AURES TRP100-III Manuel utilisateur

Receipt Printer User’s Manual

MODEL : TRP100-III

All specifications are subject to change without notice

A software tool is available to configure the printer settings on AURES technical

website: www.aures-support.fr

1. Parts Identications 3

2. Setting up the printer 4

2.1 Unpacking 4

2.2 Connecting the cables 5

2.3 Loading the roll paper 9

2.4 Adjustment of paper width 12

3. Control panel and other functions 13

3.1 Control panel 13

3.2 Error Indicating 13

4. Self Test 14

5. Hexadecimal Dump 15

6. Printer cleaning 16

7. Specications 17

7.1. General Specications 17

7.2. Auto Cutter Specications 19

7.3. Interface 19

7.4. Electrical Characteristics 19

7.5. Environmental Requirements 20

7.6. Reliability 20

7.7. Certication 20

8. Command List 21

Table of Contents

1. Parts Identifications

PRINTER COVER

POWER SWITCH

CONTROL PANEL

COVER OPEN PUSH BUTTON

Open this cover to load or

replace a paper.

Used to turn on/off

power to the printer.

Features LED indicators

to indicate printer status

and switches to operate

the printer.

Push down this button to

open the printer cover.

INTERFACE CONNECTOR PERIPHERAL DRIVE CONNECTOR POWER CONNECTOR

INTERFACE CONNECTOR (USB)

2-1. Unpacking

Your printer box should include these items. If any items are damaged or missing, please contact your

dealer for assistance.

The Printer User's Manual Roll Paper

Adaptor(Option) Interface Cable(optional)

2. Setting Up the Printer

2-2. Connecting the Cables

All cables connect to the connector panel on the back of the printer which is shown below:

Before connecting any of the cables, make sure that both the printer and the computer are turned off.

INTERFACE CONNECTOR PERIPHERAL DRIVE CONNECTOR POWER CONNECTOR

INTERFACE CONNECTOR (USB)

For connection to a

host computer. For connection to a

host computer.

For connection of the

AC adapter.

Never unplug the AC

adapter while the

printer is on.

Connects to peripheral

units such as cash

drawer, etc.

Do not connect this to a

telephone.

2-2-1. Interface Connector

<D-SUB 25 Female Serial> <Centronics Parallel>

USB Interface

Pin Signal I/O Description

1 +5V - +5V

2 DATA- - Printer transmit data line

3 DATA+ - Printer transmit data line

4 GND - System Ground

Serial Interface

PIN SIGNAL I/O DESCRIPTION

2 TxD Output Printer transmit data line RS-232C level

3 RxD Input Printer receive data line RS-232C level

4, 20 DTR Output Printer handshake to host line RS-232C level

6 DSR Input Data Send Ready

1, 7 GND - System Ground

Centronics Parallel Interface

PIN SIGNAL I/O DESCRIPTION

1 STROBE- Input Synchronize signal Data received

2~9 DATA0~7 Input/Output Data bit Transmitted 0~7

10 ACK- Output Data receiving completed.

11 BUSY Output Impossible to print of data receiving.

12 PE Output Paper empty

13 SELECT Output Printer status for ON/OFF line

14 AUTO FEED- Input Paper auto feed signal

15 GROUND - System ground

16 GROUND - System ground

17 NC -

18 LOGIC-H - +5V

19~30 GROUND - System ground

31 INIT- Input Initialize

32 ERROR- Output Printer error

33 GROUND - System ground

34 NC -

35 +5V - +5V

36 SELLECT IN- Input Printer select signal

Ethernet Interface

PIN SIGNAL I/O

1 Data Out + Output Data +

2 Data Out - Output Data -

3 GND Ground

4 Data IN + Input Data +

5 Data IN - Input Data -

6 N.C

7 N.C

8N.C

2-2-2. Cash Drawer Connector

The printer can operate two cash drawers with a 6 pin RJ-11 modular connector.

The driver is capable of supplying a maximum current of 0.1A for 510ms or less when not printing.

PIN SIGNAL DESCRIPTION

1 Signal GND -

2 Drawer kick-out drive signal 1 Output

3 Drawer open/close signal Input

4 +24V -

5 Drawer kick-out drive signal 2 Output

6 Signal GND -
