment is originally purchased.

5. Any unexpired WARRANTY shall be applicable to equipment and parts in the

possession of the original purchaser only.

6. THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES,

EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTY

OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

7. AutoPage shall not be liable, under the foregoing WARRANTIES or otherwise, for:

Any personal injury of any kind to the purchaser, its employees or agents or anyone

else whomsoever resulting directly or indirectly from the use or presence of the

equipment or parts; Consequential damages of any kind; Any inability of the purchaser

to use the equipment.

CAR LOCATOR FEATURE

Press the Car icon button firmly two times. The horn chirp 6

times and the parking lights will flash 12 times. This a standard

convenience feature to help the owner find his or her vehicle in a

crowded parking lot.

SILENT ARM / DISARM

Press the Lock and Unlock buttons together. This will Lock or

Unlock the vehicle without any horn confirmation chirp(s). The

horn chirps can be permanently deleted via feature program-

ming. See your installer for details.

SECOND CAR OPERATION

The RST2050KE has the capability of operating two vehicle’s.

Once the transmitter has been programmed to both vehicles

(see 2nd car transmitter programming) the primary vehicle will

operate with the normal buttons. The second vehicle will

operate with the shift button. For example, press the side shift

button, then press the Lock button. The second car will lock.

All functions available in normal function to the first will be

operational to the second car in the shift mode.

BATTERY REPLACEMENT

The XT-60 transmitters provided with this keyless entry remote

start uses a mini 12 volt battery. Use a small phillips screw

driver to remove the screw on the back of the transmitter. Then

use a small flat head screw to pry apart the top case of the

transmitter. Make sure to take note of the + and - signs on the

transmitter board. The transmitter will not function if the battery

is put in backwards. Battery life can last up to one year under

normal use. Signs of low battery are shortage of range or dim

light on transmitter.

REMOTE PANIC FUNCTION

The remote transmitter may be used as a remote panic switch

that will activate the security system’s siren and the parking

lights in case of an emergency. To activate the PANIC function,

press and hold the LOCK button for 3 seconds. To cancel the

PANIC, press the Lock or Unlock button on the transmitter.

REMOTE START SAFTEY FEATURES

If the remote start system detects any of the following

conditions prior to remote starting or while the vehicle is

running, the system will not start or will shut down the system

immediatelyifrunning.

SAFTEY FEATURES:

a) The vehicles hood is opened. !

b) The vehicles brake pedal is pressed.

c) The vehicles engine exceeds 2000 RPM idle speed. "

d) The vehicles gearshift lever is in another position other

Park or Neutral. !

e) The programmable run time has elasped.

! Additional installation maybe required.

" When programmed to Tach Sensing only.

DIAGNOSTIC PARKING LIGHTS CODES

The system has a built-in diagnostic routine which

indicates why the unit turned the engine off. The

parking will flash 1 to 5 times to indicate which of the

following caused the engine to shut off or not start from

remote transmitter.

CODES:

1. 1 Flash ---- RPM fail

2. 2 Flash ---- Voltage fail

3. 3 Flash ---- Hood pin fail

4. 4 Flash ---- Brake Light fail

5. 5 Flash ---- Nuetral Saftey fail (Gray wire not grounded)

Operating during remote start function:

The remote start can function while the vehicle is in the Locked

secured mode. When the engine is running from the remote start

you can insert the key into the vehicle’s ignition and turn the key

to the run position. Tap the brake pedal, the remote start will

shut down. The engine will remain running from the key in the

ignition.

TransmitterProgramming

Enter:

1. Turn ignition switch ‘ON’.

2. Press the valet switch 3 times.

3. Horn will give one long chirp and the LED

will begin to flash once every 3 seconds.

Programming:

1. Press the any button on the first transmitter.

2. The horn will chirp 1 time.

3. Within 10 seconds push any button on the second

transmitter

4. The horn will chirp 2 times.

5. To program 3rd & 4th transmitters repeat steps

1 & 2 of programming.

Exit:

1. Turn the vehicle’s ignition to the ‘OFF’ position, Or Leave

for 10 seconds.

2. The horn will give 3 long chirps to confirm exiting program-

ming.

Second Vehicle Transmitter Programming

Your Autopage Remote Start System’s remote transmitter can

be programmed to control a second vehicle equipped with an

RST2050KE or RST2053AL. To program the transmitter to a

second vehicle, follow the instruction for transmitter program-

ming. All steps will be the same except for the following:

1. Prior to pushing any button on the transmitter.

Press the side Green shift button first.

2. Once the Green button is pressed the LED on the

transmitter will illuminate for 3.5 seconds

3. While the LED is illuminated, press any button on the

transmitter.

NOTE: The RST2050KE will only retain the last 4 remote transmitters

programmed into the system. If the transmitter memory is

exceeded, the RST2050KE will start deleting transmitters in

the order of their programming.

Transmitter Button Actions System Function

Press Lock Doors

Once Arm System

Press & Hold Panic

3 Seconds Function

Press Unlock Doors

Once Disarm System

Press & Hold Channel Two

2 Seconds Trunk Control

Press Car

Twice Locator

Press & Hold Remote Start

2 Seconds ON / OFF

Press Both Together Silent

Ignition in OFF Position Arm /Disarm

2nd Car Operation Side Button

Garage Door Opener Switching Code

TRANSMITTER OPERATION

Auto Channel Setting -- XT-60 Transmitter -- RST2050KE

1815 W. 205th Street Suite #101 Torrance, CA 90501

Tel: (310) 618-2002 or (800) 262-2527

www.autopageusa.com

This WARRANTY CARD is for your record. However, AutoPage reserves the right to request you to

submitthisWARRANTYCARDwhichmusthavecompleteinformationtoreceivewarrantyservice. Please

keepthis cardin asecured place.

AUTOPAGE WARRANTY SERVICE CARD

Model: _______________

Serial # _______________

CUSTOMER TO COMPLETE DEALER TO COMPLETE

Mr/Mrs/Ms

_______________________________ ________________________________

YourName(Please Print) CompanyName

_______________________________ ________________________________

Address Dealer’sAddress

_______________________________ ________________________________

City, State, Zip Code City, State, Zip Code

_______________________________ ________________________________

TelephoneNumber Dealer’sTelephoneNumber

_______________________________ ________________________________

Year/Make /Model ofVehicle Date ofInstallation /Purchase

________________________________

Dealer’sSignature

“Proof of Purchase” which includes the store name and date of purchase must accompany all

warranty returns.

Itis thepurchaser’sresponsibilityto keepthis cardfor any futurewarranty service.

Table des matières

Autres manuels Auto Page Démarreur à distance

Auto Page

Auto Page Car-Pro CPX-RS1 Manuel utilisateur

Auto Page

Auto Page RS-750lcd Manuel utilisateur

Auto Page

Auto Page RS-620 Manuel utilisateur

Auto Page

Auto Page RST-1100 Manuel utilisateur

Auto Page

Auto Page C3-RS-625 Manuel utilisateur

Auto Page

Auto Page RS-650 Plus Manuel utilisateur

Auto Page

Auto Page RF-225 Manuel utilisateur

Auto Page

Auto Page RS-610 Manuel utilisateur

Auto Page

Auto Page C3-RS-603 Manuel utilisateur

Auto Page

Auto Page RS-602 Manuel utilisateur

Auto Page

Auto Page XT-12 Mode d’emploi

Auto Page

Auto Page KE-120 Manuel utilisateur

Auto Page

Auto Page C3-RS-625 Manuel utilisateur

Auto Page

Auto Page RS-662 Manuel utilisateur

Auto Page

Auto Page C3-RS-625 Manuel utilisateur

Auto Page

Auto Page C3-RS1100 OLED Manuel utilisateur

Auto Page

Auto Page C3-RS-601 Manuel utilisateur

Auto Page

Auto Page C3-RS-1000 OLED Manuel utilisateur

Auto Page

Auto Page RS-622 Manuel utilisateur

Auto Page

Auto Page RSTKE-900 Manuel utilisateur

Auto Page

Auto Page Car-Pro CPX-RS2 Manuel utilisateur

Auto Page

Auto Page RS-725LCD Manuel utilisateur

Auto Page

Auto Page Car-Pro CPX-RS1 Manuel utilisateur

Auto Page

Auto Page RS-615 Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

AstroStart

AstroStart 803U Manuel utilisateur

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Code Alarm

Code Alarm CA-535 Manuel utilisateur

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel
